VOLVO EC300D EC300E EC340D EC350D EC350E EC380D EC380DHR EC380E EC380EHR EXCAVATOR VOE14606699 HEAVY TRAVEL MOTOR PARTS

VOLVO EC300D EC300E EC340D EC350D EC350E EC380D EC380DHR EC380E EC380EHR EXCAVATOR VOE14606699 HEAVY TRAVEL MOTOR PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
VOE14606699
EC300D EC300E EC340D EC350D EC350E EC380D EC380DHR EC380E EC380EHR
Travel motor with mounting parts 8289146, 8289148, 8289147
Pos. Part No Qty Parts name Comments
  VOE14606699   [1]   Travel motor
1       [1]   Casing
2   VOE14565337   [1]   Rod
3   VOE14565336   [1]   Pin
4   VOE983507   [1]   O-ring
5   VOE983501   [1]   O-ring
6   VOE14528296   [1]   Screw
7   VOE997410   [1]   Hexagon nut
8   VOE14551525   [1]   Pin
9   VOE990585   [2]   O-ring
10   SA7242-10540   [2]   Cover
11   SA7242-10750   [1]   Screw
12   VOE983497   [1]   O-ring
13   SA9415-31021   [7]   Plug
14   VOE993320   [7]   O-ring
15   VOE14506978   [1]   Plate
16   SA9016-22019   [2]   Hex. socket screw
17   VOE14560637   [9]   Plug
18   SA9016-11209   [8]   Hex. socket screw
19       [2]   Plug
20   VOE993322   [2]   O-ring
21   VOE984229   [4]   Hex. socket screw
22   SA7242-10710   [2]   Clamping plate
23   SA7242-10720   [2]   Guard
24   VOE14880998   [2]   Ball
25   VOE14880006   [1]   Name plate
26   SA1010-11360   [2]   Screw
27   SA7242-10520   [2]   Washer
28   SA7242-10530   [2]   Spring
29   SA7242-11560   [1]   Spring
30   VOE14507000   [1]   Spacer
31   SA7242-11290   [1]   Plug
32   VOE983509   [1]   O-ring
33   VOE14509997   [1]   Spool
34   VOE14506994   [1]   Spring
35   VOE14506995   [1]   Plug
36   VOE983505   [1]   O-ring
37   VOE14579610   [1]   Control plunger
38   VOE14565331   [1]   Shaft
39   VOE14640025   [1]   Roller bearing
40   VOE14506955   [1]   Bearing
41   VOE914472   [1]   Snap ring
42       [1]   Casing
43   SA7242-10590   [1]   Seal
44   SA8320-01810   [1]   Retaining ring
45   VOE14506958   [2]   Pivot
46   VOE14506959   [1]   Piston
47   VOE14551526   [5]   Pin
48   VOE14506982   [3]   Plate
49   VOE14506984   [2]   Plate
50   VOE14565332   [1]   Piston
51   VOE960262   [1]   O-ring
52   VOE990849   [2]   O-ring
53   VOE14568004   [10]   Spring
54   VOE14604842   [1]   Plate
55   VOE14552644   [1]   Cylinder
56   VOE14506967   [9]   Spring
57   VOE14506968   [1]   Spacer
58   VOE14506970   [1]   Guide
59   VOE14506972   [1]   Plate
60       [9]   Pad
61   VOE14551797   [9]   Piston
62   VOE14568912   [2]   Relief valve
63   SA8240-03680   [2]   Snap ring
64   VOE990582   [2]   O-ring
65   VOE14880837   [2]   Back-up ring
66   VOE14548120   [2]   Spring
67   SA7273-30540   [4]   Ring
68   VOE983542   [2]   O-ring
69   VOE983501   [2]   O-ring
70   VOE14625244   [2]   Ring
71   VOE983527   [2]   O-ring
72   VOE14506950   [1]   Spool
73   VOE14880996   [2]   Ball
100   VOE14596398   [1]   Seal
arts on group Travel motor with mounting parts:
Pos. Part No Qty Parts name Comments
1   VOE14603461   [2]   Drive unit   S/N -210680/-230545/-260015/-
1   VOE14667673   [2]   Drive unit   S/N 210681-210684/230546- -231017/260016-260037/270
1   VOE14694046   [2]   Drive unit   S/N 271258-271438/ 280325-280400
1   VOE14713848   [2]   Drive unit   S/N 231018-231031/ 271439-271466/
1   VOE14723003   [2]   Drive unit   S/N 231032-/271467-/ 280441-
2       [2]   Travel motor
3       [2]   Gearbox
4   VOE60110287   [44]   Washer
5   VOE997474   [8]   Hexagon screw
6   VOE997475   [44]   Hexagon screw
