VOLVO EC290 EC290B EXCAVATOR TRAVEL GEARBOX

VOLVO EC290 EC290B EXCAVATOR TRAVEL GEARBOX

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group Travel gearbox:EC290B Travel gearbox SER NO INT 13562- EU & NA 80001- NoneNone 8278060,S/N 14180-/8279549,8279569,8279570,S/N 80001- Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14528258   [1]   Travel Gearbox
1   VOE14522896   [1]   Housing
2   SA7117-38230   [2]   Bearing
3   VOE14579901   [1]   Seal
4   VOE14528319   [1]   Nut
5   VOE14526459   [3]   Screw
6   VOE14601855   [1]   Cover
7   VOE983524   [3]   O-ring
8   VOE14883848   [3]   Plug
9   VOE14522897   [1]   Gear
10   SA9016-21620   [20]   Hex. socket screw
11   VOE14551153   [1]   Planet carrier
12   VOE14556491   [6]   Washer
13   SA7117-38320   [1]   Planet carrier
14   SA7117-38330   [1]   Gear
15   SA7117-38340   [1]   Ring
16   SA7117-38350   [3]   Planetary Gear
17   SA7117-38360   [3]   Needle bearing
18   SA7117-38380   [1]   Pin
19   SA9325-06012   [3]   Spring pin
20   VOE14551156   [1]   Planet carrier
21   SA9325-06012   [3]   Spring pin
22   VOE13914468   [3]   Snap ring
23   SA7117-38180   [1]   Pin
24   SA7117-38391   [1]   Planet carrier
25   SA7117-38400   [1]   Gear
26   SA7117-38410   [1]   Ring
27   SA7117-38420   [3]   Needle Bearing
28   SA7117-38431   [3]   Planetary gear
29   VOE14556489   [1]   Washer
30   VOE14556490   [1]   Washer
31   SA1036-00290   [1]   Thrust ring
32   SA7117-38371   [1]   Gear
33   VOE914467   [1]   Retaining ring
34   SA7117-38271   [4]   Planet gear
35   SA7117-38520   [4]   Needle bearing
36   SA7117-38301   [4]   Pin
37   SA7117-38460   [4]   Inner ring
38   VOE14546062   [8]   Washer
39   SA9325-06012   [4]   Spring pin
40   SA8230-21020   [1]   Thrust ring
41   VOE983252   [16]   Hexagon screw
42   VOE955922   [16]   Spring washer
