VOLVO EC380D EXCAVATOR Travel gearbox

VOLVO EC380D EXCAVATOR Travel gearbox

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
EC380D Travel gearbox S/N 21/23/231/26 270001-, 280001- NoneNone 8289146, 8289148, 8289147 Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14566401   [1]   Transfer gearbox
1   VOE14566402   [1]   Housing
2   VOE14566409   [1]   Gear
3   SA7117-38230   [2]   Bearing
4   VOE14566404   [1]   Shim
4   VOE14566405   [1]   Shim
4   VOE14566406   [1]   Shim
4   VOE14566407   [1]   Shim
4   VOE14566408   [1]   Shim
5   VOE14566403   [1]   Retainer
6   VOE14566410   [1]   Planet carrier
7       [1]   Carrier
8   VOE14566415   [4]   Pin
9   VOE14566413   [4]   Planetary gear
10   VOE14566414   [8]   Washer
11   SA9325-06012   [4]   Spring pin
12   SA8230-21020   [1]   Thrust ring
13   VOE14566412   [4]   Needle bearing
14   VOE983919   [20]   Hex. socket screw
15   VOE14566416   [1]   Gear
16   VOE14566418   [1]   Planet carrier
17   VOE14566423   [3]   Pin
18       [1]   Carrier
19   VOE14566421   [3]   Planetary gear
20   VOE14566422   [6]   Washer
21   SA9325-06012   [3]   Spring pin
22   VOE14566420   [3]   Needle bearing
23   VOE14566433   [1]   Thrust washer
24   VOE14566424   [1]   Gear
25   VOE14566425   [1]   Planet carrier
26       [1]   Carrier
27   VOE14566428   [3]   Planetary gear
28   VOE14566429   [6]   Washer
29   VOE14566430   [3]   Pin
30   SA9325-06012   [3]   Spring pin
31   VOE14566427   [3]   Needle bearing
32   VOE14569232   [1]   Ring
33   VOE14566417   [1]   Ring
34   VOE14566431   [1]   Gear
35   VOE914467   [1]   Retaining ring
36   VOE14566432   [1]   Cover
37   VOE60110006   [18]   Hexagon screw
38   SA9213-20000   [18]   Spring washer
39   VOE14883847   [2]   Plug
40   VOE990557   [2]   O-ring
41   VOE9324-21617   [4]   Pin
42   VOE14667679   [1]   Seal
