VOLVO EC290 EC290B EXCAVATOR SA7220-00601 VOE14524052 HYDRAULIC PUMP PARTS

VOLVO EC290 EC290B EXCAVATOR SA7220-00601 VOE14524052 HYDRAULIC PUMP PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
SA7220-00601 VOE14524052
EC290 EC290B
Pos. Part No Qty Parts name Comments
1   SA7220-00601   [1]   Pump   SER NO 10001-12123
  VOE14524052   [1]   Pump   SER NO 12124-
2   SA9016-12011   [4]   Bolt   SER NO 10001-10060
  VOE984229   [4]   Hex. socket screw   SER NO 10061-
3   VOE60110287   [4]   Washer   SER NO 10061-
Parts on group Hydraulic pump:
Pos. Part No Qty Parts name Comments
  SA7220-00601   [1]   Pump   SER NO 10001-12123 SER NO 30001-30141
  VOE14524052   [1]   Pump   SER NO 12124- SER NO 30142-
1   VOE14601423   [2]   Piston
2   SA7223-00120   [9]   Piston
3   SA7223-00130   [9]   Pad
4   VOE14575662   [1]   Cylinder
5   SA7223-00070   [1]   Cylinder Block
6   SA7223-00340   [1]   Plate
7   VOE14543590   [1]   Cylinder
8   SA7223-00070   [1]   Cylinder Block
9   SA7223-00350   [1]   Plate
10   VOE14506635   [2]   Plate
11   SA7223-00220   [1]   Plate
12   SA7223-00240   [1]   Bushing
13   SA7223-00030   [1]   Connector
14   SA7223-00040   [2]   Roller bearing
15   SA7223-00050   [2]   Needle bearing
16   SA7223-00060   [3]   Spacer
17   SA7242-10210   [2]   Plate
18   VOE14510060   [2]   Bushing
19   SA7223-00170   [18]   Spring
20   SA7223-00420   [2]   Stop
21   SA7223-00210   [2]   Plate
22   VOE14532653   [1]   Valve   SER NO 10001-12912 SER NO 30001-30177
  VOE14532653   [1]   Valve   SER NO 12913- SER NO 30178-
23   VOE14533608   [1]   O-ring
24   VOE14533606   [4]   O-ring
25   VOE14560637   [3]   Plug
26   VOE14883837   [1]   Plug
27   SA9016-20612   [3]   Bolt
28   SA8230-32080   [1]   Valve
29   VOE14535454   [1]   O-ring
30   VOE14535455   [1]   O-ring
31   VOE14535456   [1]   O-ring
32   SA7223-00290   [2]   Casing   SER NO 10001-13328 SER NO 30001-30207
  VOE14526119   [2]   Casing   SER NO 13329- SER NO 30208-
33   SA7223-00310   [1]   Block
34   SA7223-00390   [8]   Hex. socket screw
35   VOE967630   [4]   Hex. socket screw
36   VOE14883837   [2]   Plug
37   SA7223-00480   [2]   Non-return valve
38   SA7223-00510   [1]   Seat
39   SA7223-00530   [1]   Stop
40   VOE14880998   [1]   Ball
41   SA7223-00490   [2]   Check valve
42   SA7223-00510   [1]   Seat
43   SA7223-00550   [1]   Stop
44   VOE14880998   [1]   Ball
45   SA9415-11051   [3]   Plug
46   SA7223-00690   [2]   O-ring
47   VOE14533617   [1]   O-ring
48   VOE14533034   [2]   O-ring
49   VOE14533035   [2]   O-ring
50   VOE14533604   [16]   O-ring
51   VOE14533606   [4]   O-ring
52   VOE14533612   [3]   O-ring
53   SA7223-00700   [2]   O-ring
54   VOE14600699   [1]   Seal
55   VOE14692341   [2]   Ring
56   SA7223-00650   [2]   Ring
57   VOE979022   [4]   Hexagon nut
58   VOE914470   [2]   Snap ring
59   SA7242-10560   [2]   Pin
60   SA7223-00660   [4]   Spring pin
61   VOE14880555   [2]   Eye bolt
62   SA7223-00670   [2]   Set screw
63   SA7223-00680   [2]   Set screw
64   SA7223-00410   [2]   Piston
65   SA7223-00430   [2]   Stop
66   SA7223-00010   [1]   Shaft
67   VOE14506666   [2]   Support
68   SA7223-00020   [1]   Shaft
69   VOE14506634   [2]   Pin
70   SA7223-00400   [1]   Pin
71   SA7223-00570   [1]   Pin
72   VOE14551796   [1]   Cover
73   VOE14560637   [29]   Plug
900   VOE14533619   [2]   Regulator kit   SER NO 10001-12912 SER NO 30001-30177
  VOE14533619   [2]   Regulator kit   SER NO 12913- SER NO 30178-
  SA7220-00550   [1]   Gear Pump   SER NO 10001-13328 SER NO 30001-30207
  VOE14536672   [1]   Gear pump   SER NO 13329- SER NO 30208-
100   VOE14534297   [1]   Sealing Kit   SER NO 10001-12912 SER NO 30001-30177
  VOE14554723   [1]   Seal   SER NO 12913- SER NO 30178-
