VOLVO EC340D EC360C EC360CHR EC380D EC380DHR EXCAVATOR VOE14616199 VOE14638307 HEARVY MAIN PUMP ROTARY GROUP AND SPARE PARTS

VOLVO EC340D EC360C EC360CHR EC380D EC380DHR EXCAVATOR VOE14616199 VOE14638307 HEARVY MAIN PUMP ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
VOE14616199 VOE14638307
EC340D EC360C EC360CHR EC380D EC380DHR
Pos. Part No Qty Parts name Comments
1   VOE14616199   [1]   Pump
1   VOE14638307   [1]   Pump
  VOE14574270   [2]   Regulator kit
2   VOE984364   [4]   Hex. socket screw
3   VOE60110287   [4]   Washer
Parts on group Hydraulic pump:
Pos. Part No Qty Parts name Comments
  VOE14616199   [1]   Pump   S/N -210433, 210437- S/N -270135, -280074
1   VOE14601425   [2]   Piston
2   VOE14519957   [1]   Cover
3   VOE14511977   [1]   Shaft
4   VOE14563795   [1]   Cylinder
5   VOE14880555   [2]   Eye bolt
6   SA7223-00670   [2]   Set screw
7   VOE14563796   [1]   Cylinder
8   SA7223-00660   [4]   Spring pin
9   VOE14880069   [0003]   Plug
10   VOE14502011   [2]   Plate
11   SA7223-00210   [2]   Plate
12   VOE14520039   [1]   Shaft
13   VOE14572694   [1]   Shaft coupling
14   SA7241-00421   [2]   Roller bearing
15   VOE14511981   [2]   Bearing
16   VOE14550444   [3]   Spacer
17   SA7242-10210   [2]   Plate
18   VOE14510070   [2]   Bushing
19   SA7223-00180   [18]   Spring
20   SA7223-00260   [2]   Support
21   VOE14574286   [1]   Valve
22   VOE984473   [1]   O-ring
23   VOE14533606   [3]   O-ring
24   VOE14533608   [1]   O-ring
25   VOE14560637   [3]   Plug
26   SA9016-20612   [3]   Bolt
27   SA9415-31021   [1]   Plug
28   VOE14574269   [1]   Valve
29   VOE990738   [1]   O-ring
30   VOE990546   [1]   O-ring
31   VOE990547   [1]   O-ring
32   VOE14560637   [18]   Plug
33   VOE914470   [2]   Snap ring
34   VOE14551525   [2]   Pin
35   VOE14574287   [2]   Casing
36   VOE14506634   [2]   Pin
37   VOE14533604   [16]   O-ring
38   VOE14533606   [2]   O-ring
39   SA7223-00410   [2]   Piston
40   SA7223-00420   [2]   Stop
41   SA7223-00430   [2]   Stop
42   VOE14692341   [2]   Ring
43   SA7223-00650   [2]   Ring
44   SA7223-00690   [2]   O-ring
45   SA7223-00700   [2]   O-ring
46   VOE14560637   [12]   Plug
47   VOE14604844   [8]   Screw
48   VOE14549801   [2]   Non-return valve
49   VOE14550471   [1]   Seat
50   VOE14550472   [1]   Stopper
51   VOE14880998   [1]   Ball
52   VOE14549802   [2]   Non-return valve
53   VOE14550471   [1]   Seat
54   VOE14550473   [1]   Stopper
55   VOE14880998   [1]   Ball
56   VOE13967630   [8]   Allen Hd Screw
57   VOE14533617   [2]   O-ring
58   VOE14533034   [2]   O-ring
59   VOE14533035   [2]   O-ring
60   VOE984473   [2]   O-ring
61   VOE14574556   [3]   O-ring
62   VOE979022   [4]   Hexagon nut
63   VOE14552650   [1]   Cover
64   VOE14551796   [1]   Cover
65   VOE14600699   [1]   Seal
66   SA9415-31021   [2]   Plug
67   VOE14574267   [1]   Valve block
