VOLVO EC460 EXCAVATOR SA1142-06230 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

VOLVO EC460 EXCAVATOR SA1142-06230 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
SA1142-06230 EC460
Pos. Part No Qty Parts name Comments
1   SA1142-06230   [1]   Pump
2   SA9016-12013   [4]   Bolt
Pos. Part No Qty Parts name Comments
  SA8230-35720   [1]   Regulator   FRONT
  SA8230-35730       Regulator   REAR
1   SA8240-03580   [4]   Bolt   M8 X L50
2   SA8230-25880   [0000]   Hex. socket screw   M6 X L60
3   SA8230-25910   [2]   Hex. socket screw
4   SA8230-25920   [2]   Bolt
5   SA8230-25860   [2]   Bolt
6   SA8230-25850   [6]   Bolt
7   VOE14883837   [1]   Plug
8   VOE14560637   [6]   Plug
9   SA8230-09920   [2]   Seat
10   SA8230-09930   [2]   Stop
11   SA9676-73200   [2]   Ball
12   SA14502326   [1]   Casing
13   SA14502328   [1]   Lever
14   SA8230-09440   [1]   Lever
15   SA8230-09450   [1]   Lever
16   SA8230-09460   [1]   Plug
17   SA8230-09470   [1]   Plug
18   SA14500061   [1]   Piston
19   SA14500060   [1]   Case
20   SA8230-09500   [1]   Rod
21   SA8230-09510   [1]   Seat
22   SA14500010   [1]   Spring
23   SA14502329   [1]   Spring
24   SA8230-09530   [1]   Stem
25   SA8230-09540   [1]   Screw
26   SA8230-09240   [1]   Cover
27   SA8230-09550   [1]   Lock nut
28   SA8230-09830   [1]   Sleeve
29   SA8230-09340   [1]   Cover
30   SA8230-09560   [1]   Piston
31   SA8230-09570   [1]   Seat
32   SA14500059   [1]   Ring
33   SA8230-09770   [1]   Spring
34   SA8230-09330   [1]   Sleeve
35   SA14502330   [1]   Slide
36   SA8230-09600   [1]   Seat
37   SA14502331   [1]   Spring
38   SA8230-09610   [1]   Spring
39   SA14502332   [0000]   Cover
40   SA14502333   [1]   Plate
41   SA14502335   [1]   Casing
42   VOE990637   [1]   O-ring
43   VOE983493   [3]   O-ring
44   VOE983495   [8]   O-ring
45   VOE983497   [1]   O-ring
46   VOE990557   [1]   O-ring
47   VOE983511   [1]   O-ring
48   VOE983507   [2]   O-ring
49   VOE983509   [1]   O-ring
50   VOE990581   [1]   O-ring
51   VOE983503   [1]   O-ring
52   VOE983502   [7]   O-ring
53   VOE983525   [1]   O-ring
54   VOE990583   [1]   O-ring
55   SA9113-10800   [2]   Hexagon nut
56   SA8240-03680   [1]   Snap ring
57   SA8230-26960   [1]   Ring
58   SA8230-25700   [2]   Ring
59   SA14500006   [1]   Pin
60   SA8230-26360   [4]   Pin
61   SA8230-09750   [1]   Pin
62   SA14500005   [1]   Pin
63   SA8230-26440   [1]   Pin
64   SA8240-04510   [1]   Screw
65   SA8230-09720   [1]   Screw
100   VOE14502342   [1]   Sealing Kit   KIT
  SA8230-08830   [1]   Gear Pump
Pos. Part No Qty Parts name Comments
  SA1142-06230   [1]   Pump
1   SA7223-00140   [2]   Piston
2   SA14502322   [9]   Piston
3   SA14502323   [9]   Seat
4   SA8230-09880   [1]   Cylinder
5   SA14502321   [1]   Block
6   SA14502324   [1]   Plate
7   SA8230-09890   [1]   Cylinder
8   SA14502321   [1]   Block
9   SA14502325   [1]   Plate
10   VOE14502011   [2]   Plate
11   SA7223-00220   [1]   Plate
12   SA7223-00240   [1]   Bushing
13   SA8230-32080   [1]   Valve
14   SA8230-09110   [1]   Shaft
15   SA8230-09010   [1]   Shaft
16   SA8230-09360   [1]   Connecting rod
17   SA8230-26640   [2]   Roller Bearing
18   SA8230-26710   [2]   Needle bearing
19   SA8230-08850   [3]   Spacer
20   SA8230-09090   [1]   Hydraulic unit
21   SA7242-10210   [2]   Plate
22   SA8230-10330   [2]   Bushing   SER NO 3001-3174
  VOE14510070   [2]   Bushing   SER NO 3175-
23   SA8230-09840   [18]   Spring
24   SA8230-09850   [2]   Spacer   SER NO 3001-3174
25   SA7223-00210   [2]   Plate
26   SA8230-08960   [2]   Support
27   SA8230-35460   [1]   Cover
28   SA8230-32160   [2]   Body
29   SA8230-08990   [1]   Cover
30   VOE14622760   [1]   Cover
31   SA8230-35490   [4]   Bolt
32   SA8230-09900   [4]   Hex. socket screw
33   VOE13967630   [4]   Allen Hd Screw
34   VOE14883837   [4]   Plug
35   SA9415-11051   [4]   Plug
36   VOE14560637   [32]   Plug   NPTF1/16
37   SA8230-27740   [5]   Plug   PT1/8
38   SA8230-09780   [2]   Pin
39   SA7223-00400   [1]   Pin
40   SA7223-00570   [1]   Pin
41   SA8230-35450   [1]   Piston
42   SA8230-35480   [2]   Stop
43   SA8230-35470   [2]   Stop
44   SA7223-00590   [2]   O-ring
45   VOE990588   [1]   O-ring
46   VOE990597   [1]   O-ring
47   SA8230-26210   [2]   O-ring
48   SA7223-00600   [3]   O-ring
49   VOE983495   [15]   O-ring
50   VOE983502   [10]   O-ring
51   VOE983524   [4]   O-ring
52   SA7223-00700   [2]   O-ring
53   SA7223-00710   [1]   Seal
54   SA8230-26840   [2]   Ring
55   SA8230-26830   [2]   Ring
56   SA9111-12000   [4]   Nut
57   VOE914470   [2]   Snap ring
58   SA7242-10560   [2]   Pin
59   SA7223-00660   [5]   Spring pin
60   SA8230-25460   [2]   Eye Bolt
61   SA7223-00670   [2]   Set screw
62   SA7223-00680   [2]   Set screw
100   VOE14502342   [1]   Sealing Kit   KIT
