VOLVO EC330B EC360B EXCAVATOR VOE14500380 VOE14512271 VOE14516492 VOE14516492 VOE14520050 HEAVY PUMP PARTS

Name: VOLVO EC330B EC360B EXCAVATOR VOE14500380 VOE14512271 VOE14516492 VOE14516492 VOE14520050 HEAVY PUMP PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

VOLVO EC330B EC360B EXCAVATOR VOE14500380 VOE14512271 VOE14516492 VOE14516492 VOE14520050 HEAVY PUMP PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

VOE14500380 VOE14512271 VOE14516492 VOE14516492 VOE14520050 EC330B EC360B

Pos.	Part No	Qty	Parts name	Comments
1	VOE14500380	[1]	Pump	SER NO 10001-10122
	VOE14516492	[1]	Pump	SER NO 10123-10240
	VOE14516492		Pump	SER NO 10241-
	VOE14512271		Pump	SER NO 10241-10828
	VOE14520050		Pump	SER NO 10829-
2	VOE14512928	[2]	Regulator	SER NO 10001-10122
	VOE14561183	[2]	Regulator kit	SER NO 10123-10240
	VOE14561183		Regulator kit	SER NO 10241-
	VOE14561183		Regulator kit	SER NO 10829-
3	SA8230-08830	[1]	Gear Pump	SER NO 10001-10122
	SA7220-00510	[1]	Gear pump	SER NO 10123-10240
	SA7220-00510		Gear pump	SER NO 10241-
4	VOE949566	[4]	Hex. socket screw	SER NO 10001-10054
	SA9016-12013	[4]	Bolt	SER NO 10055-10240
	SA9016-12013		Bolt	SER NO 10241-10580
	VOE984364		Hex. socket screw	SER NO 10581-
	VOE984364		Hex. socket screw	SER NO 10829-
5	VOE60110287	[4]	Washer	SER NO 10055-10240
	VOE60110287		Washer	SER NO 10241-
	VOE60110287		Washer	SER NO 10829-
Parts on group Hydraulic gear pump:

Pos.	Part No	Qty	Parts name	Comments
	VOE14505880	[1]	Gear Pump
	SA7210-00930		Gear pump
Parts on group Hydraulic gear pump:

Pos.	Part No	Qty	Parts name	Comments
	VOE14509153	[1]	Gear Pump	SER NO 10829-10911
	VOE14525545	[1]	Gear pump	SER NO 10912-
	VOE14520055		Pump	SER NO 10829-10911
	VOE14525548		Gear pump	SER NO 10912-
Parts on group Hydraulic pump:

Pos.	Part No	Qty	Parts name	Comments
	VOE14500380	[1]	Pump
1	SA7223-00140	[2]	Piston
2	VOE14512923	[9]	Piston
3	VOE14502323	[9]	Seat
4	SA8230-09880	[1]	Cylinder
5	VOE14502321	[1]	Block
6	VOE14502324	[1]	Plate
7	SA8230-09890	[1]	Cylinder
8	VOE14502321	[1]	Block
9	VOE14502325	[1]	Plate
10	VOE14502011	[2]	Plate
11	SA7223-00220	[1]	Plate
12	SA7223-00240	[1]	Bushing
13	VOE14512921	[1]	Gear
14	SA8230-26640	[2]	Roller Bearing
15	VOE14512922	[2]	Needle Bearing
16	SA7223-00060	[3]	Spacer
17	SA8230-09300	[2]	Plate
18	VOE14510070	[2]	Bushing
19	SA8230-09840	[18]	Spring
20	SA8230-08960	[2]	Support
21	SA7223-00210	[2]	Plate
22	SA8230-09020	[1]	Valve
23	VOE14512919	[1]	Shaft
24	VOE14512920	[1]	Shaft
25	SA8230-35460	[1]	Cover
26	SA8230-32160	[2]	Body
27	VOE14512925	[1]	Block
28	SA8230-09920	[4]	Seat
29	SA8230-09930	[2]	Stop
30	SA9676-73200	[4]	Ball
31	SA9415-11051	[4]	Plug
32	VOE14560637	[27]	Plug
33	SA8230-35490	[8]	Bolt
34	SA8230-35450	[2]	Piston
35	SA8230-35480	[2]	Stop
36	SA8230-35470	[2]	Stop
37	VOE14883837	[2]	Plug
38	SA8230-09780	[2]	Pin
39	SA7223-00400	[1]	Pin
40	SA7223-00570	[1]	Pin
41	VOE14512927	[1]	Power take-off
42	VOE990602	[1]	O-ring
43	SA8230-09910	[2]	Stopper
44	SA8230-30930	[2]	Screw
45	VOE13967630	[4]	Allen Hd Screw
46	SA7223-00690	[2]	O-ring
47	VOE990597	[2]	O-ring
48	SA7223-00590	[2]	O-ring
49	SA7223-00600	[2]	O-ring
50	VOE983495	[16]	O-ring
51	VOE983502	[6]	O-ring
52	VOE983524	[4]	O-ring
53	SA7223-00700	[2]	O-ring
54	SA7223-00710	[1]	Seal
55	SA8230-26840	[2]	Ring
56	SA8230-26830	[2]	Ring
57	SA9111-12000	[4]	Nut
58	VOE914470	[2]	Snap ring
59	SA7242-10560	[2]	Pin
60	SA7223-00660	[4]	Spring pin
61	SA8230-25460	[2]	Eye Bolt
62	SA7223-00670	[2]	Set screw
63	VOE14512926	[1]	Cover
64	SA8240-03470	[4]	Bolt
65	SA8230-27740	[12]	Plug
100	VOE14554798	[1]	Seal
Parts on group Hydraulic pump:

