VOLVO EC290B EC330B EC360B EC360C EXCAVATOR VOE14516453 VOE14521840 VOE14522920 VOE14528281 HEAVY TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

VOLVO EC290B EC330B EC360B EC360C EXCAVATOR VOE14516453 VOE14521840 VOE14522920 VOE14528281 HEAVY TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
VOE14516453 VOE14521840
VOE14522920 VOE14528281
EC290B EC330B EC360B EC360C
Pos. Part No Qty Parts name Comments
  VOE14516453   [1]   Travel motor   SER NO 10211-10545
  VOE14521840   [1]   Travel motor   SER NO 10546-10712
  VOE14522920   [1]   Travel motor   SER NO 10713-11044
  VOE14528281   [1]   Travel motor   SER NO 11045-
1   VOE14506950   [1]   Spool
2   VOE14506954   [1]   Shaft
3   VOE14640025   [1]   Roller bearing
4   VOE14506955   [1]   Bearing
5   VOE914472   [1]   Snap ring
6   VOE14528283   [1]   Casing
7   SA7242-10590   [1]   Seal
8   SA9541-02090   [1]   Retaining ring
9   VOE14506958   [2]   Pivot
10   VOE14506959   [1]   Piston
11   VOE14508608   [1]   Plate
12   VOE14506974   [0009]   Piston
13   VOE14506968   [1]   Spacer
14   VOE14506970   [1]   Guide
15   VOE14506972   [1]   Plate
16   VOE14506980   [1]   Pin
17   VOE14506982   [2]   Plate
18   VOE14506984   [1]   Plate
19   VOE14506986   [1]   Piston
20   VOE14506988   [1]   O-ring   SER NO 10211-11282
  VOE14529784   [1]   O-ring   SER NO 11283-
21   VOE990849   [2]   O-ring
22   VOE14565167   [10]   Spring
23   VOE14883837   [7]   Plug
24   VOE983502   [7]   O-ring
25 VOE14552644   [1]   Cylinder
26   VOE983497   [2]   O-ring
27   VOE983507   [2]   O-ring
28   VOE14506993   [1]   Spool
29   VOE14506994   [1]   Spring
30   VOE14506995   [1]   Plug
31   VOE983505   [1]   O-ring
32   SA7242-10680   [1]   Piston rod
33   SA9511-1210A   [1]   O-ring
34   SA7242-11090   [1]   Screw   SER NO 10211-11044
  VOE14528296   [1]   Screw   SER NO 11045-
35   VOE997410   [1]   Hexagon nut
36   VOE14507000   [1]   Spacer
37   SA7242-11290   [1]   Plug
38   VOE983509   [1]   O-ring
39   SA7242-10560   [1]   Pin
40   SA7242-10520   [2]   Washer
41   SA7242-10530   [2]   Spring
42   VOE990585   [2]   O-ring
43   SA7242-10540   [2]   Cover
44   SA9016-11209   [8]   Hex. socket screw
45   SA9415-11041   [2]   Plug
46   VOE990557   [2]   O-ring
47 SA7242-11580   [2]   Relief valve
48   SA9016-12010   [4]   Hex. socket screw
49   SA9016-22019   [2]   Hex. socket screw
50   SA7242-10710   [2]   Clamping plate
51   SA9676-73200   [2]   Ball   SER NO 10211-11130
  VOE14880998   [2]   Ball   SER NO 11131-
52   SA7242-10720   [2]   Guard
53   VOE14560637   [9]   Plug
54   SA7242-10750   [2]   Screw
55   VOE14506967   [9]   Spring
56   VOE14507001   [1]   Filter   SER NO 10211-11282
57   VOE14509997   [1]   Spool
100   VOE14513325   [1]   Sealing Kit
