VOVLO EC480D EXCAVATOR 8294433 8294434 TRAVEL REDUCTION GEARBOX

VOVLO EC480D EXCAVATOR 8294433 8294434 TRAVEL REDUCTION GEARBOX

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
EC480D Travel gearbox S/N 210001-/260001- 270001-/280001- NoneNone 8294433,8294434 Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14631200   [2]   Travel gearbox
1   VOE14640155   [1]   Housing
2   VOE14631201   [1]    Gear
3   VOE14608106   [1]   Seal
4   VOE14608107   [1]   Gear
5   VOE14608108   [1]   Flexible coupling
6   VOE14599925   [2]   Seal
7   VOE14608104   [2]   Bearing
8   VOE14608135   [1]   Shim
9   VOE984848   [24]   Hex. socket screw
10   SA9324-21821   [4]   Bearing spindle
11   VOE14608133   [1]   Retainer
12   VOE997523   [20]   Hex. Socket Screw
13   VOE14608115   [1]   Gear
14   VOE14653465   [1]   Cover
15   VOE14608132   [1]   Gear
16   VOE997446   [16]   Hexagon screw
17   VOE955923   [16]   Spring washer
18   VOE14608130   [1]   Gear
19   VOE14882389   [1]   Retaining ring
20   SA1036-00290   [1]   Thrust ring
21   VOE992578   [20]   Hexagon screw
22   VOE955925   [20]   Spring washer
23   VOE14883848   [2]   Plug
24   VOE983524   [2]   O-ring
25   SA9415-43032   [1]   Plug
26   VOE14608109   [1]   Planet carrier
27   VOE14608110   [1]   Planet carrier
28   VOE14505753   [1]   Ring
29   VOE14608111   [4]   Planetary  gear
30   VOE14608112   [4]   Needle bearing
31   VOE14608113   [8]   Washer
32   VOE14608114   [4]   Pin
33   SA9325-06012   [4]   Spring pin
34   VOE14608116   [1]   Planet carrier
35   VOE14608117   [1]   Planet carrier
36   VOE14608118   [3]   Planetary gear
37   VOE14608119   [3]   Needle bearing
38   VOE14608120   [6]   Washer
39   VOE14608121   [3]   Pin
40   SA9325-06012   [3]   Spring pin
41   VOE14608122   [1]   Ring
42   VOE14608124   [1]   Planet carrier
43   VOE14608125   [1]   Planet Carrier
44   VOE14608126   [3]   Planetary gear
45   VOE14608127   [3]   Needle bearing
46   VOE14608128   [6]   Washer
47   VOE14608129   [3]   Pin
48   SA7117-30260   [1]   Thrust ring
49   SA9325-06012   [3]   Spring pin
50   VOE14608123   [1]   Gear
51   VOE14608134   [1]   Ring
