VOLVO EC380D EC380DHR EC380E EC380EHR EXCAVATOR VOE14622768 VOE14645001 VOE14645003 VOE14653149 VOE14664496 HEAVY SWING MOTOR ROTARY GROUP AND SPARE PARTS

Name: VOLVO EC380D EC380DHR EC380E EC380EHR EXCAVATOR VOE14622768 VOE14645001 VOE14645003 VOE14653149 VOE14664496 HEAVY SWING MOTOR ROTARY GROUP AND SPARE PARTS
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

VOLVO EC380D EC380DHR EC380E EC380EHR EXCAVATOR VOE14622768 VOE14645001 VOE14645003 VOE14653149 VOE14664496 HEAVY SWING MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

VOE14622768 VOE14645001 VOE14645003 VOE14653149 VOE14664496 EC380D EC380DHR EC380E EC380EHR

Pos.	Part No	Qty	Parts name	Comments
1	VOE14666141	[1]	Drive unit
1	VOE14622767		Drive unit
1	VOE14645000		Drive unit
1	VOE14680014		Drive unit
2	VOE14622768	[1]	Swing motor	S/N -210565, -230290, -270500, -280149
2	VOE14622768		Swing motor	S/N -210610
2	VOE14645003	[1]	Swing motor	S/N 210566-210684 230291-230464
2	VOE14645003		Swing motor	S/N 210611-210684 270001-270596
2	VOE14664496	[1]	Swing motor	S/N 230465-, 270597-, 280167-
2	VOE14645001		Swing motor
2	VOE14653149		Swing motor
3	VOE14622901	[1]	Swing gearbox
3	VOE14643287		Reduction gear
3	VOE14680015		Swing gearbox
4	VOE14596633	[1]	Gauge
5	VOE14596632	[1]	Pipe
6	VOE14531024	[1]	Pin
7	VOE60110301	[12]	Washer
8	VOE60110035	[11]	Hexagon screw
9	VOE984365	[1]	Hex. socket screw
10	VOE14529015	[1]	Valve
11	SA9411-92830	[2]	Elbow nipple
Parts on group Swing motor:

Pos.	Part No	Qty	Parts name	Comments
	VOE14622768	[1]	Swing motor
1	SA8230-00260	[1]	O-ring
2	VOE14685908	[2]	O-ring
3	VOE14650657	[4]	Seal
4	VOE14533606	[2]	O-ring
5	SA9324-21317	[1]	Pin
6	VOE14880821	[2]	Back-up ring
7	VOE14533613	[2]	O-ring
8	VOE14508590	[2]	Valve
Parts on group Swing motor:

Pos.	Part No	Qty	Parts name	Comments
	VOE14645001	[1]	Swing motor
	VOE14664496		Swing motor
1	SA8230-01090	[1]	Snap ring
2	SA8230-04460	[1]	Ring
3	SA8230-00910	[1]	Sealing ring
3			Seal
4	SA7177-03140	[1]	Roller bearing	S/N -210565/-270500 S/N -280149/-230290
4	VOE14626954	[1]	Roller bearing	S/N 210566-/270501- S/N 280150-/230291-
5		[1]	Housing
6	SA8230-04390	[1]	Plate
6			Plate
7	SA8230-04400	[1]	Plate
8	SA8230-04300	[1]	Spring
9	SA8230-04060	[1]	Cylinder
10	VOE14512780	[1]	Piston	9pcs
11	SA8230-22940	[4]	Friction plate
12	SA8230-22950	[4]	Plate
13	SA8230-04090	[1]	Piston
14	SA8230-00260	[1]	O-ring
14	SA8230-00260		O-ring
15	SA8230-00270	[2]	O-ring
15	VOE14685908		O-ring
16	SA8230-04270	[19]	Spring
17	VOE14650657	[4]	Seal
17			Seal ring
17	VOE14650657		Seal
18	SA8230-04310	[4]	Spring
19	SA8230-04350	[4]	Bushing
20	VOE14552099	[2]	Cap
20	SA7273-10751		Cap
21	VOE993320	[2]	O-ring	S/N -210565/-270500 S/N -280149/-230290
21	VOE983502	[2]	O-ring	S/N 210566-/270501- S/N 280150-/230291-
21			O-ring
22	SA8230-00630	[1]	Bolt
23	SA8230-04120	[2]	Piston
24		[1]	Cover
25	SA8230-00560	[2]	Pin
26	SA9324-21317	[1]	Pin
26			Pin
27	VOE14602310	[1]	Plate
28	SA8230-00840	[1]	Needle bearing
29	SA8230-01100	[1]	Snap ring
30	VOE14552450	[1]	Cap
30	SA7273-10760		Plug
31	VOE993322	[1]	O-ring	S/N -210565/-270500 S/N -280149/-230290
31	VOE990557	[1]	O-ring	S/N 210566-/270501- S/N 280150-/230291-
31	VOE14533609		O-ring
32	VOE14602309	[2]	Relief valve
32			Relief valve
33	VOE983529	[2]	O-ring
33			O-ring
34	VOE984135	[7]	Hex. socket screw
35	SA8230-11610	[2]	Cap
36	VOE14596241	[2]	Spring
37	VOE14880821	[2]	Back-up ring
37			Ring
38	VOE983525	[2]	O-ring
38			O-ring
39	SA8230-11110	[2]	Non-return valve
40			Valve
40	VOE14508590	[2]	Valve
41	VOE983503	[1]	O-ring
42	VOE14625246	[1]	Ring
43	VOE990557	[1]	O-ring
44	SA8230-00610	[3]	Bolt
44			Bolt
45	SA8230-00160	[1]	O-ring
46	SA8230-00190	[2]	O-ring
47	SA8230-04180	[1]	Valve
47			Valve
100	VOE14602311	[1]	Seal	S/N -210565/-270500 S/N -280149/-230290
200	VOE14512788	[1]	Sealing kit	S/N 210566-/270501- S/N 280150-/230291-
VOE14653149

Pos.	Part No	Qty	Parts name	Comments
1	VOE14684591	[1]	Drive unit
2	VOE14637253	[1]	Swing gearbox
3	VOE14653149	[1]	Swing motor
4	VOE914472	[1]	Snap ring
5	VOE997531	[4]	Hex. socket screw
6	VOE14596632	[1]	Pipe
7	VOE14596633	[1]	Gauge
8	VOE14531024	[1]	Pin
9	VOE60110301	[12]	Washer
10	VOE60110035	[11]	Hexagon screw
11	VOE997910	[1]	Hex. socket screw
