VOLVO EC700B EC700BHR EC700C EC700CHR EXCAVATOR VOE14522564 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

VOLVO EC700B EC700BHR EC700C EC700CHR EXCAVATOR VOE14522564 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
VOE14522564
EC700B EC700BHR EC700C EC700CHR
Pos. Part No Qty Parts name Comments
1   VOE14592003   [2]   Reduction gear   S/N 10001-10466
  VOE14592003   [2]   Reduction gear   S/N 10467-
2   VOE14522564   [2]   Travel motor
3   VOE60110301   [60]   Washer
4   VOE992996   [60]   Hexagon screw
5   VOE60110300   [8]   Washer
6   VOE990855   [8]   Hexagon screw
7   VOE14539096   [2]   O-ring
Parts on group Travel motor:
Pos. Part No Qty Parts name Comments
  VOE14522564   [1]   Travel motor
1   VOE14534991   [1]   Case
2   VOE14534992   [1]   Plate
3   SA8230-34150   [2]   Seat
4   VOE14534995   [2]   Spring
5   VOE14534996   [2]   Seat
6   VOE14534997   [2]   Cap
7   VOE14534998   [2]   Relief valve
8   SA8230-32630   [2]   O-ring
9   SA8230-32380   [2]   Valve
10   VOE983494   [2]   O-ring
11   VOE14534999   [3]   Valve
12   SA8230-33400   [2]   Spring
13   SA8230-34050   [2]   Plug
14   VOE990557   [2]   O-ring
15   SA8230-33430   [2]   Guide
16   SA8230-33940   [2]   Plug
17   VOE14535000   [2]   Non-return valve
18   VOE14535001   [2]   Spring
19   VOE14535002   [2]   Plug
20   VOE983527   [2]   O-ring
21   VOE14535003   [2]   Valve
22   VOE14539093   [1]   Valve
23   SA8230-32350   [2]   Plug
24   VOE983502   [6]   O-ring
25   SA8230-32690   [2]   Plug
26   SA8230-33390   [2]   Plug
27   VOE14535005   [1]   Shaft
28 VOE14535006   [1]   Block
29 VOE14535007   [1]   Plate
30 VOE14535008   [9]   Piston
31   VOE14535009   [1]   Plate
32   VOE14535010   [1]   Holder
33   VOE14535011   [1]   Plate
34   VOE14535012   [2]   Ball
35   VOE14535013   [2]   Piston
36   VOE14535014   [2]   Spring
37   VOE14535015   [1]   Roller bearing
38   VOE14535016   [1]   Roller bearing
39   VOE14535017   [1]   Collar
40   VOE14535018   [1]   Pin
41   VOE14535019   [9]   Spring
42   VOE14535020   [2]   Plate
43   VOE14535021   [4]   Plate
44   VOE14535022   [3]   Plate
45   VOE14535023   [1]   Piston
46   SA8230-34070   [1]   O-ring
47   VOE14535024   [1]   Ring
48   VOE14535025   [1]   O-ring
49   VOE14535026   [1]   Ring
50   VOE14535027   [10]   Spring
51   SA8230-32320   [4]   Pin
52   VOE14535028   [1]   Seal
53   VOE960262   [1]   O-ring
54   SA9511-12010   [1]   O-ring
55   VOE14535029   [2]   Plug
56   VOE983524   [2]   O-ring
57   VOE14535030   [9]   Bolt
58   VOE14535031   [2]   Plug
59   VOE14535032   [1]   Plate
600   VOE14535034   [1]   Block   Inc. 28,29,30
700   VOE14535035   [1]   Plate   Inc.31,32
800   VOE14535036   [1]   Case   Inc. 1,35,58
900   VOE14539094   [1]   Plate   Inc. 9,11,21,22
100   VOE14535033   [1]   Seal
