VOLVO EC330B EC360B EXCAVATOR VOE14500380 VOE14512271 VOE14516492 VOE14516492 VOE14520050 HEAVY PUMP ROATRY GROUP AND SPARE PARTS

VOLVO EC330B EC360B EXCAVATOR VOE14500380 VOE14512271 VOE14516492 VOE14516492 VOE14520050 HEAVY PUMP ROATRY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
VOE14500380 VOE14512271
VOE14516492 VOE14516492
VOE14520050
EC330B EC360B
Pos. Part No Qty Parts name Comments
1   VOE14500380   [1]   Pump   SER NO 10001-10122
  VOE14516492   [1]   Pump   SER NO 10123-10240
  VOE14516492       Pump   SER NO 10241-
  VOE14512271       Pump   SER NO 10241-10828
  VOE14520050       Pump   SER NO 10829-
2   VOE14512928   [2]   Regulator   SER NO 10001-10122
  VOE14561183   [2]   Regulator kit   SER NO 10123-10240
  VOE14561183       Regulator kit   SER NO 10241-
  VOE14561183       Regulator kit   SER NO 10829-
3   SA8230-08830   [1]   Gear Pump   SER NO 10001-10122
  SA7220-00510   [1]   Gear pump   SER NO 10123-10240
  SA7220-00510       Gear pump   SER NO 10241-
4   VOE949566   [4]   Hex. socket screw   SER NO 10001-10054
  SA9016-12013   [4]   Bolt   SER NO 10055-10240
  SA9016-12013       Bolt   SER NO 10241-10580
  VOE984364       Hex. socket screw   SER NO 10581-
  VOE984364       Hex. socket screw   SER NO 10829-
5   VOE60110287   [4]   Washer   SER NO 10055-10240
  VOE60110287       Washer   SER NO 10241-
  VOE60110287       Washer   SER NO 10829-
Parts on group Hydraulic gear pump:
Pos. Part No Qty Parts name Comments
  VOE14505880   [1]   Gear Pump
  SA7210-00930       Gear pump
Parts on group Hydraulic gear pump:
Pos. Part No Qty Parts name Comments
  VOE14509153   [1]   Gear Pump   SER NO 10829-10911
  VOE14525545   [1]   Gear pump   SER NO 10912-
  VOE14520055       Pump   SER NO 10829-10911
  VOE14525548       Gear pump   SER NO 10912-
Parts on group Hydraulic pump:
Pos. Part No Qty Parts name Comments
  VOE14500380   [1]   Pump
1   SA7223-00140   [2]   Piston
2   VOE14512923   [9]   Piston
3   VOE14502323   [9]   Seat
4   SA8230-09880   [1]   Cylinder
5   VOE14502321   [1]   Block
6   VOE14502324   [1]   Plate
7   SA8230-09890   [1]   Cylinder
8   VOE14502321   [1]   Block
9   VOE14502325   [1]   Plate
10   VOE14502011   [2]   Plate
11   SA7223-00220   [1]   Plate
12   SA7223-00240   [1]   Bushing
13   VOE14512921   [1]   Gear
14   SA8230-26640   [2]   Roller Bearing
15   VOE14512922   [2]   Needle Bearing
16   SA7223-00060   [3]   Spacer
17   SA8230-09300   [2]   Plate
18   VOE14510070   [2]   Bushing
19   SA8230-09840   [18]   Spring
20   SA8230-08960   [2]   Support
21   SA7223-00210   [2]   Plate
22   SA8230-09020   [1]   Valve
23   VOE14512919   [1]   Shaft
24   VOE14512920   [1]   Shaft
25   SA8230-35460   [1]   Cover
26   SA8230-32160   [2]   Body
27   VOE14512925   [1]   Block
28   SA8230-09920   [4]   Seat
29   SA8230-09930   [2]   Stop
30   SA9676-73200   [4]   Ball
31   SA9415-11051   [4]   Plug
32   VOE14560637   [27]   Plug
33   SA8230-35490   [8]   Bolt
34   SA8230-35450   [2]   Piston
35   SA8230-35480   [2]   Stop
36   SA8230-35470   [2]   Stop
37   VOE14883837   [2]   Plug
38   SA8230-09780   [2]   Pin
39   SA7223-00400   [1]   Pin
40   SA7223-00570   [1]   Pin
41   VOE14512927   [1]   Power take-off
42   VOE990602   [1]   O-ring
43   SA8230-09910   [2]   Stopper
44   SA8230-30930   [2]   Screw
45   VOE13967630   [4]   Allen Hd Screw
46   SA7223-00690   [2]   O-ring
47   VOE990597   [2]   O-ring
48   SA7223-00590   [2]   O-ring
49   SA7223-00600   [2]   O-ring
50   VOE983495   [16]   O-ring
