VOLVO EC360C EXCAVATOR Travel motor None NoneNone 8280846, 8280847, 8281897SN -110531 PARTS

VOLVO EC360C EXCAVATOR Travel motor None NoneNone 8280846, 8280847, 8281897SN -110531 PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
VOE14551150 VOE14566400 DRIVE UNIT
VOE14528281 VOE14551802 TRAVEL MOTOR
EC290B EC290C EC290C EC330B EC330C EC360B EC360C EC360CHR EC380DHR FC3329C
Pos. Part No Qty Parts name Comments
1   VOE14551150   [2]   Drive unit   S/N -110531
  VOE14566400   [2]   Drive unit   S/N 110532-
2   VOE14528281   [1]   Travel motor   S/N -110531
  [1]   Travel motor   S/N 110532-
3   VOE14551151   [1]   Gearbox   S/N -110531
  VOE14566401   [1]   Transfer gearbox   S/N 110532-
4   VOE997475   [44]   Hexagon screw
5   VOE60110287   [44]   Washer
6   VOE997474   [8]   Hexagon screw
Parts on group Travel motor:
Pos. Part No Qty Parts name Comments
  VOE14528281   [1]   Travel motor
1   VOE14506950   [1]   Spool
2   VOE14506954   [1]   Shaft
3   VOE14640025   [1]   Roller bearing
4   VOE14506955   [1]   Bearing
5   VOE914472   [1]   Snap ring
6   VOE14528283   [1]   Casing
7   SA7242-10590   [1]   Seal
8   SA8320-01810   [1]   Retaining ring
9   VOE14506958   [2]   Pivot
10   VOE14506959   [1]   Piston
11   VOE14508608   [1]   Plate
12   VOE14506974   [9]   Piston
13   VOE14506968   [1]   Spacer
14   VOE14506970   [1]   Guide
15   VOE14506972   [1]   Plate
16   VOE14506980   [1]   Pin
17   VOE14506982   [2]   Plate
18   VOE14506984   [1]   Plate
19   VOE14506986   [1]   Piston
20   VOE14529784   [1]   O-ring
21   VOE990849   [2]   O-ring
22   VOE14565167   [10]   Spring
23   VOE14883837   [7]   Plug
24   VOE983502   [7]   O-ring
25   VOE14552644   [1]   Cylinder
26   VOE983496   [2]   O-ring
27   VOE983507   [2]   O-ring
28   VOE14506993   [1]   Spool
29   VOE14506994   [1]   Spring
30   VOE14506995   [1]   Plug
31   VOE983505   [1]   O-ring
32   SA7242-10680   [1]   Piston rod
33   VOE983501   [1]   O-ring
34   VOE14528296   [1]   Screw
35   VOE997410   [1]   Hexagon nut
36   VOE14507000   [1]   Spacer
37   SA7242-11290   [1]   Plug
38   VOE983509   [1]   O-ring
39   SA7242-10560   [1]   Pin
40   SA7242-10520   [2]   Washer
41   SA7242-10530   [2]   Spring
42   VOE990585   [2]   O-ring
43   SA7242-10540   [2]   Cover
44   SA9016-11209   [8]   Hex. socket screw
45   SA9415-11041   [2]   Plug
46   VOE990557   [2]   O-ring
47   SA7242-11580   [2]   Relief valve
48   SA9016-12010   [4]   Hex. socket screw
49   SA9016-22019   [2]   Hex. socket screw
50   SA7242-10710   [2]   Clamping plate
51   VOE14880998   [2]   Ball
52   SA7242-10720   [2]   Guard
53   VOE14560637   [9]   Plug
54   SA7242-11560   [1]   Spring
55   VOE14506967   [9]   Spring
56   VOE14551526   [5]   Pin
57   VOE14509997   [1]   Spool
58   VOE14529840   [1]   Casing
59   SA7242-10750   [1]   Screw
100   VOE14513325   [1]   Sealing Kit
