VOLVO EC480D EXCAVATOR 8291523 8291970 TRAVEL REDUCTION GEARBOX

VOLVO EC480D EXCAVATOR 8291523 8291970 TRAVEL REDUCTION GEARBOX

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
EC480D Travel gearbox S/N 210001-/260001- 270001-/280001- NoneNone 8291523, 8291970, Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14608847   [1]   Reduction  Gear   S/N -210304/-271749 S/N -280118
  VOE14648036   [1]   Travel gearbox   S/N 210305-/271750- S/N 280119-
1   SA8230-09980   [1]   Cover
2       [1]   Cover
3       [1]   Ring
4       [1]   Ring
5   VOE11701193   [1]   Friction washer
6   VOE14262071   [2]   Plug
7   VOE11701192   [1]   O-ring
8   VOE14262070   [2]   Washer
9   VOE14541740   [16]   Screw
10   VOE11706896   [1]   Reduction  gear
11   SA8230-21320   [1]   Ring
12   VOE14541726   [3]   Clip
13   SA8230-21130   [3]   Planetary gear
14   SA8230-22070   [3]   Roller bearing
15   VOE14541741   [1]   Case
16   SA8230-35760   [1]   Reduction gear
17   SA8230-21310   [1]   Ring
18   VOE14541743   [4]   Clip
19   SA8230-21170   [4]   Planetary gear
20   SA8230-22080   [4]   Roller bearing
21   VOE14541742   [1]   Case
22   VOE14608963   [1]   Planet carrier
23   SA8230-35600   [4]   Bushing
24   VOE14608962   [4]   Screw
25   SA8230-22290   [4]   Screw
26   SA8230-36310   [1]   O-ring
27   SA8230-35430   [1]   Screw
28   SA8230-35780   [1]   Housing
29   VOE14541746   [1]   Bushing
30   VOE14541747   [1]   Spacer
31   VOE14541748   [2]   O-ring
32       [1]   Bearing
33   VOE14541745   [1]   Case
34   VOE11706895   [1]   Sun gear
35   SA8230-35550   [1]   Sun gear
36   SA8230-35560   [1]   Sun gear
37   VOE15175856   [1]   Ring
38   VOE14604802   [1]   Hub
39   VOE14604801   [1]   Retainer
40   SA8230-35520   [1]   Shaft
41   VOE11701198   [1]   O-ring
42   VOE14604484   [7]   Disc
43   SA8230-35630   [6]   Ring
44   SA8230-22380   [1]   Ring
45   SA8230-22170   [1]   O-ring
46   SA8230-22180   [1]   O-ring
47   SA8230-22390   [1]   Ring
48   VOE14604654   [1]   Piston
49   VOE11702537   [21]   Spring
50   SA8230-35590   [1]   Spacer
51   SA8230-35420   [1]   Clip
52   VOE14604655   [1]   Adapter
53   VOE11707954   [1]   O-ring
54   SA8230-22050   [2]   Screw
55   VOE14604803   [1]   Clip
56   SA8230-22110   [1]   O-ring
57   VOE14520527   [4]   Roller bearing
  VOE14585155   [1]   Overhaul kit
