VOLVO EC290B EC290C FC3329C EXCAVATOR VOE14524190 VOE14573056 SWING MOTOR PARTS

VOLVO EC290B EC290C FC3329C EXCAVATOR VOE14524190 VOE14573056 SWING MOTOR PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
VOE14524190 VOE14573056
EC290B EC290C FC3329C
Pos. Part No Qty Parts name Comments
1   VOE14573056   [1]   Swing Motor
2   VOE14524190   [1]   Swing motor
3   VOE14542165   [1]   Swing gearbox
4   VOE14512936   [1]   Gauge   LEVEL
5   VOE14512937   [1]   Pipe
6   VOE914470   [1]   Snap ring
7   VOE14531019   [1]   Washer
8   VOE14531024   [1]   Pin
9   VOE14504235   [1]   Pinion
10   VOE14504260   [1]   Plate
11   VOE60110287   [14]   Washer
12   VOE997459   [2]   Hexagon screw
13   VOE997475   [14]   Hexagon screw
Parts on group Swing motor:
Pos. Part No Qty Parts name Comments
  VOE14524190   [1]   Swing motor
1   VOE14501795   [1]   Casing
  VOE14501796   [1]   Casing
  SA8230-25950   [2]   Spring Pin
2   VOE14501797   [1]   Shaft
3   VOE14501798   [2]   Plunger
4   VOE14501799   [2]   Spring
5   VOE14501800   [1]   Ring
6   VOE14501801   [1]   Bearing
7   VOE14501802   [2]   Plug
8   VOE14518516   [2]   Relief valve
9   VOE990582   [1]   O-ring
10   VOE14880837   [1]   Back-up ring
11   VOE14612206   [1]   Piston
  VOE14501793   [9]   Piston
  VOE14501794   [9]   Seat
12   SA8230-13610   [1]   Casing
13   SA8230-13760   [1]   Valve plate
14   SA8230-13820   [1]   Piston
15   SA8230-13900   [1]   Plate
16   SA8230-13910   [3]   Plate
17   SA8230-13940   [2]   Friction plate
18   SA8230-13980   [1]   Brake Shoe
19   SA8230-14010   [3]   Spacer
20   SA8230-14020   [1]   Cover
21   SA8230-14030   [1]   Spring
22   SA8230-14040   [20]   Spring brake
23   SA8230-14050   [1]   Bushing
24   SA8230-14060   [1]   Spacer
25   SA8230-14070   [1]   Spacer
26   SA8230-25551   [1]   O-ring
27   SA8230-25690   [1]   Ring
28   SA8230-25740   [1]   Ring
29   SA8230-25820   [4]   Bolt
30   SA8230-26390   [12]   Bar
31   SA7241-00421   [1]   Roller bearing
32   VOE14612219   [1]   Plug
33   SA8220-15000   [1]   Seal
34   SA8230-13440   [1]   Valve
35   SA8230-33690   [2]   Plug
36   SA8230-30430   [1]   Plug
37   SA8230-32950   [1]   Cylinder
38   SA8230-32990   [1]   O-ring
39   SA8230-33960   [1]   O-ring
40   VOE14883837   [1]   Plug
41   VOE983502   [1]   O-ring
42   SA8230-27360   [1]   Block
43   SA8230-29070   [1]   Casing
44   SA8230-25640   [2]   Plug
45   VOE983502   [2]   O-ring
46   VOE14529757   [2]   O-ring
47   VOE14533603   [2]   O-ring
48   SA8240-03610   [4]   Screw
49   VOE14684415   [2]   Valve
50   VOE983509   [1]   O-ring
51   VOE14625240   [1]   Ring
52   VOE983530   [2]   O-ring
53   VOE990596   [1]   O-ring
54   VOE914470   [2]   Snap ring
100   VOE14501803   [1]   Seal
