Kawasaki K3V112 hydraulic pump rotory group and spare parts for Kobelco SK200 SK200-6E SK200-8 SK210-8 SK230-6 SK250-6E excavator

Kawasaki K3V112 hydraulic pump rotory group and spare parts for Kobelco SK200 SK200-6E SK200-8 SK210-8 SK230-6 SK250-6E excavator

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
K3V112DT
31N6-10010 31N6-10050 31N6-10051
R210LC-7 R220LC-7
VOE14571504 VOE14632317 EC250D EC250E VOE14719055 VOE14719056

Kobelco SK200-1 SK200-2 SK200-3 SK200-6E SK200-8 SK210-8 SK230-6 SK230-6E SK250-6E
Hyundai R210-5 R220-5 R225-7
Daewoo S220LC DH225-7 DH258-5
Sumitomo SH200A1 SH200A2
Kato HD700 HD800-2
Pos. Part No Qty Parts name Comments
  VOE14571504   [1]   Pump
1   VOE14603707   [2]   Piston
2   VOE14541876   [1]   Cylinder
3   VOE14541875   [1]   Cylinder
4   VOE14541874   [2]   Plate
5   SA14550186   [2]   Check valve
6   VOE14541873   [1]   Pin
7   VOE14596496   [1]   Block
8   VOE14567587   [1]   O-ring
9   SA9016-10611   [3]   Bolt
10   VOE14541872   [1]   Shaft
11   VOE14541871   [1]   Shaft
12   VOE14541870   [1]   Clutch
13   VOE14535425   [2]   Bearing
14   VOE14541869   [2]   Bearing
15   SA8230-14530   [4]   Spacer
16   VOE14541865   [2]   Plate
17   VOE14535448   [2]   Bushing
18   VOE14541864   [18]   Spring
19   SA8230-21920   [2]   Plate
20   VOE14609379   [2]   Support
21   VOE14541861   [1]   Cover
22   VOE14550179   [2]   Casing
23   SA8230-08980   [1]   Valve block
24   SA8230-09690   [8]   Hex. socket screw
25   SA13967630   [4]   Bolt
26   VOE14883837   [3]   Plug
27   SA14550185   [4]   Plug
28   SA14560637   [19]   Plug
29   VOE14540778   [2]   Piston
30   SA8230-09640   [2]   Plug
31   SA8230-09650   [2]   Plate
32   VOE990583   [2]   O-ring
33   VOE14535450   [1]   O-ring
34   VOE14535451   [4]   O-ring
35   VOE14533604   [16]   O-ring
36   VOE14533606   [7]   O-ring
37   VOE14550187   [4]   O-ring
38   VOE14533609   [2]   O-ring
39   VOE14600699   [1]   Seal
40   VOE14625246   [2]   Ring
41   SA9566-20350   [2]   Back-up ring
42   SA8230-25620   [2]   Nut
43   VOE979022   [2]   Hexagon nut
44   SA13914468   [2]   Ring
45   SA8230-26430   [2]   Plate
46   SA7223-00660   [4]   Spring pin
47   VOE14623509   [2]   Eye bolt
48   VOE14540770   [2]   Screw
49   SA8230-09700   [2]   Bolt
50   VOE14552768   [2]   O-ring
51   VOE14550218   [2]   Plug
100   VOE14604627   [1]   Sealing kit
Pos. Part No Qty Parts name Comments
VOE14632317   [1]   Hydraulic pump
1   VOE14603707   [1]   Piston
2 VOE14719055   [2]   Cylinder
3 VOE14719056   [1]   Cylinder
4   VOE14541874   [2]   Plate
5 VOE14541873   [2]   Pin
6   VOE14701586   [2]   Plug
7   VOE14550185   [4]   Plug
8   VOE14718299   [1]   Sealing kit
9   VOE14533615   [2]   O-ring
10   VOE14535450   [1]   O-ring
11   VOE14535451   [4]   O-ring
12   VOE14533604   [18]   O-ring
13   VOE14533606   [6]   O-ring
