VOLVO EC700B EXCAVATOR Travel gearbox 8279230,SN -10466-None VOE8279230 `

VOLVO EC700B EXCAVATOR Travel gearbox 8279230,SN -10466-None VOE8279230 `

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group Travel gearbox:
Pos. Part No Qty Parts name Comments
  VOE14592003   [1]   Reduction gear   S/N 10001-10466
1   VOE14535305   [1]   Cover
2   VOE14535304   [2]   Washer
3   VOE14535303   [2]   Plug
4   VOE14535315   [1]   O-ring
5   VOE11701193   [1]   Friction washer
6       [1]   Ring
7       [1]   Cover
8   VOE14535302   [21]   Screw
9   VOE14535307   [1]   Gear
10   VOE14535308   [1]   Gear
11   VOE14535309   [1]   Reduction gear
12   VOE14541725   [1]   Ring
13   VOE14541723   [3]   Pin
14   VOE14541726   [3]   Clip
15   VOE14541727   [3]   Planetary gear
16   VOE14541728   [3]   Bearing
17   VOE14541724   [1]   Case
18   VOE14535310   [1]   Reduction gear
19   VOE14541725   [1]   Ring
20   VOE14541732   [4]   Clip
21   VOE14541729   [4]   Planetary gear
22   VOE14541731   [4]   Bearing
23   VOE14541730   [1]   Case
24   VOE14535311   [1]   Ring
25   VOE14535312   [5]   Clip
26   VOE14535313   [0005]   Planetary gear
27   VOE14541733   [0001]   Planetary gear
28   VOE14541734   [0002]   Bearing
29   VOE14541735   [0002]   Spacer
30   VOE14541736   [0001]   Clip
31   VOE14535314   [5]   Spacer
32   VOE14535315   [1]   O-ring
33   VOE14535316   [1]   Housing
34   VOE14535317   [1]   Screw
35   VOE14535318   [1]   Stop
36   VOE14535319   [1]   Nut
37   VOE14535320   [1]   Gear
38   VOE14535321   [2]   Bearing
39   VOE14535322   [1]   Spacer
40   VOE14535323   [1]   Spacer
41   VOE14535324   [1]   O-ring
42   VOE14535325   [1]   Cover
43   VOE14535326   [24]   Screw
44   VOE14535327   [1]   Seal
45   VOE14535328   [1]   Clip
46   VOE14535329   [1]   Retainer
47   VOE14535330   [1]   Hub
48   VOE14535331   [1]   O-ring
49   VOE14535332   [1]   Adapter
50   VOE14535333   [12]   Screw
51   VOE14535334   [4]   Screw
