VOLVO VOE14675391 VOE14723835 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

VOLVO VOE14675391 VOE14723835 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
  VOE14675391
Pos. Part No Qty Parts name Comments
1   VOE14675391   [1]   Pump   S/N -211529
2   VOE978937   [2]   Hexagon screw
3   VOE955926   [2]   Spring washer
4   VOE936445   [2]   Testing nipple   S/N -211526
  SA9415-31011   [2]   Plug   S/N 211527-
  VOE993319   [2]   O-ring   S/N 211527-
Parts on group Hydraulic pump:
Pos. Part No Qty Parts name Comments
  VOE14675391   [1]   Pump   S/N -211529
1   VOE14669172   [1]   Gear pump
2   VOE983507   [1]   O-ring
3   VOE983495   [1]   O-ring
4   VOE983502   [1]   O-ring
5   VOE983501   [1]   O-ring
6   VOE983510   [1]   O-ring
7   VOE983501   [1]   O-ring
8   VOE983502   [1]   O-ring
9   VOE983502   [1]   O-ring
10   VOE14668157   [1]   O-ring
11   VOE14668158   [2]   O-ring
12   VOE14669164   [1]   O-ring
13   VOE14669165   [1]   O-ring
14   VOE14669166   [1]   O-ring
15   VOE14669168   [1]   O-ring
16   RM14669170   [1]   Steering
17   VOE14669169   [1]   O-ring
18   VOE983495   [5]   O-ring
19   VOE14682890   [1]   Solenoid   PWM9101
  VOE14703420       Seal
Parts on group Pump gearbox with assembling parts:
Pos. Part No Qty Parts name Comments
1   VOE14709571   [1]   Valve
2   VOE14709570   [1]   Valve
3   VOE14709582   [1]   Valve
4   VOE14709572   [1]   Sealing kit
5   VOE14709573   [1]   Sealing kit
VOE14675391 VOE14723835
ECR88D
Pos. Part No Qty Parts name Comments
  VOE14723835   [1]   Pump   S/N 210468 - S/N 281313 -
1   VOE14709573   [1]   Sealing kit
2   VOE983495   [5]   O-ring
3   VOE983502   [1]   O-ring
4   VOE14668158   [2]   O-ring
5   VOE14669164   [1]   O-ring
6   VOE14669165   [1]   O-ring
7   VOE983511   [1]   O-ring
8   VOE14709572   [1]   Sealing kit
9   VOE14703420   [1]   Seal
10   VOE14748731   [1]   Gasket
11   VOE14571668   [2]   Ring
12   VOE983494   [2]   O-ring
13   VOE14748759   [1]   Plate
  VOE14748758   [1]   Stop bracket
14   VOE14748809   [1]   Cylinder block
15   VOE14748808   [1]   Valve
16   VOE14748748   [1]   Valve
17   VOE983507   [1]   O-ring
18   VOE983495   [1]   O-ring
19   VOE983502   [1]   O-ring
20   VOE14748750   [1]   Plug
21   VOE14668157   [1]   O-ring
22   VOE14709582   [1]   Valve
23   VOE983501   [1]   O-ring
24   VOE983510   [1]   O-ring
25   VOE14709571   [1]   Valve
26   VOE983501   [1]   O-ring
27   VOE983502   [1]   O-ring
28   VOE14745064   [1]   Needle bearing
29   VOE14748467   [1]   Needle bearing
30   VOE14748468   [1]   Washer
31   VOE14748469   [1]   Shaft
32   SA8230-32410   [3]   Pin
33   VOE14748732   [2]   Bushing
34   VOE14748733   [1]   Washer
35   VOE14748734   [1]   Snap ring
36   VOE14748735   [4]   Bolt
37   VOE14748736   [1]   Pin
38   VOE14748737   [1]   Pin
39   VOE14748738   [1]   Bushing
40   VOE14748739   [1]   Spring
41   VOE14748740   [1]   Spring
42   VOE14748741   [1]   Spring
43   VOE14748742   [1]   Spring
44   VOE14748743   [2]   Screw
45   VOE14748744   [1]   Nut
46   VOE14669172   [1]   Gear pump
47   VOE14748745   [8]   Bolt
48   VOE14748746   [2]   Bolt
49   VOE14748747   [2]   Washer
50   VOE14748749   [1]   Collar
51   VOE14568066   [1]   Plug
52   VOE14748751   [2]   Plug
53   VOE14682890   [1]   Solenoid
54   VOE14748752   [1]   Spool
55   VOE14748753   [1]   Valve
56   VOE14748754   [1]   Spring
57   VOE14669166   [1]   O-ring
58   VOE14669169   [1]   O-ring
59   VOE14669168   [1]   O-ring
60   VOE14748755   [2]   Bolt
61   VOE983510   [1]   O-ring
62   VOE14748756   [1]   Piston
63   VOE14748757   [1]   Bushing