14   VOE14550187   [4]   O-ring
15   VOE14533609   [2]   O-ring
16   VOE14600699   [1]   Seal
17   VOE14701582   [2]   Ring
18   SA9566-20350   [2]   Back-up ring
K3V112DT
31N6-10010 31N6-10050 31N6-10051 R210LC-7 R220LC-7
Pos. Part No Qty Parts name Comments
*. 31N6-10010 [1]   MAIN PUMP ASSY      *-1,2,3,4
*. 31N6-10050 [1]   MAIN PUMP ASSY      *-1,2,3,4
*. 31N6-10051 [1]   MAIN PUMP ASSY      *-1,2,3,4
*-1. @ [1]   MAIN PUMP UNIT
111 XJBN-00077 [1]   DRIVE SHAFT(F)
113 XJBN-00078 [1]   DRIVE SHAFT(R)
114 XJBN-00351 [1]   COUPLING-SPLINE
123 XJBN-00079 [2]   BEARING-ROLLER
123 XJBN-00950 [2]   BEARING-ROLLER
124 XJBN-00080 [2]   BEARING-NEEDLE
127 XJBN-00081 [4]   SPACER-BEARING
NS141. XJBN-00067 [2]   BLOCK-CYLINDER
NS151. XJBN-00061 [18]   PISTON
NS152. XJBN-00062 [18]   SHOE
*-11. XJBN-01116 [1]   SET PLATE KIT      INCL153,156,158
153 XJBN-00082 [2]   PLATE-SET
156 XJBN-00353 [2]   BUSHING-SPHERICAL
156 XJBN-00083 [2]   BUSHING-SPHERICAL
158 XJBN-00354 [2]   SPACER
157 XJBN-00084 [18]   SPRING-CYLINDER
211 XJBN-00085 [2]   PLATE-SHOE
NS212. XJBN-00070 [2]   PLATE-SWASH
S214. XJBN-00071 [2]   BUSHING-TILTING
251 XJBN-00086 [2]   SUPPORT
261 XJBN-00087 [1]   COVER(F)-SEAL
271 XJBN-00088 [2]   CASING-PUMP
312 XJBN-00089 [1]   BLOCK-VALVE
S313. XJBN-00065 [1]   PLATE-VALVE(R)
S314. XJBN-00068 [1]   PLATE-VALVE(L)
401 XJBN-00090 [8]   SCREW-HEX SOC HD
406 XJBN-00355 [4]   SCREW-HEX SOC HD
466 XJBN-00356 [2]   PLUG
468 XJBN-00357 [4]   PLUG
490 XJBN-00032 [18]   PLUG
NS531. XJBN-00358 [2]   PIN-TILTING
532 XJBN-00091 [2]   PISTON-SERVO
534 XJBN-00092 [2]   STOPPER(L)
535 XJBN-00093 [2]   STOPPER(S)
NS541. XJBN-00073 [4]   SEAT
NS541. XJBN-00859 [4]   SEAT
NS543. XJBN-00074 [2]   STOPPER 1
NS543. XJBN-00860 [2]   STOPPER
NS544. XJBN-00076 [2]   STOPPER 2
NS544. XJBN-00861 [2]   STOPPER
S545. XJBN-00359 [4]   BALL-STEEL
NS548. XJBN-00360 [2]   PIN-FEED BACK
K702. XJBN-00918 [2]   O-RING
K710. XJBN-00095 [1]   O-RING
K717. XJBN-00096 [4]   O-RING
K724. XJBN-00361 [16]   O-RING
K725. XJBN-00362 [4]   O-RING
K728. XJBN-00363 [4]   O-RING
K732. XJBN-00912 [2]   O-RING
K774. XJBN-00098 [1]   SEAL-OIL
789 XJBN-00099 [2]   RING-BACK UP
792 XJBN-00100 [2]   BACK-UP RING
806 XJBN-00101 [2]   NUT
808 XJBN-00364 [2]   NUT
824 XJBN-00102 [2]   RING-SNAP
885 XJBN-00103 [2]   PIN-VALVE PLATE
886 XJBN-00365 [4]   PIN-SPRING
901 XJBN-00104 [2]   BOLT-EYE
953 XJBN-00105 [2]   SCREW-SET
954 XJBN-00106 [2]   SCREW-SET
981 XJBN-00156 [1]   NAME PLATE
981 XJBN-00391 [1]   NAME PLATE
983 XJBN-00341 [2]   PIN
*-2. @ [1]   REGULATOR      SEE 4020
*-3. @ [1]   GEAR PUMP      SEE 4030
*-4. @ [1]   EPPR VALVE      SEE 4040
11 XJBN-00060 [2]   PISTON SUB ASSY      SEE ILLUST
13 XJBN-00063 [1]   CYLINDER ASSY(RH)      SEE ILLUST
14 XJBN-00066 [1]   CYLINDER ASSY(LH)      SEE ILLUST
