VOLVO EC330B EC360 EC360B EXCAVATOR SA7240-10601 HEAVY TRAVEL MOTOR ROATRY GROUP AND SPARE PARTS

VOLVO EC330B EC360 EC360B EXCAVATOR SA7240-10601 HEAVY TRAVEL MOTOR ROATRY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
  SA7240-10601 EC330B EC360 EC360B
Pos. Part No Qty Parts name Comments
  SA7240-10601   [1]   Travel motor
1   SA7242-10090   [1]   Shaft
2   VOE14640025   [1]   Roller bearing
3   SA7242-10110   [1]   Needle bearing
4   SA7242-10120   [1]   Spacer
5   VOE914472   [1]   Snap ring
6 SA7242-11460   [1]   Cover
7   SA7242-10150   [1]   Bushing
8   SA7242-10160   [9]   Spring
9   SA7242-10170   [1]   Spacer
10   SA7242-10180   [9]   Piston
11   SA7242-10210   [1]   Plate
12   SA7242-11140   [1]   Plate
13   SA7242-11150   [1]   Support
14   SA9676-73200   [2]   Ball
15   SA7242-10330   [1]   Cover
16   VOE914542   [1]   Retaining ring
17   VOE14560637   [11]   Plug
18   VOE990591   [1]   O-ring
19   SA7242-10580   [1]   O-ring
20   SA7242-10590   [1]   Seal
21   SA7242-10600   [1]   Piston
22   SA7242-10630   [1]   Piston
23   SA7242-10660   [1]   Guard
24   SA7242-10670   [1]   Guard
25   SA7242-11090   [2]   Screw
26   VOE997410   [2]   Hexagon nut
27   VOE983523   [1]   O-ring
28   VOE983507   [2]   O-ring
29   SA9566-10160   [1]   Back-up ring
30   VOE14880818   [1]   Back-up ring
31   SA7242-11210   [1]   Piston
32   SA7242-10750   [3]   Screw
33   VOE983497   [3]   O-ring
34   SA7242-10760   [1]   Piston
35   VOE14565167   [10]   Spring
36   SA7242-10790   [1]   Piston ring
37   SA7242-10800   [1]   Piston ring
38   SA7242-10820   [1]   Seat
39   SA7242-10830   [1]   Slide
40   SA7242-10840   [1]   Bushing
41   SA7242-10850   [1]   Spring
42   SA7242-11300   [1]   Plug
43   SA7242-10870   [1]   Separating plate
44   SA7242-10880   [2]   Friction plate
45   SA7242-10010   [1]   Slide
46   VOE14883837   [7]   Plug
47   SA7242-11580   [2]   Relief valve
48   SA7242-10540   [2]   Cover
49   VOE990585   [2]   O-ring
50   SA9016-11209   [8]   Hex. socket screw
51   SA9016-11610   [8]   Hex. socket screw
52   SA7242-10550   [4]   Screw
53   SA9415-11041   [4]   Plug
54   VOE990557   [4]   O-ring
55   SA7242-10680   [1]   Piston rod
56   VOE983502   [7]   O-ring
57   SA7242-11290   [1]   Plug
58   VOE983509   [1]   O-ring
59   SA9511-1210A   [1]   O-ring
60   SA7242-11540   [1]   Spool
61   SA7242-11560   [1]   Spring
62   SA7242-10710   [2]   Clamping plate
63   SA7242-10720   [2]   Guard
100   SA7242-11450   [1]   Kit
