VOLVO EC360C EXCAVATOR Travel motor None NoneNone 8280846,8280847,8281897SN 110532 PARTS

VOLVO EC360C EXCAVATOR Travel motor None NoneNone 8280846,8280847,8281897SN 110532 PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Pos. Part No Qty Parts name Comments
  VOE14551802   [1]   Travel motor
1   VOE14565334   [1]   Casing
2   VOE14565337   [1]   Rod
3   VOE14565336   [1]   Pin
4   VOE983507   [1]   O-ring
5   VOE983501   [1]   O-ring
6   VOE14528296   [1]   Screw
7   VOE997410   [1]   Hexagon nut
8   VOE14551525   [1]   Pin
9   VOE990585   [2]   O-ring
10   SA7242-10540   [2]   Cover
11   SA7242-10750   [1]   Screw
12   VOE983497   [1]   O-ring
13   SA9415-31021   [7]   Plug
14   VOE993320   [7]   O-ring
15   SA7242-11580   [2]   Relief valve
16   SA9016-22019   [2]   Hex. socket screw
17   VOE14560637   [9]   Plug
18   SA9016-11209   [8]   Hex. socket screw
19   SA9415-31041   [2]   Plug
20   VOE993322   [2]   O-ring
21   VOE984229   [4]   Hex. socket screw
22   SA7242-10710   [2]   Clamping plate
23   SA7242-10720   [2]   Guard
24   VOE14880998   [2]   Ball
25       [1]   Nameplate
26   SA1010-11360   [2]   Screw
27   SA7242-10520   [2]   Washer
28   SA7242-10530   [2]   Spring
29   SA7242-11560   [1]   Spring
30   VOE14507000   [1]   Spacer
31   SA7242-11290   [1]   Plug
32   VOE983509   [1]   O-ring
33   VOE14509997   [1]   Spool
34   VOE14506994   [1]   Spring
35   VOE14506995   [1]   Plug
36   VOE983505   [1]   O-ring
37   VOE14880996   [2]   Ball
38   VOE14565331   [1]   Shaft
39   VOE14640025   [1]   Roller bearing
40   VOE14506955   [1]   Bearing
41   VOE914472   [1]   Snap ring
42   VOE14552647   [1]   Casing
43   SA7242-10590   [1]   Seal
44   SA9541-02090   [1]   Retaining ring
45   VOE14506958   [2]   Pivot
46   VOE14506959   [1]   Piston
47   VOE14551526   [5]   Pin
48   VOE14506982   [3]   Plate
49   VOE14506984   [2]   Plate
50   VOE14565332   [1]   Piston
51   VOE960262   [1]   O-ring
52   VOE990849   [1]   O-ring
53   VOE14568004   [10]   Spring
54   VOE14508608   [1]   Plate
55   VOE14552645   [1]   Cylinder block
56   VOE14506967   [9]   Spring
57   VOE14506968   [1]   Spacer
58   VOE14506970   [1]   Guide
59   VOE14506972   [1]   Plate
60   VOE14506977   [9]   Pad
61   VOE14551797   [9]   Piston
62   VOE14506978   [1]   Plate
100   VOE14596398   [1]   Seal