51   VOE983502   [6]   O-ring
52   VOE983524   [4]   O-ring
53   SA7223-00700   [2]   O-ring
54   SA7223-00710   [1]   Seal
55   SA8230-26840   [2]   Ring
56   SA8230-26830   [2]   Ring
57   SA9111-12000   [4]   Nut
58   VOE914470   [2]   Snap ring
59   SA7242-10560   [2]   Pin
60   SA7223-00660   [4]   Spring pin
61   SA8230-25460   [2]   Eye Bolt
62   SA7223-00670   [2]   Set screw
63   VOE14512926   [1]   Cover
64   SA8240-03470   [4]   Bolt
65   SA8230-27740   [12]   Plug
100   VOE14554798   [1]   Seal
Parts on group Hydraulic pump:
Pos. Part No Qty Parts name Comments
  VOE14516492   [1]   Pump
  VOE14512271       Pump
  VOE14520050       Pump
1   SA7223-00140   [2]   Piston
2   SA7223-00150   [9]   Piston
3   SA7223-00160   [9]   Pad
4   VOE14563795   [1]   Cylinder
5   SA7223-00090   [1]   Block
6   SA7223-00360   [1]   Plate
7   SA7223-00790   [1]   Cylinder
8   SA7223-00090   [1]   Block
9   SA7223-00370   [1]   Plate
10   VOE14502011   [2]   Plate
11   SA7223-00220   [1]   Plate
12   SA7223-00240   [1]   Bushing
13   VOE14511979   [1]   Gear
14   SA7241-00421   [2]   Roller bearing
15   VOE14511981   [2]   Bearing
16   SA7223-00060   [3]   Spacer
17   SA7242-10210   [2]   Plate
18   VOE14510070   [2]   Bushing
19   SA7223-00180   [18]   Spring
20   SA7223-00260   [2]   Support
21   SA7223-00210   [2]   Plate
22   VOE14532653   [1]   Valve   SER NO 10001-11490
  VOE14532653       Valve   SER NO 11491-
23   VOE14533608   [1]   O-ring
24   VOE14533606   [4]   O-ring
25   VOE14560637   [3]   Plug
26   VOE14883837   [1]   Plug
27   SA9016-20612   [3]   Bolt
28   SA8230-32080   [1]   Valve
29   VOE14535454   [1]   O-ring
30   VOE14535455   [1]   O-ring
31   VOE14535456   [1]   O-ring
32   VOE14560637   [27]   Plug
33   SA7223-00390   [8]   Hex. socket screw
34   SA7223-00410   [2]   Piston
35   SA7223-00420   [2]   Stop
36   SA7223-00430   [2]   Stop
37   SA7223-00480   [2]   Non-return valve
38   SA7223-00510   [1]   Seat
39   SA7223-00530   [1]   Stop
40   SA9676-73200   [1]   Ball
41   SA7223-00490   [2]   Check valve
42   SA7223-00510   [1]   Seat
43   SA7223-00550   [1]   Stop
44   SA9676-73200   [1]   Ball
45   VOE967630   [4]   Hex. socket screw
46   SA7223-00690   [2]   O-ring
47   VOE14533617   [2]   O-ring
48   VOE14533034   [2]   O-ring
49   VOE14533035   [2]   O-ring
50   VOE14533604   [16]   O-ring
51   VOE14533606   [4]   O-ring
52   VOE14533612   [3]   O-ring
53   SA7223-00700   [2]   O-ring
54   VOE14600699   [1]   Seal
55   VOE14692341   [2]   Ring
56   SA7223-00650   [2]   Ring
57   VOE979022   [4]   Hexagon nut
58   VOE914470   [2]   Snap ring
59   SA7242-10560   [2]   Pin
60   SA7223-00660   [4]   Spring pin
61   VOE14880555   [2]   Eye bolt
62   SA7223-00670   [2]   Set screw
63   VOE14511994   [1]   Cover
64   VOE983919   [4]   Hex. socket screw
65   VOE14512382   [12]   Plug
66   VOE14883837   [2]   Plug
67   VOE14533618   [1]   O-ring
68   SA7223-00680   [2]   Set screw
69   VOE14512927   [1]   Power take-off
  VOE14512927       Power take-off
70   VOE14519957       Cover
71   VOE14511977   [1]   Shaft
72   VOE14511978   [1]   Shaft
  VOE14520039       Shaft
73   VOE14533617   [1]   O-ring
74   VOE14551796   [1]   Cover
75   SA7223-00290   [2]   Casing
76   VOE14511982   [1]   Block
  VOE14518276       Block
77   VOE14502012   [2]   Pin
78   SA7223-00400   [1]   Pin
79   SA7223-00570   [1]   Pin
80   SA9415-11051   [3]   Plug
100   VOE14512931   [1]   Sealing kit   SER NO 10001-11490
  VOE14534326   [1]   Sealing Kit   SER NO 11491-
