VOLVO EC360B Excavator Travel gearbox None 8277279 SN -10210

VOLVO EC360B Excavator Travel gearbox None 8277279 SN -10210

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
EC360B Travel gearbox None 8277279 S/N -10210-None NoneNone None Autodata Volvo online
Pos. Part No Qty Parts name Comments
  SA7117-45060   [1]   Travel Gearbox
1   SA7117-00540   [1]   Housing
2   SA1036-00320   [2]   Absorbent
3   SA1036-00050   [1]   Gear
4   VOE947695   [20]   Hex. socket screw
5   SA1036-00330   [1]   Seal
6   SA1036-00390   [2]   Shim   T=0.8MM
  SA1036-00400   [2]   Shim   T=0.9MM
  SA1036-00410   [2]   Shim   T=1.0MM
  SA1036-00420   [2]   Shim   T=1.2MM
  SA1036-00430   [1]   Shim   T=1.5MM
  SA1036-00440   [1]   Shim   T=2.3MM
7   SA7117-00570   [1]   Retainer
8   VOE997446   [18]   Hexagon screw
9   SA1036-00290   [2]   Thrust ring
10   SA1036-00260   [1]   Sun gear
11   VOE14517932   [1]   Cover
12   SA1036-00450   [1]   Shim   T=0.5MM
  SA1036-00460   [1]   Shim   T=1.0MM
13   SA9016-21007   [20]   Hexagon screw
14   SA9023-11006   [2]   Set screw
15   VOE14883847   [3]   Plug
16   SA7117-00530   [1]   Planet carrier
17   SA7117-00560   [1]   Gear
18   SA1036-00220   [4]   Planetary Gear
19   SA1036-00240   [4]   Needle bearing
20   SA1036-00180   [8]   Washer
21   SA1036-00230   [4]   Pin
22   VOE13951991   [4]   Spring pin
23   SA7117-00520   [1]   Carrier
24   SA7117-00550   [1]   Carrier
25   SA1036-00310   [1]   Thrust ring
26   SA1036-00280   [1]   Sun gear
27   SA1036-00300   [1]   Ring
28   SA1036-00200   [1]   Ring
29   SA1036-00160   [3]   Planetary Gear
30   SA1036-00190   [3]   Needle bearing
31   SA1036-00180   [6]   Washer
32   SA1036-00170   [3]   Pin
33   SA9325-06012   [3]   Spring pin
34   SA7117-00510   [1]   Planet carrier
35   SA1036-00080   [1]   Planet carrier
36   SA1036-00100   [3]   Pin
37   SA9325-06012   [3]   Spring pin
38   SA1036-00270   [1]   Sun gear
39   SA1036-00140   [1]   Ring
40   SA1036-00090   [3]   Planetary Gear
41   SA1036-00130   [3]   Needle bearing
42   SA1036-00110   [3]   Washer
43   SA1036-00120   [3]   Thrust washer
44   VOE914472   [3]   Snap ring
45   VOE990557   [3]   O-ring
