| Parts on group Travel gearbox:EC290B Travel gearbox SER NO INT 13562- EU & NA 80001- 8277459-None NoneNone None Autodata Volvo online |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
|
VOE14528258 |
[1] |
Travel Gearbox |
|
| 1 |
SA7117-38221 |
[1] |
Housing |
SER NO 10001-10928 |
|
VOE14521858 |
[1] |
Housing |
SER NO 10929-11467 |
|
VOE14522896 |
[1] |
Housing |
SER NO 11468- |
| 2 |
SA7117-38230 |
[2] |
Bearing |
|
| 3 |
SA7117-38240 |
[1] |
Seal |
SER NO 10001-11467 |
|
VOE14579901 |
[1] |
Seal |
SER NO 11468- |
| 4 |
SA7117-38251 |
[1] |
Nut |
SER NO 10001-12345 |
|
VOE14528319 |
[1] |
Nut |
SER NO 12346- |
| 5 |
SA9023-10803 |
[2] |
Set screw |
SER NO 10001-12345 |
|
VOE14526459 |
[3] |
Screw |
SER NO 12346- |
| 6 |
SA7117-38190 |
[1] |
Cover |
SER NO 10001-10255 |
|
VOE14517931 |
[1] |
Cover |
SER NO 10256-11311 |
|
VOE14601855 |
[1] |
Cover |
SER NO 11312- |
| 7 |
VOE983524 |
[3] |
O-ring |
SER NO 10256- SER NO 30001- |
| 8 |
SA9415-43042 |
[3] |
Plug |
SER NO 10001-10255 |
|
VOE14883848 |
[3] |
Plug |
SER NO 10256- SER NO 30001- |
| 9 |
SA7117-38311 |
[1] |
Gear |
SER NO 10001-11311 |
|
VOE14522897 |
[1] |
Gear |
SER NO 11312- |
| 10 |
SA9016-21620 |
[20] |
Hex. socket screw |
|
| 11 |
VOE14551153 |
[1] |
Planet carrier |
|
| 12 |
VOE14556491 |
[6] |
Washer |
|
| 13 |
SA7117-38320 |
[1] |
Planet carrier |
|
| 14 |
SA7117-38330 |
[1] |
Gear |
|
| 15 |
SA7117-38340 |
[1] |
Ring |
|
| 16 |
SA7117-38350 |
[3] |
Planetary Gear |
|
| 17 |
SA7117-38360 |
[3] |
Needle bearing |
|
| 18 |
SA7117-38380 |
[1] |
Pin |
|
| 19 |
SA9325-06012 |
[3] |
Spring pin |
|
| 20 |
VOE14551156 |
[1] |
Planet carrier |
|
| 21 |
SA9325-06012 |
[3] |
Spring pin |
|
| 22 |
VOE13914468 |
[3] |
Snap ring |
|
| 23 |
SA7117-38180 |
[1] |
Pin |
|
| 24 |
SA7117-38391 |
[1] |
Planet carrier |
|
| 25 |
SA7117-38400 |
[1] |
Gear |
|
| 26 |
SA7117-38410 |
[1] |
Ring |
|
| 27 |
SA7117-38420 |
[3] |
Needle Bearing |
|
| 28 |
|
[3] |
Planetary Gear |
|
| 29 |
VOE14556489 |
[1] |
Washer |
|
| 30 |
VOE14556490 |
[1] |
Washer |
|
| 31 |
SA1036-00290 |
[1] |
Thrust ring |
|
| 32 |
SA7117-38371 |
[1] |
Gear |
|
| 33 |
VOE914467 |
[1] |
Retaining ring |
|
| 34 |
SA7117-38271 |
[4] |
Planet gear |
|
| 35 |
SA7117-38520 |
[4] |
Needle bearing |
|
| 36 |
SA7117-38301 |
[4] |
Pin |
|
| 37 |
SA7117-38460 |
[4] |
Inner ring |
|
| 38 |
VOE14546062 |
[8] |
Washer |
|
| 39 |
SA9325-06012 |
[4] |
Spring pin |
|
| 40 |
SA8230-21020 |
[1] |
Thrust ring |
|
| 41 |
VOE967631 |
[16] |
Hex. socket screw |
SER NO 10001-11311 |
|
VOE983252 |
[16] |
Hexagon screw |
SER NO 11312- |
| 42 |
VOE955922 |
[16] |
Spring washer |
SER NO 11312- |
