VOLVO EC240B EC240C FC2924C EXCAVATOR VOE14531594 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

Name: VOLVO EC240B EC240C FC2924C EXCAVATOR VOE14531594 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

VOLVO EC240B EC240C FC2924C EXCAVATOR VOE14531594 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

VOE14531594 EC240B EC240C FC2924C

Pos.	Part No	Qty	Parts name	Comments
	VOE14531594	[1]	Pump
1	VOE14603707	[2]	Piston
2		[9]	Piston
3		[9]	Seat
4	VOE14541876	[1]	Cylinder
5		[1]	Block
6		[1]	Plate
7	VOE14541875	[1]	Cylinder
8		[1]	Block
9		[1]	Plate
10	VOE14541874	[2]	Plate
11	VOE14541874	[1]	Plate
12		[1]	Bushing
13	SA7223-00450	[2]	Non-return valve
14		[1]	Seat
15		[1]	Guard
16		[1]	Ball
17	SA7223-00460	[2]	Non-return valve
18		[1]	Seat
19		[1]	Guard
20		[1]	Ball
21	VOE14535453	[1]	Valve
22	VOE14533608	[1]	O-ring
23	VOE14533606	[4]	O-ring
24	VOE14560637	[3]	Plug
25	VOE14883837	[1]	Plug
26	SA8230-25880	[3]	Hex. socket screw
27	SA8230-32080	[1]	Valve
28	VOE14535454	[1]	O-ring
29	VOE14535455	[1]	O-ring
30	VOE14535456	[1]	O-ring
31	VOE14541872	[1]	Shaft
32	SA8230-21920	[2]	Plate
33	VOE14609379	[2]	Support
34	VOE14541861	[1]	Cover
35	VOE14541860	[1]	Casing
36	SA8230-08980	[1]	Valve block
37	SA8230-09690	[8]	Hex. socket screw
38	VOE13967630	[4]	Allen Hd Screw
39	VOE14883837	[3]	Plug
40	SA9415-11051	[4]	Plug
41	VOE14560637	[21]	Plug
42	VOE14541873	[2]	Pin
43		[1]	Pin
44		[1]	Pin
45	VOE14540778	[2]	Piston
46	SA8230-09640	[2]	Plug
47	SA8230-09650	[2]	Plate
48	VOE14533615	[2]	O-ring
49	VOE14535450	[1]	O-ring
50	VOE14535451	[4]	O-ring
51	VOE14533604	[16]	O-ring
52	VOE14533606	[8]	O-ring
53	VOE14533612	[4]	O-ring
54	VOE14533609	[2]	O-ring
55	VOE14600699	[1]	Seal
56	VOE14625246	[2]	Ring
57	SA9566-20350	[2]	Back-up ring
58	SA8230-25620	[2]	Nut
59	VOE979022	[2]	Hexagon nut
60	VOE13914468	[2]	Snap ring
61	SA8230-26430	[2]	Plate
62	SA7223-00660	[4]	Spring pin
63	VOE14623509	[2]	Eye bolt
64	VOE14540770	[2]	Screw
65	SA8230-09700	[2]	Bolt
66	VOE14541871	[1]	Shaft
67	VOE14541870	[1]	Clutch
68	VOE14535425	[2]	Bearing
69	VOE14541869	[2]	Bearing
70	SA8230-14530	[4]	Spacer
71	VOE14541865	[2]	Plate
72	VOE14535448	[2]	Bushing
73	VOE14541864	[18]	Spring
100	VOE14525082	[1]	Sealing kit
Parts on group Regulator, hydraulic pump:

Pos.	Part No	Qty	Parts name	Comments
	VOE14541878	[2]	Regulator control
1	SA8230-25910	[2]	Hex. socket screw
2	SA8230-25920	[2]	Bolt
3	SA8230-25860	[2]	Bolt
4	SA8230-25850	[10]	Bolt
5	VOE14560637	[5]	Plug
6		[1]	Casing
7		[1]	Lever
8		[1]	Lever
9		[1]	Lever
10		[1]	Plug
11		[1]	Plug
12		[1]	Piston
13		[1]	Case
14		[1]	Rod
15		[1]	Seat
16		[1]	Spring
17		[1]	Spring
18		[1]	Stem
19		[1]	Screw
20		[1]	Cover
21		[1]	Lock nut
22		[1]	Sleeve
23		[1]	Cover
24		[1]	Piston
25		[1]	Seat
26		[1]	Ring
27		[1]	Spring
28		[1]	Sleeve
29		[1]	Spool
30		[1]	Seat
31		[1]	Spring
32		[1]	Spring
33		[1]	Cover
34	VOE14533616	[1]	O-ring
35	VOE14533603	[3]	O-ring
36	VOE14533604	[2]	O-ring
37	VOE14533605	[1]	O-ring
38	VOE14533609	[1]	O-ring
39	VOE14533611	[1]	O-ring
40	VOE14533608	[2]	O-ring
41	VOE14540773	[1]	O-ring
42	VOE14533614	[1]	O-ring
43	VOE14601515	[1]	O-ring
44	VOE14533606	[2]	O-ring
45	VOE14533613	[1]	O-ring
46	VOE14533615	[1]	O-ring
47	SA9113-10800	[2]	Hexagon nut
48	SA8240-03680	[1]	Snap ring
49	SA8230-26960	[1]	Ring
50	VOE914503	[2]	Retaining ring
51		[1]	Pin
52		[4]	Pin
53		[1]	Pin
54		[1]	Pin
55		[1]	Pin
56		[1]	Screw
57	VOE14535390	[1]	Screw
100	VOE14525082	[1]	Sealing kit