30 XJBN-00069 [2]   SWASH PLATE SUB ASSY      SEE ILLUST
41 XJBN-00072 [2]   CHECK VALVE ASSY 1      SEE ILLUST
42 XJBN-00075 [2]   CHECK VALVE ASSY 2      SEE ILLUST
530 XJBN-00366 [2]   TILTING PIN ASSY      SEE ILLUST
K. XJBN-00971 [1]   PUMP UNIT SEAL KIT      SEE ILLUST
K1000698E DX225LC DX225LC (S/N 5433~) DX225LCA DX230LC
Pos. Part No Qty Parts name Comments
*. K9001902 [1]   SEAL KIT;MAIN PUMP+REG.
-. K1000698E [1]   MAIN PUMP
11 1.409-00167 [2]   PISTON & SHOE ASS`Y
111 1.405-00060 [1]   SHAFT;DRIVING(F)
113 405-00008 [1]   SHAFT;DRIVING(R)
114 101-00006 [1]   GEAR
123 109-00097 [2]   BEARING;ROLLER
124 109-00098 [2]   BEARING;SPACER
127 1.109-00124 [4]   SPACER;BEARING
13 1.451-00063 [1]   CYLINDER ASS'Y(R)
14 1.451-00060 [1]   CYLINDER ASS'Y(L)
153 1.412-00083 [2]   PLATE;PUSH
156 408-00013 [2]   BUSH;SPHERICAL
157 129-00044 [18]   SPRING;CYLINDER
158 114-00228 [2]   SPACER
211 412-00006 [2]   PLATE;SHOE
250 1.197-00005 [1]   SUPPORT KIT
251 195-00463 [2]   SUPPORT
261 1.430-00212 [1]   COVER;SEAL(F)
271 *NA00349 [2]   CASING;PUMP
30 284-00005 [2]   SWASH PLATE ASS`Y
312 *NA00077 [1]
401 S2229071 [8]   BOLT;SOCKET
406 S2208871 [4]   BOLT;SOCKET
41 K9001849 [2]   CHECK 1 ASS`Y
42 K9001850 [2]   CHECK 2 ASS'Y
466 2181-1950D5 [4]   PLUG PF3/4
468 2181-1890D2 [2]   PLUG
490 181-00519 [18]   PLUG
530 123-00150 [2]   TILTING PIN ASS`Y
532 409-00003 [2]   PISTON;SERVO
534 416-00004 [2]   STOPPER(L)
535 416-00005 [2]   STOPPER(S)
702 S8010355 [2]   O-RING
710 S8010951 [3]   O-RING
717 S8011451 [4]   O-RING
724 S8000081 [16]   O-RING
725 S8000111 [2]   O-RING
728 S8000241 [4]   O-RING
732 S8000185 [2]   . O-RING
774 K9001851 [1]   SEAL;OIL
789 S8060181 [2]   . RING;BACKUP
79 420-00127 [1]   VALVE;PROPORTIONAL
792 S8090350 [2]   RING;BACK-UP
806 S4012933 [2]   NUT
808 S4013133 [2]   NUT
824 S6500400 [2]   RING,RETAINING
885 123-00151 [2]   PIN D8X12L
886 S5740870 [4]   PIN,SPRING
901 S3140025 [2]   BOLT,EYE
953 S3527808 [2]   SCREW,SET
954 120-00130 [2]   SCREW;ADJUST
985 K9001852 [1]   COVER
986 S2212061 [4]   BOLT;SOCKET M10X1.5X25
Pos. Part No Qty Parts name Comments
-. K9001833 [2]   REGULATOR ASS'Y
412 S2209661 [2]   BOLT
413 S2210071 [2]   BOLT
436 S2205261 [2]   BOLT
438 S2204861 [10]   BOLT
496 181-00318 [5]   BOLT;SOCKER
601 1.402-00055 [1]   CASING(A)
611 1.357-00014 [1]   LEVER;FEEDBACK(A)
612 1.357-00005 [1]   LEVER 1(A)
613 1.357-00008 [1]   LEVER 2(B)
614 1.181-00136 [1]   PLUG;CENTER(A)
615 1.181-00090 [1]   PLUG;ADJUST(A)
621 1.409-00189 [1]   PISTON;COMPEN
622 1.402-00036 [1]   CASE,PISTON
623 1.428-00208 [1]   ROD;COMPEN
624 1.131-00165 [1]   SEAT;SPRING(C)
625 1.131-00143 [1]   SPRING;OUTER
626 1.131-00139 [1]   SPRING;INNER
627 K9001834 [1]   RING;ADJUST(C)
628 K9001835 [1]   SCREW,ADJUST(C)
629 K9001836 [1]   COVER C(A)
630 1.121-00044 [1]   NUT;LOCK
