VOLVO EC380E EC380D EC480D EC480E EC480EHR EXCAVATOR VOE14593321 HEAVY TRAVEL MOTOR ROTARY GROUP

VOLVO EC380E EC380D EC480D EC480E EC480EHR EXCAVATOR VOE14593321 HEAVY TRAVEL MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
VOE14593321
EC380E EC380D EC480D EC480E EC480EHR
Pos. Part No Qty Parts name Comments
1   VOE14632579   [2]   Drive unit
2   VOE14593321   [1]   Travel motor
3   VOE14631200   [1]   Travel gearbox
4   VOE60110287   [48]   Washer
5   VOE997476   [48]   Hexagon screw
Parts on group Travel motor:
Pos. Part No Qty Parts name Comments
  VOE14593321   [1]   Travel motor
1   VOE14567691   [3]   Plug
2   VOE14736210   [1]   Housing
3   SA8230-15150   [1]   Spring
4   VOE14620988   [1]   Piston
5   VOE14569271   [2]   Pivot
6   VOE14622990   [1]   Ring
7   VOE14622989   [1]   Roller bearing
8   VOE14569276   [1]   Shaft
9   VOE14622991   [1]   Ring
10   VOE14736073   [1]   Plate
11 VOE14622048   [1]   Cylinder block
12   VOE14736211   [9]   Piston
13   VOE14736359   [1]   Plate
14   VOE14736360   [1]   Bushing
15   VOE14620989   [9]   Spring
16   VOE14736074   [4]   Friction plate
17   VOE14736361   [4]   Plate
18   VOE14736362   [1]   Piston
19   VOE14736077   [1]   Screw
20   VOE14736078   [1]   Flange
21   VOE14622050   [1]   Needle bearing
22   VOE14567682   [2]   Plug
23   VOE14622052   [2]   Ball
24   VOE14685200   [2]   Plug
25   VOE14567683   [1]   Plug
26   VOE14622054   [1]   Spool
27   VOE14573791   [1]   Spring
28   VOE14736079   [8]   Bolt
29   SA8230-21660   [14]   Spring
30   VOE14736080   [2]   Relief valve
31   VOE14622051   [1]   Valve
32   VOE14736081   [1]   Sealing kit
33   VOE14622061   [1]   Plug
