VOLVO EC330B EC360B EXCAVATOR VOE14509428 VOE14512786 SA8230-01090 HEAVY SWING MOTOR PARTS

VOLVO EC330B EC360B EXCAVATOR VOE14509428 VOE14512786 SA8230-01090 HEAVY SWING MOTOR PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
VOE14509428  VOE14512786  SA8230-01090 EC330B EC360B
Pos. Part No Qty Parts name Comments
1   VOE14509428   [1]   Swing motor
2   VOE14512786   [1]   Swing motor
3   VOE14512787   [1]   Reduction gear
4   VOE14531019   [1]   Washer
5   VOE14531018   [1]   Plate
6   VOE14531024   [1]   Pin
7   SA1055-00481   [1]   Pinion
8   VOE60110356   [2]   Hexagon screw
9   VOE991649   [11]   Hexagon screw
10   SA9016-12415   [1]   Hex. socket screw   SER NO 10001-10580
  VOE984365   [1]   Hex. socket screw   SER NO 10581-
11   VOE60110301   [12]   Washer
Parts on group Swing motor:
Pos. Part No Qty Parts name Comments
  VOE14512786   [1]   Swing motor
1   SA8230-01090   [1]   Snap ring
2   SA8230-04460   [1]   Ring
3   SA8230-00910   [1]   Sealing ring
4   SA7177-03140   [1]   Roller bearing
5   VOE14512779   [1]   Housing
6   SA8230-04390   [1]   Plate
7   SA8230-04400   [1]   Plate
8   SA8230-04300   [1]   Spring
9   SA8230-04060   [1]   Cylinder
10   VOE14512780   [1]   Piston   9pcs
11   SA8230-22940   [4]   Friction plate
12   SA8230-22950   [4]   Plate
13   SA8230-04090   [1]   Piston
14   SA8230-00260   [1]   O-ring
15   SA8230-00270   [2]   O-ring
16   SA8230-04270   [19]   Spring
17   SA8230-00900   [4]   Seal
18   SA8230-04310   [4]   Spring
19   SA8230-04350   [4]   Bushing
20   SA8230-01160   [2]   Cap
21   VOE983502   [2]   O-ring
22   SA8230-00630   [1]   Bolt
23   SA8230-04120   [2]   Piston
24   VOE14512781   [1]   Cover
25   SA8230-00560   [2]   Pin
26   VOE14508590   [2]   Valve
27   VOE14625246   [1]   Ring
28   VOE983503   [2]   O-ring
29   VOE990557   [3]   O-ring
30   SA8230-37030   [1]   Cap
31   VOE990557   [1]   O-ring
32   VOE14512782   [2]   Relief valve
33   VOE983529   [1]   O-ring
34   VOE984135   [7]   Hex. socket screw
35   SA8230-11610   [2]   Cap
36   VOE14596241   [2]   Spring
37   SA9566-10260   [2]   Back-up ring
38   VOE983525   [2]   O-ring
39   SA8230-11110   [2]   Non-return valve
40   SA9324-21317   [1]   Pin
41   SA8230-04020   [1]   Plate
42   SA8230-00840   [1]   Needle bearing
43   SA8230-01100   [1]   Snap ring
44   SA8230-00610   [3]   Bolt
45   SA8230-00160   [1]   O-ring
46   SA8230-00190   [2]   O-ring
47   SA8230-04220   [1]   Manifold
100   VOE14512788   [1]   Sealing kit
