VOLVO EC240B EXCAVATOR Travel gearbox

VOLVO EC240B EXCAVATOR Travel gearbox

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group Travel gearbox:EC240B Travel gearbox SER NO INT 12641- EU & NA 80001- NoneNone 8277649,8277650,8277651,8279629,8279630,8279631 Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14528735   [1]   Gearbox
1   VOE14528715   [1]   Housing
2   VOE14538940   [2]   Bearing
3   SA7117-34120   [1]   Ring gear
4   SA9016-21818   [20]   Hex. socket screw
5   VOE14528720   [1]   Seal
6   VOE14883847   [3]   Plug
7   SA7117-34190   [1]   Retainer
8   VOE997446   [12]   Hexagon screw
9   SA7117-34200   [1]   Planet carrier
10   SA7117-34210   [1]   Carrier
11   SA7117-34220   [4]   Planetary gear
12   SA7117-34230   [8]   Needle bearing
13   SA7117-34240   [8]   Washer
14   SA7117-34250   [4]   Pin
15   VOE13951991   [4]   Spring pin
16   VOE14528721   [1]   Planet carrier
17   VOE14528722   [1]   Carrier
18   SA1036-00310   [1]   Thrust ring
19   SA7117-34280   [1]   Gear
20   SA8230-21020   [1]   Thrust ring
21   SA7117-34290   [1]   Retaining ring
22   SA7117-34300   [3]   Planetary gear
23   SA7117-34310   [3]   Needle bearing
24   VOE14556491   [6]   Washer
25   SA7117-34330   [3]   Pin
26   SA9325-06012   [3]   Spring pin
27   SA7117-34340   [1]   Planet carrier
28   SA7117-34350   [1]   Planet carrier
29   SA7117-34370   [3]   Pin
30   SA9325-06012   [3]   Spring pin
31   SA7117-34360   [1]   Gear
32   SA7117-34440   [1]   Retaining ring
33   SA7117-34420   [3]   Planetary gear
34   SA7117-34380   [3]   Needle bearing
35   SA7117-34390   [3]   Washer
36   SA7117-34400   [3]   Washer
37   SA9541-01034   [3]   Retaining ring
38   SA1036-00290   [2]   Thrust ring
39   SA7117-34430   [1]   Gear
40   VOE14601854   [1]   Cover
41   VOE955922   [16]   Spring washer
42   VOE993025   [16]   Hexagon screw
43   SA7117-34140   [1]   Shim   0.1t
44   SA7117-34150   [1]   Shim   0.3t
45   SA7117-34160   [1]   Shim   0.5t
46   SA7117-34170   [1]   Shim   1.0t
47   SA1036-00450   [1]   Shim
48   SA1036-00460   [1]   Shim
49   VOE990557   [3]   O-ring
100   VOE14526221   [1]   Overhaul kit