Pos.	Part No	Qty	Parts name	Comments
	VOE14516492	[1]	Pump
	VOE14512271		Pump
	VOE14520050		Pump
1	SA7223-00140	[2]	Piston
2	SA7223-00150	[9]	Piston
3	SA7223-00160	[9]	Pad
4	VOE14563795	[1]	Cylinder
5	SA7223-00090	[1]	Block
6	SA7223-00360	[1]	Plate
7	SA7223-00790	[1]	Cylinder
8	SA7223-00090	[1]	Block
9	SA7223-00370	[1]	Plate
10	VOE14502011	[2]	Plate
11	SA7223-00220	[1]	Plate
12	SA7223-00240	[1]	Bushing
13	VOE14511979	[1]	Gear
14	SA7241-00421	[2]	Roller bearing
15	VOE14511981	[2]	Bearing
16	SA7223-00060	[3]	Spacer
17	SA7242-10210	[2]	Plate
18	VOE14510070	[2]	Bushing
19	SA7223-00180	[18]	Spring
20	SA7223-00260	[2]	Support
21	SA7223-00210	[2]	Plate
22	VOE14532653	[1]	Valve	SER NO 10001-11490
	VOE14532653		Valve	SER NO 11491-
23	VOE14533608	[1]	O-ring
24	VOE14533606	[4]	O-ring
25	VOE14560637	[3]	Plug
26	VOE14883837	[1]	Plug
27	SA9016-20612	[3]	Bolt
28	SA8230-32080	[1]	Valve
29	VOE14535454	[1]	O-ring
30	VOE14535455	[1]	O-ring
31	VOE14535456	[1]	O-ring
32	VOE14560637	[27]	Plug
33	SA7223-00390	[8]	Hex. socket screw
34	SA7223-00410	[2]	Piston
35	SA7223-00420	[2]	Stop
36	SA7223-00430	[2]	Stop
37	SA7223-00480	[2]	Non-return valve
38	SA7223-00510	[1]	Seat
39	SA7223-00530	[1]	Stop
40	SA9676-73200	[1]	Ball
41	SA7223-00490	[2]	Check valve
42	SA7223-00510	[1]	Seat
43	SA7223-00550	[1]	Stop
44	SA9676-73200	[1]	Ball
45	VOE967630	[4]	Hex. socket screw
46	SA7223-00690	[2]	O-ring
47	VOE14533617	[2]	O-ring
48	VOE14533034	[2]	O-ring
49	VOE14533035	[2]	O-ring
50	VOE14533604	[16]	O-ring
51	VOE14533606	[4]	O-ring
52	VOE14533612	[3]	O-ring
53	SA7223-00700	[2]	O-ring
54	VOE14600699	[1]	Seal
55	VOE14692341	[2]	Ring
56	SA7223-00650	[2]	Ring
57	VOE979022	[4]	Hexagon nut
58	VOE914470	[2]	Snap ring
59	SA7242-10560	[2]	Pin
60	SA7223-00660	[4]	Spring pin
61	VOE14880555	[2]	Eye bolt
62	SA7223-00670	[2]	Set screw
63	VOE14511994	[1]	Cover
64	VOE983919	[4]	Hex. socket screw
65	VOE14512382	[12]	Plug
66	VOE14883837	[2]	Plug
67	VOE14533618	[1]	O-ring
68	SA7223-00680	[2]	Set screw
69	VOE14512927	[1]	Power take-off
	VOE14512927		Power take-off
70	VOE14519957		Cover
71	VOE14511977	[1]	Shaft
72	VOE14511978	[1]	Shaft
	VOE14520039		Shaft
73	VOE14533617	[1]	O-ring
74	VOE14551796	[1]	Cover
75	SA7223-00290	[2]	Casing
76	VOE14511982	[1]	Block
	VOE14518276		Block
77	VOE14502012	[2]	Pin
78	SA7223-00400	[1]	Pin
79	SA7223-00570	[1]	Pin
80	SA9415-11051	[3]	Plug
100	VOE14512931	[1]	Sealing kit	SER NO 10001-11490
	VOE14534326	[1]	Sealing Kit	SER NO 11491-