631 K9001837 [1]   SLEEVE;PF
641 K9001838 [1]   COVER;PILOT
643 1.409-00204 [1]   PISTON;PILOT
644 1.131-00170 [1]   SEAT;SPRING(Q)
645 1.115-00171 [1]   RING;ADJUST(Q)
646 1.131-00157 [1]   SPRING;PILOT
651 1.425-00001 [1]   SLEEVE
652 1.424-00038 [1]   SPOOL(A)
653 1.131-00166 [1]   SEAT;SPRING
654 1.131-00160 [1]   SPRING;RETURN
655 1.131-00172 [1]   SPRING;SET
656 1.430-00017 [1]   COVER
708 S8010755 [1]   O-RING 1BG-75
722 S8000061 [3]   O-RING
724 S8000085 [9]   O-RING
725 S8000111 [1]   O-RING
728 S8000181 [1]   O-RING
730 S8000221 [1]   O-RING
732 S8000161 [1]   O-RING
733 S8000201 [1]   O-RING
734 S8010251 [1]   O-RING
735 S8002721 [1]   O-RING
755 S8000111 [2]   O-RING
756 S8000261 [1]   O-RING
763 S8010351 [1]   O-RING
801 S4012533 [2]   NUT
814 S6500100 [1]   RING,SNAP
836 1.115-00366 [1]   RING;STOP
858 S6510150 [2]   RING,SNAP
874 1.123-00007 [1]   PIN
875 1.123-00012 [2]   PIN
876 1.123-00014 [2]   PIN
887 1.123-00009 [1]   PIN
897 1.123-00016 [1]   PIN
898 K9001839 [1]   PIN
924 S3524008 [1]   SCREW,SET
925 120-00199 [1]   SCREW,ADJUST(Qi)
K9001811 1 gear pump
  VOE14571141 EC200B EC210B
Pos. Part No Qty Parts name Comments
  VOE14571141   [1]   Pump
1   VOE14600771   [2]   Piston
2   VOE14550188   [1]   Cylinder
3   VOE14550189   [1]   Cylinder
4   SA8230-09800   [2]   Plate
5   SA7223-00450   [2]   Non-return valve
6   SA7223-00460   [2]   Non-return valve
7   SA8230-09790   [1]   Pin
8   VOE14604266   [1]   Non-return valve
9   VOE14533608   [1]   O-ring
10   VOE14533606   [4]   O-ring
11   VOE14560637   [3]   Plug
12   VOE14883837   [1]   Plug
13   SA8230-25880   [3]   Hex. socket screw
14   VOE14574269   [1]   Valve
15   VOE990547   [1]   O-ring
16   VOE990738   [1]   O-ring
17   VOE990546   [1]   O-ring
18   SA8230-09100   [1]   Main shaft
19   SA8230-09070   [1]   Shaft
20   SA8230-09660   [1]   Coupling
21   VOE14535425   [2]   Bearing
22   VOE14535447   [2]   Bearing
23   SA8230-14530   [4]   Spacer
24   VOE14541865   [2]   Plate
25   VOE14535448   [2]   Bushing
26   SA8230-09710   [18]   Spring
27   SA8230-21920   [2]   Plate
28   SA8230-08940   [2]   Support
29   SA8230-09350   [1]   Flange connection
30   VOE14541860   [2]   Casing
31   SA8230-08980   [1]   Valve block
32   SA8230-09690   [8]   Hex. socket screw
33   VOE967630   [4]   Hex. socket screw
34   VOE14883837   [3]   Plug
35   SA9415-11051   [4]   Plug
36   VOE14560637   [21]   Plug
37   VOE14540778   [2]   Piston
38   VOE14600770   [2]   Plate
39   SA8230-09650   [2]   Plate
40   VOE14533615   [2]   O-ring
41   VOE14535450   [1]   O-ring
42   VOE14535451   [4]   O-ring
43   VOE14533604   [16]   O-ring
44   VOE14533606   [4]   O-ring
45   VOE14533612   [4]   O-ring
46   VOE14533609   [2]   O-ring
47   VOE14600711   [1]   Seal
48   VOE14625246   [2]   Ring
49   SA9566-20350   [2]   Back-up ring
