VOLVO EC700B EC700BHR EC700C EXCAVATOR VOE14535293 VOE14622007 VOE14645005 SWING MOTOR PARTS

VOLVO EC700B EC700BHR EC700C EXCAVATOR VOE14535293 VOE14622007 VOE14645005 SWING MOTOR PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
  VOE14535293
Pos. Part No Qty Parts name Comments
1       [2]   Swing Motor
2   VOE14609494   [1]   Swing gearbox
3   VOE14535293   [1]   Swing motor
4   VOE14512785   [1]   Level gauge
5   VOE14531019   [2]   Washer
6   VOE14526643   [2]   Plate
7   VOE14531024   [2]   Pin
8   VOE14524406   [2]   Pinion
9   VOE997464   [4]   Hexagon screw
10   VOE991649   [24]   Hexagon screw
11   VOE60110301   [24]   Washer
VOE14535293 VOE14622007 VOE14645005
EC700B EC700BHR EC700C
Pos. Part No Qty Parts name Comments
VOE14535293   [1]   Swing motor   S/N - 10664
VOE14622007       Swing motor   S/N 10665 -
VOE14645005       Swing motor
1   SA8230-01090   [1]   Snap ring
2   SA8230-04460   [1]   Ring
3   SA8230-00910   [1]   Sealing ring
4   SA7177-03140   [1]   Roller bearing
4   VOE14626954       Roller bearing
5   VOE14512779   [1]   Housing
6   SA8230-04390   [1]   Plate
7   SA8230-04400   [1]   Plate
8   SA8230-04300   [1]   Spring
9 SA8230-04060   [1]   Cylinder
10   VOE14512780   [1]   Piston   9pcs
11   SA8230-22940   [4]   Friction plate
12   SA8230-22950   [4]   Plate
13   SA8230-04090   [1]   Piston
14   SA8230-00260   [1]   O-ring
15   SA8230-00270   [2]   O-ring
16   SA8230-04270   [19]   Spring
17   VOE14650657   [4]   Seal
18   SA8230-04310   [4]   Spring
19   SA8230-04350   [4]   Bushing
20   SA7273-10751   [2]   Cap
21   VOE983502   [2]   O-ring
22   SA8230-00630   [1]   Bolt
23   SA8230-04120   [2]   Piston
24   VOE14512781   [1]   Cover
25   SA8230-00560   [2]   Pin
26   VOE14508590   [2]   Valve
27   VOE14625246   [2]   Ring
28   VOE983503   [2]   O-ring
29   VOE990557   [3]   O-ring
30   SA8230-37030   [1]   Cap
31   SA8230-04180   [1]   Valve
32   VOE14535294   [2]   Relief valve
33   VOE983529   [1]   O-ring
34   VOE984135   [7]   Hex. socket screw
35   SA8230-11610   [2]   Cap
36   VOE14596241   [2]   Spring
37   VOE14880821   [2]   Back-up ring
38   VOE983525   [2]   O-ring
39   SA8230-11110   [2]   Non-return valve
40   SA9324-21317   [1]   Pin
41   SA8230-04020   [1]   Plate
42   SA8230-00840   [1]   Needle bearing
43   SA8230-01100   [1]   Snap ring
44   SA8230-00610   [1]   Bolt
45   SA8230-00160   [3]   O-ring
46   SA8230-00190   [2]   O-ring
100   VOE14535301   [1]   Seal
