VOLVO EC480D EXCAVATOR VOE8288862 SWING REUDCTION GEARBOX

VOLVO EC480D EXCAVATOR VOE8288862 SWING REUDCTION GEARBOX

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
EC480D Swing gearbox S/N 210001-/260001- 270001-/280001- 8288862-None VOE8288862 None Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14541030   [2]   Swing gearbox
1   VOE14540404   [1]   Shaft
2   VOE14540405   [1]   Collar
3   VOE990596   [1]   O-ring
4   VOE14508911   [1]   Seal
5   VOE14509281   [1]   Cover
6   VOE993025   [10]   Hexagon screw
7   VOE14640027   [1]   Roller  bearing   E PROD
7   VOE14640027   [1]   Roller bearing   L PROD
8   SA7118-30510   [1]   Case
9   SA7118-34510   [1]   Adapter
10   VOE14529015   [1]   Valve
11   VOE950677   [4]   Pin
12   VOE14558674   [1]   Roller bearing
13   SA9541-01090   [1]   Retaining ring
14   SA7118-30380   [1]   Thrust ring
15   SA7118-30390   [1]    Gear
16   SA7118-30480   [1]   Washer
17   SA7118-30200   [1]   Planet carrier
18   SA7118-30230   [1]   Pin
19   SA7118-30260   [6]   Washer
20   SA7118-30220   [3]   Planetary gear
21   SA9325-08010   [3]   Spring pin
22   SA7118-30210   [1]   Planet carrier
23   VOE14528725   [1]   Planet carrier
24   SA7118-30410   [1]   Planet carrier
25   SA7118-30420   [3]   Planetary gear
26   SA7118-30460   [3]   Washer
27   VOE914469   [3]   Retaining ring
28   VOE14528726   [3]   Pin
29   SA7118-30450   [3]   Washer
30   VOE14550879   [3]   Needle bearing
31   SA7118-30490   [1]   Sun gear
32   SA7118-30350   [1]   Ring gear
33   SA7118-30370   [1]   Plate
34   VOE984363   [12]   Hex. socket screw
  VOE14526214   [1]   Overhaul kit
EC480D Swing gearbox S/N 210001-/260001- 270001-/280001- 8288862-None VOE8288862 None Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14713782   [2]   Swing gearbox
  VOE14724277   [2]   Swing gearbox
1   VOE14711374   [1]   Shaft
2   VOE14540405   [1]   Collar
3   VOE990596   [1]   O-ring
4   VOE14508911   [1]   Seal
5   VOE14509281   [1]   Cover
6   VOE993025   [10]   Hexagon screw
7   VOE14640027   [1]   Roller  bearing   E PROD
7   VOE14640027   [1]   Roller bearing   L PROD
8   SA7118-30510   [1]   Case
9   SA7118-34510   [1]   Adapter
10   VOE14529015   [1]   Valve
11   VOE950677   [4]   Pin
12   VOE14558674   [1]   Roller bearing
13   SA9541-01090   [1]   Retaining ring
14   SA7118-30380   [1]   Thrust ring
15   SA7118-30390   [1]    Gear
16   SA7118-30480   [1]   Washer
17   SA7118-30200   [1]   Planet carrier
18   SA7118-30230   [1]   Pin
19   SA7118-30260   [6]   Washer
20   SA7118-30220   [3]   Planetary gear
21   SA9325-08010   [3]   Spring pin
22   SA7118-30210   [1]   Planet carrier
23   VOE14528725   [1]   Planet carrier
24   SA7118-30410   [1]   Planet carrier
25   SA7118-30420   [3]   Planetary gear
26   SA7118-30460   [3]   Washer
27   VOE914469   [3]   Retaining ring
28   VOE14528726   [3]   Pin
29   SA7118-30450   [3]   Washer
30   VOE14550879   [3]   Needle bearing
31   SA7118-30490   [1]   Sun gear
32   SA7118-30350   [1]   Ring gear
33   SA7118-30370   [1]   Plate
34   VOE984363   [12]   Hex. socket screw
  VOE14526214   [1]   Overhaul kit
