VOLVO EC460 EXCAVATOR SA1142-07410 SA7118-30030 SWING MOTOR ROTARY GROUP AND SPARE PARTS

VOLVO EC460 EXCAVATOR SA1142-07410 SA7118-30030 SWING MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
SA1142-07410 SA7118-30030 EC460
Pos. Part No Qty Parts name Comments
1   SA7118-30030   [2]   Swing Motor
2   SA7118-30130   [1]   Gearbox
3   SA1142-07410   [1]   Swing Motor
4   SA7118-30610   [1]   Pipe
5   SA7118-30600   [1]   Gauge
6   VOE914465   [1]   Snap ring
7   VOE984088   [8]   Hex. socket screw
Pos. Part No Qty Parts name Comments
  SA1142-07410   [1]   Swing Motor
1   SA8230-35500   [1]   Piston
2   SA14500016   [9]   Piston
3   SA14500018   [9]   Seat
4   SA8230-14390   [1]   Casing
5   SA14500015   [1]   Casing
6   SA7223-00660   [2]   Spring pin
7   SA8230-36570   [1]   Valve
8   SA8230-29070   [1]   Casing
9   SA8230-25640   [2]   Plug
10   VOE983502   [2]   O-ring
11   VOE983503   [2]   O-ring
12   VOE983493   [2]   O-ring
13   SA8240-03610   [4]   Screw
14   SA8230-36560   [2]   Valve
15   VOE983509   [1]   O-ring
16   VOE14625240   [1]   Ring
17   SA8230-13640   [1]   Shaft
18   SA8230-13890   [1]   Cylinder
19   SA8230-14240   [1]   Retainer
20   SA8230-14230   [1]   Spring
21   SA8230-26350   [12]   Rod
22   SA8230-14250   [1]   Spacer
23   SA8230-14220   [2]   Spacer
24   SA8230-13950   [1]   Plate
25   SA8230-14190   [1]   Plate
26   SA8230-13740   [1]   Valve plate
27   SA8230-13590   [1]   Casing
28   SA8230-14210   [1]   Plate
29   SA8230-14160   [2]   Control plunger
30   SA8230-14150   [2]   Spring
31   SA8230-25820   [4]   Bolt
32   SA8230-25750   [1]   Ring
33   SA8230-25730   [1]   Ring
34   SA8230-26520   [1]   Roller bearing
35   SA8230-26600   [1]   Roller bearing
36   SA8230-25680   [2]   Plug
37   VOE14552321   [1]   O-ring
38   VOE983526   [2]   O-ring
39   SA8230-32140   [1]   Seal
40   SA8230-13870   [1]   Piston
41   VOE14693875   [1]   O-ring
42   SA8230-25540   [2]   O-ring
43   SA8230-14200   [24]   Spring brake
44   SA8230-13960   [3]   Friction plate
45   SA8230-13970   [4]   Separating plate
46   SA8230-26920   [3]   Plastic plug
47   SA8230-26930   [1]   Plug
48   SA8240-03280   [1]   Plug
49   VOE14511642   [1]   Valve
  VOE14562621   [2]   Plug
  VOE983493   [2]   O-ring
  VOE983503   [1]   O-ring
50   SA8230-36550   [2]   Relief valve
51   VOE990582   [1]   O-ring
100   SA8230-13430   [1]   Sealing Kit
