VOLVO EC360C EXCAVATOR Travel gearbox 8280846, 8280847, 8281897SN -110531 `

VOLVO EC360C EXCAVATOR Travel gearbox 8280846, 8280847, 8281897SN -110531 `

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
EC360C Travel gearbox None NoneNone 8280846, 8280847, 8281897:S/N -110531 Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14551151   [1]   Gearbox
1   VOE14522996   [1]   Housing
2   SA7117-38230   [2]   Bearing
3   VOE14579901   [1]   Seal
4   VOE14528319   [1]   Nut
5   SA7117-38271   [4]   Planet gear
6   SA7117-38520   [4]   Needle bearing
7   SA7117-38301   [4]   Pin
8   VOE14522997   [1]   Gear
9   SA9016-21620   [24]   Hex. socket screw
10   SA1036-00290   [1]   Thrust ring
11   VOE14551153   [1]   Planet carrier
12   VOE14556491   [6]   Washer
13   SA7117-38320   [1]   Planet carrier
14   SA7117-38330   [1]   Gear
15   SA7117-38340   [1]   Ring
16   SA7117-38350   [3]   Planetary Gear
17   SA7117-38360   [3]   Needle bearing
18   SA7117-38380   [3]   Pin
19   SA9325-06012   [3]   Spring pin
20   VOE14551152   [1]   Planet gear
  VOE14515055   [1]   Carrier
21   SA7117-38180   [3]   Pin
22   SA7117-38400   [1]   Gear
23   SA7117-38410   [1]   Ring
24   VOE14556490   [3]   Washer
25   SA7117-38420   [3]   Needle Bearing
26   VOE14556489   [3]   Washer
27   VOE13914468   [3]   Snap ring
28   SA9325-06012   [3]   Spring pin
29   VOE14513559   [3]   Planetary Gear
30   VOE14601855   [1]   Cover
31   VOE983252   [16]   Hexagon screw
32   VOE14883848   [3]   Plug
33   SA7117-38460   [4]   Inner ring
34   VOE14546062   [8]   Washer
35   VOE14526459   [3]   Screw
36   VOE983524   [3]   O-ring
37   SA9325-06012   [4]   Spring pin
38   VOE14515056   [1]   Sun gear
39   VOE914467   [1]   Retaining ring
40   VOE955922   [16]   Spring washer
41   SA8230-21020   [1]   Thrust ring
