VOLVO EC340D EC360C EC360CHR EC380D EC380DHR EXCAVATOR VOE14616199 VOE14638307 HEARVY MAIN PUMP PARTS

VOLVO EC340D EC360C EC360CHR EC380D EC380DHR EXCAVATOR VOE14616199 VOE14638307 HEARVY MAIN PUMP PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
VOE14616199 VOE14638307
EC340D EC360C EC360CHR EC380D EC380DHR
Pos. Part No Qty Parts name Comments
1   VOE14616199   [1]   Pump
1   VOE14638307   [1]   Pump
  VOE14574270   [2]   Regulator kit
2   VOE984364   [4]   Hex. socket screw
3   VOE60110287   [4]   Washer
Parts on group Hydraulic pump:
Pos. Part No Qty Parts name Comments
  VOE14616199   [1]   Pump   S/N -210433, 210437- S/N -270135, -280074
1   VOE14601425   [2]   Piston
2   VOE14519957   [1]   Cover
3   VOE14511977   [1]   Shaft
4   VOE14563795   [1]   Cylinder
5   VOE14880555   [2]   Eye bolt
6   SA7223-00670   [2]   Set screw
7   VOE14563796   [1]   Cylinder
8   SA7223-00660   [4]   Spring pin
9   VOE14880069   [0003]   Plug
10   VOE14502011   [2]   Plate
11   SA7223-00210   [2]   Plate
12   VOE14520039   [1]   Shaft
13   VOE14572694   [1]   Shaft coupling
14   SA7241-00421   [2]   Roller bearing
15   VOE14511981   [2]   Bearing
16   VOE14550444   [3]   Spacer
17   SA7242-10210   [2]   Plate
18   VOE14510070   [2]   Bushing
19   SA7223-00180   [18]   Spring
20   SA7223-00260   [2]   Support
21   VOE14574286   [1]   Valve
22   VOE984473   [1]   O-ring
23   VOE14533606   [3]   O-ring
24   VOE14533608   [1]   O-ring
25   VOE14560637   [3]   Plug
26   SA9016-20612   [3]   Bolt
27   SA9415-31021   [1]   Plug
28   VOE14574269   [1]   Valve
29   VOE990738   [1]   O-ring
30   VOE990546   [1]   O-ring
31   VOE990547   [1]   O-ring
32   VOE14560637   [18]   Plug
33   VOE914470   [2]   Snap ring
34   VOE14551525   [2]   Pin
35   VOE14574287   [2]   Casing
36   VOE14506634   [2]   Pin
37   VOE14533604   [16]   O-ring
38   VOE14533606   [2]   O-ring
39   SA7223-00410   [2]   Piston
40   SA7223-00420   [2]   Stop
41   SA7223-00430   [2]   Stop
42   VOE14692341   [2]   Ring
43   SA7223-00650   [2]   Ring
44   SA7223-00690   [2]   O-ring
45   SA7223-00700   [2]   O-ring
46   VOE14560637   [12]   Plug
47   VOE14604844   [8]   Screw
48   VOE14549801   [2]   Non-return valve
49   VOE14550471   [1]   Seat
50   VOE14550472   [1]   Stopper
51   VOE14880998   [1]   Ball
52   VOE14549802   [2]   Non-return valve
53   VOE14550471   [1]   Seat
54   VOE14550473   [1]   Stopper
55   VOE14880998   [1]   Ball
56   VOE13967630   [8]   Allen Hd Screw
57   VOE14533617   [2]   O-ring
58   VOE14533034   [2]   O-ring
59   VOE14533035   [2]   O-ring
60   VOE984473   [2]   O-ring
61   VOE14574556   [3]   O-ring
62   VOE979022   [4]   Hexagon nut
63   VOE14552650   [1]   Cover
64   VOE14551796   [1]   Cover
65   VOE14600699   [1]   Seal
66   SA9415-31021   [2]   Plug
67   VOE14574267   [1]   Valve block