68   SA7223-00680   [2]   Set screw
  VOE14602457   [2]   Sealing kit
Parts on group Hydraulic pump:
Pos. Part No Qty Parts name Comments
  VOE14638307   [1]   Pump   S/N 210434-210436 S/N 270136-, 280075-
1   VOE14601425   [2]   Piston
2   VOE14519957   [1]   Cover
3   VOE14511977   [1]   Shaft
4   VOE14563795   [1]   Cylinder
5   VOE14880555   [2]   Eye bolt
6   SA7223-00670   [2]   Set screw
7   VOE14563796   [1]   Cylinder
8   SA7223-00660   [4]   Spring pin
9   VOE14880069   [0003]   Plug
10   VOE14502011   [2]   Plate
11   SA7223-00210   [2]   Plate
12   VOE14520039   [1]   Shaft
13   VOE14572694   [1]   Shaft coupling
14   SA7241-00421   [2]   Roller bearing
15   VOE14511981   [2]   Bearing
16   VOE14550444   [3]   Spacer
17   SA7242-10210   [2]   Plate
18   VOE14510070   [2]   Bushing
19   SA7223-00180   [18]   Spring
20   SA7223-00260   [2]   Support
21   VOE14574286   [1]   Valve
22   VOE984473   [1]   O-ring
23   VOE14533606   [3]   O-ring
24   VOE14533608   [1]   O-ring
25   VOE14560637   [3]   Plug
26   SA9016-20612   [3]   Bolt
27   SA9415-31021   [1]   Plug
28   VOE14574269   [1]   Valve
29   VOE990738   [1]   O-ring
30   VOE990546   [1]   O-ring
31   VOE990547   [1]   O-ring
32   VOE14560637   [18]   Plug
33   VOE914470   [2]   Snap ring
34   VOE14551525   [2]   Pin
35   VOE14574287   [2]   Casing
36   VOE14506634   [1]   Pin
37   VOE14533604   [8]   O-ring
38   VOE14533606   [1]   O-ring
39   SA7223-00410   [1]   Piston
40   SA7223-00420   [1]   Stop
41   SA7223-00430   [1]   Stop
42   VOE14692341   [1]   Ring
43   SA7223-00650   [1]   Ring
44   SA7223-00690   [1]   O-ring
45   SA7223-00700   [1]   O-ring
46   VOE14560637   [6]   Plug
47   VOE14604844   [8]   Screw
48   VOE14549801   [2]   Non-return valve
49   VOE14550471   [1]   Seat
50   VOE14550472   [1]   Stopper
51   VOE14880998   [1]   Ball
52   VOE14549802   [2]   Non-return valve
53   VOE14550471   [1]   Seat
54   VOE14550473   [1]   Stopper
55   VOE14880998   [1]   Ball
56   VOE13967630   [8]   Allen Hd Screw
57   VOE14533617   [2]   O-ring
58   VOE14533034   [2]   O-ring
59   VOE14533035   [2]   O-ring
60   VOE984473   [2]   O-ring
61   VOE14574556   [3]   O-ring
62   VOE979022   [4]   Hexagon nut
63   VOE14552650   [1]   Cover
64   VOE14551796   [1]   Cover
65   VOE14600699   [1]   Seal
66   SA9415-31021   [2]   Plug
67   VOE14574267   [1]   Valve block
68   SA7223-00680   [2]   Set screw
  VOE14602457   [1]   Sealing kit
Parts on group Regulator, hydraulic pump:
Pos. Part No Qty Parts name Comments
  VOE14574270   [1]   Regulator kit
Parts on group Pump gearbox with assembling parts:
Pos. Part No Qty Parts name Comments
1   VOE14591192   [1]   Flange
2   VOE14528378   [1]   Vibration damper
3   VOE997384   [12]   Washer
4   VOE978934   [12]   Hexagon screw
5   VOE983251   [8]   Hexagon screw
6   VOE992040   [8]   Plain washer
