VOLVO EC460C EC480D EC480DHR PL4809D EXCAVATOR VOE14595548 VOE14625693 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

VOLVO EC460C EC480D EC480DHR PL4809D EXCAVATOR VOE14595548 VOE14625693 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
VOE14595548 VOE14625693 EC460C EC480D EC480DHR PL4809D
Pos. Part No Qty Parts name Comments
  VOE14595548   [1]   Hydraulic  pump
1   VOE14594327   [2]   Piston
2   VOE14552768   [4]    O-ring
3   VOE14533615   [2]   O-ring
4   VOE14563795   [1]   Cylinder
5   VOE914470   [2]   Snap ring
6   VOE14551525   [2]   Pin
7   VOE14563796   [1]   Cylinder
8   SA7223-00660   [5]   Spring pin
9   VOE14880555   [2]   Eye bolt
10   VOE14502011   [2]   Plate
11   SA7223-00670   [2]   Set screw
12   SA7223-00680   [2]   Set screw
13   VOE979022   [4]   Hexagon nut
14   VOE14536032   [1]   Shaft
15   VOE14536031   [1]   Shaft
16   SA8230-09360   [1]   Connecting rod
17   SA7241-00421   [2]   Roller bearing
18   VOE14511981   [2]   Bearing
19   SA8230-08850   [3]   Spacer
20   SA8230-09090   [1]   Hydraulic unit
21   VOE14536027   [2]   Plate
22   VOE14510070   [2]   Bushing
23   SA7223-00180   [18]   Spring
24   VOE14512543   [2]   Plate
25   SA7223-00210   [2]   Plate
26   SA7223-00260   [2]   Support
27   VOE14551796   [1]   Cover
28   VOE14594328   [2]   Casing
29   VOE14594329   [1]   Cover
30   VOE14615364   [1]   Cover
  VOE14535197   [4]   Screw
31   SA7223-00390   [4]   Hex. socket screw
32   SA8230-09900   [4]   Hex. socket screw
33   VOE13967630   [8]   Allen Hd Screw
34   VOE14550218   [4]   Plug
35   VOE14550185   [4]   Plug
36   VOE14560637   [28]   Plug
37   VOE14512382   [1]   Plug
38   VOE14536023   [2]   Pin
39   VOE14512544   [1]   Cover
40   VOE983919   [8]   Hex. socket screw
41   VOE14536033   [2]   Piston
42   SA7223-00420   [2]   Stop
43   SA7223-00430   [2]   Stop
44   SA7223-00690   [2]   O-ring
45   VOE14535385   [1]   O-ring
46   VOE14533617   [2]   O-ring
47   VOE14615353   [2]   O-ring
48   VOE14533035   [3]   O-ring
49   VOE14533604   [19]   O-ring
50   VOE14533606   [2]   O-ring
51   VOE14550187   [4]   O-ring
52   SA7223-00700   [2]   O-ring
53   VOE14600699   [1]   Seal
54   VOE14692341   [2]   Ring
55   SA7223-00650   [2]   Ring
100   VOE14594333   [1]   Seal
30   VOE14574269   [1]   Valve
Pos. Part No Qty Parts name Comments
  VOE14625693   [1]   Hydraulic pump
1   VOE14704173   [2]   Regulator kit