68   SA7223-00680   [2]   Set screw
  VOE14602457   [2]   Sealing kit
Parts on group Hydraulic pump:
Pos. Part No Qty Parts name Comments
  VOE14638307   [1]   Pump   S/N 210434-210436 S/N 270136-, 280075-
1   VOE14601425   [2]   Piston
2   VOE14519957   [1]   Cover
3   VOE14511977   [1]   Shaft
4   VOE14563795   [1]   Cylinder
5   VOE14880555   [2]   Eye bolt
6   SA7223-00670   [2]   Set screw
7   VOE14563796   [1]   Cylinder
8   SA7223-00660   [4]   Spring pin
9   VOE14880069   [0003]   Plug
10   VOE14502011   [2]   Plate
11   SA7223-00210   [2]   Plate
12   VOE14520039   [1]   Shaft
13   VOE14572694   [1]   Shaft coupling
14   SA7241-00421   [2]   Roller bearing
15   VOE14511981   [2]   Bearing
16   VOE14550444   [3]   Spacer
17   SA7242-10210   [2]   Plate
18   VOE14510070   [2]   Bushing
19   SA7223-00180   [18]   Spring
20   SA7223-00260   [2]   Support
21   VOE14574286   [1]   Valve
22   VOE984473   [1]   O-ring
23   VOE14533606   [3]   O-ring
24   VOE14533608   [1]   O-ring
25   VOE14560637   [3]   Plug
26   SA9016-20612   [3]   Bolt
27   SA9415-31021   [1]   Plug
28   VOE14574269   [1]   Valve
29   VOE990738   [1]   O-ring
30   VOE990546   [1]   O-ring
31   VOE990547   [1]   O-ring
32   VOE14560637   [18]   Plug
33   VOE914470   [2]   Snap ring
34   VOE14551525   [2]   Pin
35   VOE14574287   [2]   Casing
36   VOE14506634   [1]   Pin
37   VOE14533604   [8]   O-ring
38   VOE14533606   [1]   O-ring
39   SA7223-00410   [1]   Piston
40   SA7223-00420   [1]   Stop
41   SA7223-00430   [1]   Stop
42   VOE14692341   [1]   Ring
43   SA7223-00650   [1]   Ring
44   SA7223-00690   [1]   O-ring
45   SA7223-00700   [1]   O-ring
46   VOE14560637   [6]   Plug
47   VOE14604844   [8]   Screw
48   VOE14549801   [2]   Non-return valve
49   VOE14550471   [1]   Seat
50   VOE14550472   [1]   Stopper
51   VOE14880998   [1]   Ball
52   VOE14549802   [2]   Non-return valve
53   VOE14550471   [1]   Seat
54   VOE14550473   [1]   Stopper
55   VOE14880998   [1]   Ball
56   VOE13967630   [8]   Allen Hd Screw
57   VOE14533617   [2]   O-ring
58   VOE14533034   [2]   O-ring
59   VOE14533035   [2]   O-ring
60   VOE984473   [2]   O-ring
61   VOE14574556   [3]   O-ring
62   VOE979022   [4]   Hexagon nut
63   VOE14552650   [1]   Cover
64   VOE14551796   [1]   Cover
65   VOE14600699   [1]   Seal
66   SA9415-31021   [2]   Plug
67   VOE14574267   [1]   Valve block
68   SA7223-00680   [2]   Set screw
  VOE14602457   [1]   Sealing kit
Parts on group Regulator, hydraulic pump:
Pos. Part No Qty Parts name Comments
  VOE14574270   [1]   Regulator kit
Parts on group Pump gearbox with assembling parts:
Pos. Part No Qty Parts name Comments
1   VOE14591192   [1]   Flange
2   VOE14528378   [1]   Vibration damper
3   VOE997384   [12]   Washer
4   VOE978934   [12]   Hexagon screw
5   VOE983251   [8]   Hexagon screw
6   VOE992040   [8]   Plain washer
