VOLVO VOE14654548 VOE14715564 SWING MOTOR ROTARY GROUP

VOLVO VOE14654548 VOE14715564 SWING MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
  VOE14654548 VOE14715564
ECR88D
Pos. Part No Qty Parts name Comments
  VOE14654548       Swing motor
1   VOE14527073   [1]   Sealing kit
2   VOE14527081   [1]   Brake
3   VOE14527082   [1]   Body
4   VOE14527083   [8]   Bolt
5   VOE14527681   [6]   Ball
6   VOE14527085   [1]   Washer
7   VOE14527086   [1]   Ring
8   VOE14587959   [1]   Plug
9   VOE14527087   [1]   Shaft
10   VOE14527084   [1]   Piston
11   VOE14527090   [1]   Bolt
12   VOE11714987   [2]   Screw
13   PJ7418169   [1]   Flange
14   RM59425587   [0 1]   Sealing kit
15   VOE14527089   [1]   Disc
16   VOE14671450   [1]   Cover
17   VOE14527071   [11]   Bolt
18   VOE14587960   [1]   Distributor
19   VOE14671460   [1]   Seal
20   VOE11715566   [6]   Spring
21   VOE14674570   [1]   Block
22   VOE11712919   [1]   Screw
23   VOE14527071   [1]   Bolt
24   VOE14668647   [2]   O-ring
25   VOE14674549   [2]   Gasket kit
26   VOE14674567   [2]   Relief valve
27   VOE14676471   [2]   O-ring
28   VOE14669171   [1]   Seal
29   VOE14587953   [2]   O-ring
30   VOE14527073   [1]   Sealing kit
31   VOE14741523   [1]   Sealing kit
32   VOE14527091   [1]   O-ring
13   PJ7418169   [1]   Flange
14   RM59425587   [1]   Sealing kit
Parts on group Swing motor with mounting parts:
Pos. Part No Qty Parts name Comments
1   VOE14654548   [1]   Swing motor   S/N - 213091
1   VOE14715564   [1]   Swing motor   S/N 213092 -
2   VOE997462   [7]   Hexagon screw
3   VOE60110299   [7]   Washer
  VOE14521092   [1]   Pin
  VOE14715564 ECR88D
Pos. Part No Qty Parts name Comments
  VOE14715564   [1]   Swing motor
1   VOE14729990   [1]   Pinion
2   VOE14729991   [1]   Planet carrier
3   VOE14729992   [1]   Planet carrier
4   VOE14729993   [1]   Body
5   VOE14708996   [1]   Repair kit
6   VOE14729994   [1]   Plate
7   VOE14708999   [1]   Sealing kit
8   VOE14709000   [1]   Sealing kit
9   VOE15152201   [1]   Sealing kit
