VOLVO EC480D EC480DHR EC480E EC480EHR PL4809D EXCAVATOR VOE14612482 VOE14673219 SWING MOTOR PARTS

Name: VOLVO EC480D EC480DHR EC480E EC480EHR PL4809D EXCAVATOR VOE14612482 VOE14673219 SWING MOTOR PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

VOLVO EC480D EC480DHR EC480E EC480EHR PL4809D EXCAVATOR VOE14612482 VOE14673219 SWING MOTOR PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

VOE14612482 VOE14673219 EC480D EC480DHR EC480E EC480EHR PL4809D EC480D Swing motor with mounting parts S/N 210001-/260001- 270001-/280001- NoneNone S/N -274467, -280568 Autodata Volvo online

Pos.	Part No	Qty	Parts name	Comments
	VOE14614206	[2]	Swing motor S/N -210514,-260044, -273831,-280355
	VOE14702281	[2]	Swing motor S/N 273832-, 280356-
1	VOE14541030	[2]	Swing gearbox S/N -210514,-260044
2	VOE14612482	[2]	Swing motor S/N -210514,-260044 -273831,-280355
2	VOE14673219	[2]	Swing motor S/N 273832-,280356-
VOE14673219 EC480D Swing motor with mounting parts S/N 210001-/260001- 270001-/280001- NoneNone S/N 274468-, 280569- Autodata Volvo online

Pos.	Part No	Qty	Parts name	Comments
	VOE14713781	[2]	Drive unit	S/N -274504, -280591
	VOE14724275	[2]	Drive unit	S/N 274505-/280592-
1	VOE14713782	[2]	Swing gearbox	S/N -274504, -280591
1	VOE14724277	[2]	Swing gearbox	S/N 274505-/280592-
2	VOE14673219	[2]	Swing motor
EC480D Swing motor S/N 210001-/260001- 270001-/280001- 8288862-None VOE8288862 None Autodata Volvo online

Pos.	Part No	Qty	Parts name	Comments
	VOE14612482	[2]	Swing motor
1	VOE14594933	[1]	Piston
2	VOE14594354	[1]	Plug
3	VOE14529771	[1]	Plate
4	VOE14594934	[1]	Casing
5	SA7223-00660	[2]	Spring pin
6	VOE14612051	[1]	Plug
7	VOE14529774	[1]	Shaft
8	VOE14529773	[1]	Cylinder
9	VOE14594937	[1]	Valve block
10		[1]	Casing
11	VOE14560637	[4]	Plug
12	VOE14552329	[2]	O-ring
13	VOE14512960	[6]	Screw
14	SA8230-36560	[2]	Valve
15	VOE983509	[1]	O-ring
16	VOE14625240	[1]	Ring
17	VOE14594354	[2]	Plug
18	VOE14529759	[1]	Plug
19	VOE14550664	[1]	Valve
20	VOE14594353	[2]	Plug
21	VOE14511643	[3]	Screw
22	VOE14529762	[3]	Plate
23	VOE14529772	[1]	Spring
24	VOE14529770	[1]	Plate
25	VOE14529769	[1]	Plate
26	VOE14529837	[1]	Casing
27	VOE14552322	[1]	Cover
28	SA8230-14160	[2]	Control plunger
29	SA8230-14150	[2]	Spring
30	SA8230-25820	[4]	Bolt
31	VOE14529766	[1]	Ring
32	VOE14529761	[4]	Plate
33	SA8230-26520	[1]	Roller bearing
34	VOE14529765	[1]	Bearing
35	VOE14550218	[2]	Plug
36	SA8230-25680	[2]	Plug
37	SA8230-26191	[2]	O-ring
38	VOE14552321	[1]	O-ring
39	VOE983526	[2]	O-ring
40	VOE14552320	[1]	Seal
41	VOE14512953	[1]	Piston
42	VOE14693875	[1]	O-ring
43	SA8230-25540	[1]	O-ring
44	VOE14529763	[20]	Spring
45	VOE14599563	[2]	Relief valve
46	VOE990582	[2]	O-ring
100	VOE14620596	[1]	Seal
EC480D Swing motor S/N 210001-/260001- 270001-/280001- NoneNone None Autodata Volvo online

Pos.	Part No	Qty	Parts name	Comments
	VOE14673219	[1]	Swing motor
1	VOE14529766	[1]	Ring
2	VOE14552322	[1]	Cover
3	VOE14529768	[1]	Casing
4	VOE14511643	[3]	Screw
5	VOE14550664	[1]	Valve
6	VOE14594353	[2]	Plug
7	VOE14552320	[1]	Seal
8	VOE14623517	[1]	Bearing
9	VOE14529774	[1]	Shaft
10	VOE14594933	[1]	Piston
11	VOE14529770	[1]	Plate
12	VOE14529771	[1]	Plate
13	VOE14529772	[1]	Spring
14	VOE14529773	[1]	Cylinder
15	VOE14529761	[4]	Plate
16	VOE14529762	[3]	Plate
17	VOE14693875	[1]	O-ring
18	SA8230-25540	[1]	O-ring
19	VOE14512953	[1]	Piston
20	VOE14529763	[20]	Spring
21	VOE14529769	[1]	Plate
22	VOE14529765	[1]	Bearing
23	VOE14735330	[1]	Casing
24	VOE14552321	[1]	O-ring
25	SA8230-25680	[2]	Plug
26	VOE14552329	[2]	O-ring
27	SA8230-14150	[2]	Spring
28	SA8230-14160	[2]	Control plunger
29	VOE14736363	[2]	Relief valve
30	VOE990582	[2]	O-ring
31	VOE14594354	[3]	Plug
32	SA8230-25820	[4]	Bolt
33	VOE14612051	[1]	Plug
34	VOE14736364	[1]	Valve block
35	VOE14550661	[1]	Casing
36	VOE14550218	[2]	Plug
37	VOE993320	[2]	O-ring
38	VOE14529757	[2]	O-ring
39	VOE14533603	[2]	O-ring
40	SA8240-03610	[4]	Screw
41	SA8230-36560	[2]	Valve
42	VOE983509	[2]	O-ring
43	VOE14625240	[2]	Ring
