VOLVO EC480D EXCAVATOR 8286646 8286647 8286648 TRAVEL REDUCTION GEARBOX

VOLVO EC480D EXCAVATOR 8286646 8286647 8286648 TRAVEL REDUCTION GEARBOX

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
EC480D Travel gearbox S/N 210001-/260001- 270001-/280001- NoneNone 8286646, 8286647, 8286648 Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14557192   [1]   Travel gearbox
1   SA8230-09980   [1]   Cover
2   VOE14262071   [1]   Plug
3       [1]   Ring
4   VOE14541737   [1]   Ring
5   VOE11701193   [1]   Friction washer
6   VOE14262071   [2]   Plug
7   VOE11701192   [1]   O-ring
8   VOE14262070   [2]   Washer
9   VOE14541740   [16]   Screw
10   VOE14608961   [1]   Planet carrier
11   SA8230-35760   [1]   Reduction  gear
12   SA8230-21310   [1]   Ring
13   VOE14541743   [4]   Clip
14   SA8230-21170   [4]   Planetary gear
15   SA8230-22080   [4]   Roller bearing
16   VOE14541742   [1]   Case
17   VOE14608963   [1]   Planet carrier
18   SA8230-35600   [4]   Bushing
19   VOE14608962   [4]   Screw
20   SA8230-35780   [1]   Housing
21   VOE14541746   [1]   Bushing
22   VOE14541747   [1]   Spacer
23   VOE14541748   [2]   O-ring
24       [1]   Bearing
25   VOE14541745   [1]   Case
26   VOE14608960   [1]    Gear
27   SA8230-35550   [1]   Sun gear
28   SA8230-35560   [1]   Sun gear
29   VOE15175856   [1]   Ring
30   VOE14608964   [1]   Hub
31   VOE14535329   [1]   Retainer
32   VOE14535334   [4]   Screw
33   SA8230-35430   [16]   Screw