50   SA8230-25620   [2]   Nut
51   VOE979022   [2]   Hexagon nut
52   VOE13914468   [2]   Snap ring
53   SA8230-26430   [2]   Plate
54   SA7223-00660   [4]   Spring pin
55   VOE14623509   [2]   Eye bolt
56   SA8230-26780   [2]   Bolt
57   SA8230-09700   [2]   Bolt
100   VOE14555298   [1]   Sealing kit
VOE14535458 1 GEAR PUMP
VOE14604267 2 regulator
400914-00220A  SOLAR 225LC-V
Pos. Part No Qty Parts name Comments
*. 2401-9223KT [1]   SEAL KIT;MAIN PUMP+REG.
*. 720777-PH [1]   CYLINDER ASS'Y(R)
*. 720778-PH [1]   CYLINDER ASS'Y(L)
*. 704543A [2]   PISTON & SHOE ASS'Y
*. 717008 [2]   SWASH PLATE ASS'Y
*. 717005 [2]   TILTING PIN ASS'Y
*. 704550A [2]   CHECK 1 ASS'Y
*. 704544A [2]   CHECK 2 ASS'Y
-. 401-00356A [1]   MAIN PUMP
111 124568 [1]   SHAFT;DRIVING(F)
113 124569 [1]   SHAFT;DRIVING(R)
114 113783 [1]   COUPLING;SPLINE
123 219362 [2]   BEARING;ROLLER
124 219363 [2]   BEARING;SPACER
127 113784 [4]   BEARING;SPACER
141 137491 [1]   BLOCK;CYLINDER
141 137491 [1]   BLOCK;CYLINDER
151 *NA00796 [18]   PISTON
152 *NA01140 [18]   PISTON
153 115786 [2]   PLATE;PUSH
156 121437 [2]   BUSH;SPHERICAL
157 113787 [18]   SPRING;CYLINDER
158 113789 [2]   SPACER
211 113790 [2]   PLATE;SHOE
212 113780 [1]   PLATE;SWASH
214 218550 [1]   BUSH;TILTING
250 718424 [1]   SUPPORT KIT
251 113791 [2]   SUPPORT
261 113792 [1]   COVER;SEAL(F)
271 113794 [2]   CASING;PUMP
310 707849 [1]   VALVE BLOCK KIT
312 113795 [1]   BLOCK;VALVE
313 115798 [1]   PLATE;VALVE(R)
314 115799 [1]   PLATE;VALVE(L)
401 113797 [8]   BOLT;SOCKET M20x210
406 200846 [4]   BOLT;SOCKET M8X20
468 108847 [3]   PLUG;VP
469 108848 [2]   PLUG PF1/8
490 224308 [21]   PLUG
531 113807 [1]   PIN;TILTING
532 113798 [2]   PISTON;SERVO
534 113799 [2]   STOPPER(L)
535 113800 [2]   STOPPER(S)
541 113706 [2]   SEAT
541 113706 [2]   SEAT
543 113705 [2]   STOPPER 1
544 113703 [2]   STOPPER 2
545 200166 [2]   BALL;STEEL
545 200166 [2]   BALL;STEEL
548 113380 [1]   PIN;FEEDBACK
702 220019 [2]   O-RING 1BG35
710 204452 [2]   O-RING 1BG95
717 201639 [4]   O-RING 1BG145
724 201765 [16]   O-RING 1BP8
725 201689 [5]   O-RING 1BP11
726 S8000145 [2]   O-RING 1BP14
728 201721 [3]   O-RING 1BP24
732 220016 [2]   O-RING 1BP18
774 212231 [1]   SEAL;OIL TCV40V
789 203480 [2]   RING;BACK-UP T2P18
79 719753 [1]   VALVE;PROPORTIONAL
792 203418 [2]   RING;BACK-UP T2G45
806 201557 [2]   NUT M16
808 102048 [2]   NUT M20
824 202606 [2]   RING;SNAP
885 113801 [2]   PIN D8X12L
886 200678 [2]   PIN;SPRING
901 212033 [2]   BOLT;EYE
953 118892 [2]   SCREW;SET M16X30L
954 113803 [2]   SCREW;ADJUST
-. 719212 [1]   PUMP;GEAR
-. 722473 [2]   REGULATOR

Materials

Shipping & Returns

Dimensions

Care Instructions

查看完整資訊

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Kawasaki Best Selling Series

檢視全部

Komatsu Best Selling Series

檢視全部

Caterpillar Best Selling Series

檢視全部
