VOLVO EC300D SWING REDUCTION GEARBOX PARTS

VOLVO EC300D SWING REDUCTION GEARBOX PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group Swing gearbox:
Pos. Part No Qty Parts name Comments
  VOE14569767   [1]   Swing gearbox
  VOE14569767       Swing gearbox   S/N -231044, -250199, -271170, -280958
  VOE14724044       Swing gearbox   S/N 231045-, 250200-, 271171-, 280959-
1   VOE14547262   [1]   Case
2   VOE14547260   [1]   Ring
3   VOE14547259   [1]   Collar
4   VOE14547258   [1]   Shaft
5   VOE14547263   [1]   Cover
6   VOE14547266   [1]   Gear
7   VOE984363   [20]   Hex. socket screw
8   VOE944088   [12]   Screw
9   VOE14547261   [1]   Bearing
10   SA9415-43012   [1]   Plug
11   VOE914167   [1]   Lubricating nipple
12   VOE14566830   [1]   Seal
13   VOE14547265   [1]   Bearing
14   SA9541-01110   [1]   Retaining ring
15   SA7118-30380   [1]   Thrust ring
16   VOE14547272   [1]   Gear
17   VOE14547278   [1]   Thrust washer
18   VOE14547279   [1]   Gear
19   VOE14880960   [1]   Retaining ring
20   VOE14547281   [1]   Pipe
21   VOE14547280   [1]   Planet carrier 2
22   VOE14547267   [1]   Planet carrier
23   VOE14547271   [4]   Pin
24   VOE14547268   [4]   Gear
25   VOE14547269   [4]   Bushing
26   VOE14556491   [8]   Washer
27   SA9325-06012   [4]   Spring pin
28   VOE14547273   [1]   Planet carrier 1
29   VOE14547274   [1]   Planet carrier
30   VOE14547275   [3]   Gear
31   SA7117-30230   [3]   Needle bearing
32   VOE14547277   [3]   Pin
33   SA9325-06012   [3]   Spring pin
34   VOE14547276   [6]   Washer
35   VOE950677   [4]   Pin
36   VOE949329   [1]   Gasket
37   VOE14722461   [1]   Draining valve
