KOMATSU HPV95K HPV112 hydraulic pump 708-2G-00320 708-2G-01320 rotary group and spare parts For PC210-7K PC210-8K PC230-8K PC210-10 PC240-10 PC290-10 excavator

KOMATSU HPV95K HPV112 hydraulic pump 708-2G-00320 708-2G-01320 rotary group and spare parts For PC210-7K PC210-8K PC230-8K PC210-10 PC240-10 PC290-10 excavator

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。

Model：Komatsu HPV95K  HPV112
Part number：708-2G-00320 708-2G-01320
Application：PC210-7K PC210-8K PC230-8K PC210-10 PC240-10 PC290-10
Brand：ITRITA
Material：Aluminum and Steel
Place of production：China
Delivey time：within 3 days
Payment：Western Union，T/T
Warranty（in China）：3 months

Pos. Part No Qty Parts name Comments
     708-2G-00320   [1]   Pump Assembly Komatsu China
  ["SN: K60001-UP"] |$0.
        708-2G-01320   [1]   Pump Subassembly Komatsu China
  ["SN: K60001-UP", "SCC: C2"] |$1.
1   708-2G-12620   [1]   Shaft, Rear Komatsu China
  ["SN: K60001-UP", "SCC: C2"]
2   708-2L-42250   [1]   Bearing Komatsu 0.42 kg.
  ["SN: K60001-UP", "SCC: C2"]
3   708-2E-05040   [1]   Washer Kit Komatsu 0.101 kg.
  ["SN: K60001-UP", "SCC: C2"] analogs:["7082E12190"]
4   708-25-12790   [1]   Ring, Snap Komatsu 0.006 kg.
  ["SN: K60001-UP", "SCC: C2"]
5-6   708-2G-04650   [1]   Block Assembly, Rear Komatsu China
  ["SN: K60001-UP", "SCC: C2"] |$10.
7   708-18-13230   [1]   Pin Komatsu 0.01 kg.
  ["SN: K60001-UP", "SCC: C2"]
8   04065-05820   [1]   Ring, Snap Komatsu 0.01 kg.
  ["SN: K60001-UP", "SCC: C2"]
9   708-2L-43130   [1]   Seat Komatsu 0.03 kg.
  ["SN: K60001-UP", "SCC: C2"]
10   708-2G-13760   [1]   Spring Komatsu China
  ["SN: K60001-UP", "SCC: C2"]
11   708-2H-23141   [1]   Seat Komatsu 0.03 kg.
  ["SN: K60001-UP", "SCC: C2"]
12   708-2G-13740   [1]   Guide Komatsu China
  ["SN: K60001-UP", "SCC: C2"]
13   708-2L-43360   [3]   Pin Komatsu 0.000 kg.
  ["SN: K60001-UP", "SCC: C2"]
14   708-2G-13750   [1]   Retainer Komatsu China
  ["SN: K60001-UP", "SCC: C2"]
15   708-2L-43311   [9]   Piston Subassembly Komatsu 0.28 kg.
  ["SN: K60001-UP", "SCC: C2"]
16-17   708-2G-04660   [1]   Cradle Assembly Komatsu China
  ["SN: K60001-UP", "SCC: C2"] |$22.
18   04020-01228   [1]   Pin, Dowel Komatsu 0.026 kg.
  ["SN: K60001-UP", "SCC: C2"] analogs:["21T3016190"]
19   01252-61025   [6]   Bolt Komatsu 0.028 kg.
  ["SN: K60001-UP", "SCC: C2"]
