VOVLO EC140B Swing gearbox

VOVLO EC140B Swing gearbox

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group Swing gearbox:EC140B Swing gearbox None 8277787-None NoneNone None Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14507900   [1]   Transmission   S/N 10001-11940 S/N 20001-20374
  VOE14541064   [1]   Swing gearbox   S/N 11941- S/N 20375-
1   SA1012-01500   [1]   Valve   S/N 10001-10973
  VOE14722461   [1]   Draining valve   S/N 10974-
2   SA1036-00120   [1]   Thrust washer
3   VOE14540597   [1]   Pipe
4   SA7118-23200   [1]   Planet carrier
5   SA7118-23240   [3]   Pin
6   SA7118-23250   [3]   Bushing
7   SA7147-00150   [6]   Thrust washer
8   SA9325-06012   [3]   Spring pin
9   SA7118-23270   [1]   Roller bearing
10   SA7118-23280   [1]   Roller bearing
11   SA7118-23300   [1]   Shaft   S/N 10001-11631
  VOE14528928   [1]   Shaft   S/N 11632-
12   SA7118-23310   [1]   Collar
13   SA7118-23330   [1]   Seal
14   SA7118-23390   [1]   Sun gear
15   SA7118-23400   [1]   Planet carrier
16   SA7118-23430   [3]   Pin
17   SA7118-23440   [3]   Needle bearing
18   SA7118-23460   [3]   Washer
19   SA7147-00150   [3]   Thrust washer
20   SA9325-06012   [3]   Spring pin
21   VOE914462   [3]   Snap ring
22   SA7118-23490   [1]   Gear
23   SA7118-23520   [2]   Collar   THICK=5.8
  SA7118-23530   [2]   Shim   THICK=5.9
  SA7118-23540   [2]   Shim   THICK=6.0
  SA7118-23550   [2]   Shim   THICK=6.1
  SA7118-23560   [2]   Shim   THICK=6.2
  SA7118-23570   [2]   Shim   THICK=6.3
24   VOE984358   [10]   Hex. socket screw
25   SA9324-21212   [2]   Pin
26   VOE949329   [1]   Gasket
27   VOE990592   [1]   O-ring   S/N 10001-11946
  VOE990592   [1]   O-ring   S/N 11947-
28   VOE14588466   [1]   Gear
29   VOE14514438   [1]   Case
100   VOE14526213   [1]   Overhaul kit
