VOLVO EC460 EC460B EC480D FB2800C FBR2800C EXCAVATOR VOE14569653 TRAVEL MOTOR ROTARY GROUP

VOLVO EC460 EC460B EC480D FB2800C FBR2800C EXCAVATOR VOE14569653 TRAVEL MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
  VOE14569653 EC460 EC460B EC480D FB2800C FBR2800C
Pos. Part No Qty Parts name Comments
1   VOE14569653   [2]   Travel motor
2   SA1143-01100   [2]   Travel Gearbox
3   SA9011-22017   [48]   Bolt
4   VOE60110287   [48]   Washer
Pos. Part No Qty Parts name Comments
  VOE14569653   [1]   Travel motor
1   VOE15122586   [1]   Rotator
2   SA8230-29690   [1]   Rotator
3   SA8230-29560   [1]   Cylinder
4   SA8230-30300   [1]   Lens
5   SA8230-30170   [1]   Pin
6   VOE14502604   [7]   Piston
7   SA8230-29550   [1]   Piston
8   SA8230-29970   [2]   Ring
9   SA8230-02570   [1]   Shim
  SA8230-34880   [1]   Shim
  SA8230-34890   [1]   Shim
  SA8230-34900   [1]   Shim
  SA8230-34910   [1]   Shim
  SA8230-34920   [1]   Shim
10   SA8230-30180   [1]   Spring
11   VOE15094944   [1]   Plate
12   SA8230-29920   [14]   Screw
13   SA8230-30270   [1]   Shaft
14   SA8230-29800   [1]   Shim
  SA8230-29850   [1]   Shim
  SA8230-29860   [1]   Shim
  SA8230-29870   [1]   Shim
  SA8230-29880   [1]   Shim
15   SA8230-29750   [1]   Plate
  SA8230-30190   [1]   Plate
  SA8230-30200   [1]   Plate
  SA8230-30210   [1]   Plate
  SA8230-30220   [1]   Plate
  SA8230-30230   [1]   Plate
  SA8230-30240   [1]   Plate
  SA8230-30250   [1]   Plate
  SA8230-30260   [1]   Plate
16   SA8230-29150   [1]   Retaining ring
17   SA8230-29400   [1]   Roller bearing
18   SA8230-29410   [1]   Roller bearing
18   VOE14714682   [1]   Roller bearing
19   SA8230-34460   [1]   Control unit
20   SA8230-34740   [1]   Housing
21   SA8230-29180   [1]   Retaining ring
22   SA8230-02530   [1]   Seal
23   VOE15106575   [1]   Plate
24   VOE11705810   [1]   O-ring
25   SA8230-29450   [1]   Screw
26   VOE14525808   [1]   O-ring
27   SA8230-29650   [2]   Pin
28   VOE14211726   [2]   Lock nut
29   SA8230-34430   [1]   O-ring
Pos. Part No Qty Parts name Comments
  SA8230-34460   [1]   Control unit
1   SA8230-34480   [1]   Plate
2   SA8230-34720   [1]   Piston
3   SA8230-34730   [1]   Trunnion
4   SA8230-34930   [1]   Bushing
5   SA8230-34750   [1]   Piston
6   SA8230-30030   [1]   Spring
7   SA8230-34670   [1]   Screw
8   SA8230-14920   [1]   Screw
9   ZM2271600   [1]   Screw
10   SA8230-34700   [1]   Pin
11   SA8230-34410   [1]   Screw
12   SA8230-34870   [1]   Screw
13   SA8230-34860   [1]   Bushing
14   SA8230-34690   [1]   Spring
15   SA8230-34510   [4]   Screw
16   SA8230-34400   [1]   Valve
17   SA8230-34520   [4]   Screw
18   SA8230-34560   [2]   Pin
19   ZM2905553   [3]   Screw plug
20   VOE11702857   [5]   Plug
21   VOE11702858   [1]   O-ring
22   VOE11702859   [1]   O-ring
23   SA8230-29940   [5]   Pin
24   SA8230-34530   [1]   Ball
25   SA8230-34620   [1]   Screw
26   ZM2161760   [1]   Plug
27   SA8230-34610   [1]   Screw
28   SA8230-34630   [1]   Pin
29   VOE14211724   [1]   Nut
30   SA8230-34500   [2]   Valve
31   SA8230-34470   [1]   Valve
32   SA8230-34450   [1]   Valve
