VOLVO EC250D EC250E EC300D EC300E EXCAVATOR TRAVEL MOTOR PARTS

VOLVO EC250D EC250E EC300D EC300E EXCAVATOR TRAVEL MOTOR PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
  VOE14704091 EC250D EC250E EC300D EC300E
Pos. Part No Qty Parts name Comments
  VOE14704091   [1]   Travel  motor
1   VOE14604828   [1]   Casing
2   VOE14604841   [1]    O-ring
3   VOE960260   [1]   O-ring
4   VOE983497   [1]   O-ring
5   VOE983507   [1]   O-ring
6   VOE14704273   [1]   Cylinder
  VOE14506978   [1]   Plate
  VOE14603001   [1]   Cylinder block
7   VOE14551797   [9]   Piston
8   VOE14551525   [1]   Pin
9   VOE990585   [2]   O-ring
10   SA7242-10540   [2]   Cover
11   SA7242-10750   [2]   Screw
12   VOE983497   [2]   O-ring
13   SA9415-31021   [7]   Plug
14   VOE993320   [7]   O-ring
15   VOE14506972   [1]   Plate
16   VOE984848   [2]   Hex. socket screw
17   VOE14560637   [10]   Plug
18   VOE968131   [8]   Hex. socket screw
19   SA9415-31041   [2]   Plug
20   VOE993322   [2]   O-ring
21   VOE984229   [4]   Hex. socket screw
22   SA7242-10710   [2]   Clamping plate
23   SA7242-10720   [2]   Guard
24   VOE14880998   [2]   Ball
25       [1]   Nameplate
26   SA1010-11360   [2]   Screw
27   SA7242-10520   [2]   Washer
28   SA7242-10530   [2]   Spring
29   SA7242-11560   [1]   Spring
30   VOE14507000   [1]   Spacer
31   SA7242-11290   [1]   Plug
32   VOE983509   [1]   O-ring
33   VOE14509997   [1]   Spool
34   VOE14506994   [1]   Spring
35   VOE14506995   [1]   Plug
36   VOE983505   [1]   O-ring
37   VOE14579610   [1]   Control plunger
38   VOE14604829   [1]   Shaft
39   VOE14640025   [1]   Roller bearing
40   VOE14506955   [1]   Bearing
41   VOE914472   [1]   Snap ring
42   VOE14604826   [1]   Casing
43   SA7242-10590   [1]   Seal
44   SA8320-01810   [1]   Retaining ring
45   VOE14506958   [2]   Pivot
46   VOE14604837   [1]   Piston
47   VOE14551526   [1]   Pin
48   VOE14604834   [3]   Plate
49   VOE14604835   [2]   Plate
50   VOE14604833   [1]   Piston
51   VOE960262   [1]   O-ring
52   VOE960262   [1]   O-ring
53   VOE14568004   [10]   Spring
54   VOE14604831   [1]   Plate
55   VOE14603001   [1]   Cylinder block
56   VOE14506967   [9]   Spring
57   VOE14506968   [1]   Spacer
58   VOE14506970   [1]   Guide
59   VOE14506950   [1]   Spool
60   VOE14880996   [2]   Ball
61   VOE14548116   [2]   Relief valve
62   SA8240-03680   [2]   Snap ring
63   VOE990582   [2]   O-ring
64   VOE14880837   [2]   Back-up ring
65   VOE14548120   [2]   Spring
66   SA7273-30540   [4]   Ring
67   VOE983542   [2]   O-ring
68   VOE983501   [2]   O-ring
69   VOE14625244   [2]   Ring
70   VOE983527   [2]   O-ring
  VOE14596398   [1]   Seal
