VOLVO EC360B Excavator Travel gearbox None 8277279 SN 10211

VOLVO EC360B Excavator Travel gearbox None 8277279 SN 10211

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
EC360B Travel gearbox None 8277279 S/N 10211--None NoneNone None Autodata Volvo online
Pos. Part No Qty Parts name Comments
      [1]   Travel Gearbox
1   VOE14516451   [1]   Housing   SER NO 10211-10545
  VOE14521859   [1]   Housing   SER NO 10546-10712
  VOE14522996   [1]   Housing   SER NO 10713-
2   SA7117-38230   [2]   Bearing
3   SA7117-38240   [1]   Seal   SER NO 10211-10712
  VOE14579901   [1]   Seal   SER NO 10713-
4   SA7117-38251   [1]   Nut   SER NO 10211-11044
  VOE14528319   [1]   Nut   SER NO 11045-
5   SA7117-38271   [4]   Planet gear
6   SA7117-38520   [4]   Needle bearing
7   SA7117-38301   [4]   Pin
8   VOE14516450   [1]   Gear   SER NO 10211-10712
  VOE14522997   [1]   Gear   SER NO 10713-
9   SA9016-21620   [24]   Hex. socket screw
10   SA1036-00290   [1]   Thrust ring
11   VOE14551153   [1]   Planet carrier
12   VOE14556491   [6]   Washer
13   SA7117-38320   [1]   Planet carrier
14   SA7117-38330   [1]   Gear
15   SA7117-38340   [1]   Ring
16   SA7117-38350   [3]   Planetary Gear
17   SA7117-38360   [3]   Needle bearing
18   SA7117-38380   [3]   Pin
19   SA9325-06012   [3]   Spring pin
20   VOE14551152   [1]   Planet gear
  VOE14515055   [1]   Carrier
21   SA7117-38180   [3]   Pin
22   SA7117-38400   [1]   Gear
23   SA7117-38410   [1]   Ring
24   VOE14556490   [3]   Washer
25   SA7117-38420   [3]   Needle Bearing
26   VOE14556489   [3]   Washer
27   VOE13914468   [3]   Snap ring
28   SA9325-06012   [3]   Spring pin
29   VOE14513559   [3]   Planetary Gear
30   VOE14517931   [1]   Cover   SER NO 10211-10712
  VOE14601855   [1]   Cover   SER NO 10713-
31   VOE967631   [16]   Hex. socket screw   SER NO 10211-10712
  VOE983252   [16]   Hexagon screw   SER NO 10713-
32   VOE14883848   [3]   Plug
33   SA7117-38460   [4]   Inner ring
34   SA7117-38470   [8]   Washer
35   SA9023-10803   [4]   Set screw   SER NO 10211-11044
  VOE14526459   [3]   Screw   SER NO 11045-
36   VOE983524   [3]   O-ring
37   SA9325-06012   [4]   Spring pin
38   VOE14515056   [1]   Sun gear
39   VOE914467   [1]   Retaining ring
40   VOE955922   [16]   Spring washer   SER NO 10713-
41   SA1036-00300   [1]   Ring
