| Parts on group Swing gearbox:EC240B Swing gearbox SER NO INT 12641- EU & NA 80001- 8277587-None NoneNone None Autodata Volvo online |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
|
VOE14542163 |
[1] |
Gearbox |
|
| 1 |
VOE14518703 |
[1] |
Carrier |
|
| 2 |
SA1036-00530 |
[1] |
Crankshaft |
|
| 3 |
SA1036-00550 |
[3] |
Planetary Gear |
|
| 4 |
SA1036-00610 |
[3] |
Pin |
|
| 5 |
SA7118-34231 |
[3] |
Pin |
|
| 6 |
SA7118-34260 |
[3] |
Bushing |
|
| 7 |
SA1036-00620 |
[6] |
Washer |
|
| 8 |
SA9325-10012 |
[3] |
Spring pin |
|
| 9 |
VOE14640028 |
[1] |
Bearing |
|
| 10 |
SA1036-00710 |
[1] |
Bearing |
|
| 11 |
SA1036-00630 |
[1] |
Knob |
|
| 12 |
VOE14558605 |
[1] |
Seal |
SER NO 10001-13402 SER NO 80001-81085 |
|
VOE14558605 |
[1] |
Seal |
SER NO 13403- SER NO 81086- |
| 13 |
SA7118-01560 |
[1] |
Plate |
|
| 14 |
SA7114-12590 |
[4] |
Screw |
|
| 15 |
VOE14504206 |
[1] |
Gear |
|
| 16 |
SA1036-00700 |
[4] |
Pin |
|
| 17 |
SA7118-34340 |
[1] |
Casing |
|
| 18 |
VOE14510986 |
[1] |
Sun gear |
|
| 19 |
VOE984369 |
[16] |
Hex. socket screw |
|
| 20 |
VOE14550896 |
[1] |
Carrier |
|
| 21 |
SA7118-34410 |
[1] |
Carrier |
|
| 22 |
SA7118-34420 |
[3] |
Planetary Gear |
|
| 23 |
VOE14550897 |
[3] |
Pin |
|
| 24 |
SA7118-34440 |
[3] |
Needle bearing |
|
| 25 |
SA7118-34450 |
[3] |
Washer |
|
| 26 |
SA7118-34460 |
[3] |
Washer |
|
| 27 |
SA9541-01085 |
[3] |
Retaining ring |
|
| 28 |
SA9325-08010 |
[3] |
Spring pin |
|
| 29 |
SA7118-34470 |
[1] |
Gear |
|
| 30 |
SA7118-34480 |
[1] |
Washer |
|
| 31 |
SA7118-34490 |
[1] |
Sun gear |
|
| 32 |
VOE984354 |
[8] |
Hex. socket screw |
|
| 33 |
VOE14514384 |
[1] |
Pipe |
SER NO 10001-12701 SER NO 30001-30199 |
|
VOE14540597 |
[1] |
Pipe |
SER NO 12702- SER NO 30200- |
| 34 |
SA1012-01500 |
[1] |
Valve |
|
| 35 |
|
[1] |
Casing |
|
| 36 |
SA9541-01085 |
[1] |
Retaining ring |
|
| 37 |
VOE949329 |
[1] |
Gasket |
|
| 100 |
VOE14526215 |
[1] |
Overhaul kit |
|
| 200 |
VOE14627726 |
[1] |
Housing |
inc 15,16,35 |
