VOLVO EC240 EC240B EC240C FC2924C EXCAVATOR VOE14550094 VOE14573054 SWING MOTOR ROTARY GROUP AND SPARE PARTS

VOLVO EC240 EC240B EC240C FC2924C EXCAVATOR VOE14550094 VOE14573054 SWING MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
VOE14550094  VOE14573054
EC240 EC240B EC240C FC2924C
Pos. Part No Qty Parts name Comments
1   VOE14573054   [1]   Swing Motor
2   VOE14550094   [1]   Swing motor
3   VOE14542163   [1]   Gearbox
4   VOE14514380   [1]   Pipe
5   VOE14514381   [1]   Pipe
6   VOE14514385   [1]   Gauge
7   VOE13914468   [1]   Snap ring
8   VOE14531015   [1]   Plate
9   VOE14531024   [1]   Pin
10   SA1155-00050   [1]   Swing gear
11   VOE14531107   [1]   Plate
12   VOE997459   [2]   Hexagon screw
13   VOE997474   [14]   Hexagon screw
14   VOE60110287   [14]   Washer
Parts on group Swing motor:
Pos. Part No Qty Parts name Comments
  VOE14550094   [1]   Swing motor
1 VOE14500062   [1]   Piston
2   VOE14509246   [1]   Casing
3   VOE14500066   [1]   Shaft
4   SA8230-13500   [1]   Spacer
5 SA8230-13680   [1]   Cylinder
6   SA8230-13700   [1]   Retainer
7   SA8230-13460   [1]   Spring
8   SA8230-26390   [12]   Bar
9   SA8230-13490   [3]   Spacer
10   SA8230-13630   [1]   Plate
11   SA8230-13710   [1]   Plate
12   SA8230-13750   [1]   Plate
13   SA8230-13580   [1]   Casing
14   SA8230-13540   [1]   Cover
15   VOE14501798   [2]   Plunger
16   VOE14501799   [2]   Spring
17   SA8230-25820   [4]   Bolt
18   SA8230-25760   [1]   Ring
19   SA8230-25740   [1]   Ring
20   SA8230-26530   [1]   Roller bearing
21   SA8230-26600   [1]   Roller bearing
22   SA8230-25640   [2]   Plug
23   VOE14501802   [2]   Plug
24   SA8230-25551   [1]   O-ring
25   VOE983502   [2]   O-ring
26   VOE983530   [2]   O-ring
27   VOE983503   [2]   O-ring
28   VOE14563078   [1]   Seal
29   SA8220-10730   [1]   Piston
30   VOE14552321   [1]   O-ring
31   SA8230-25560   [1]   O-ring
32   SA8230-14040   [12]   Spring brake
33   SA8230-13770   [3]   Friction plate
34   SA8230-13720   [4]   Separating plate
35   SA8230-13450   [1]   Slide
36   SA8230-13480   [1]   Spring
37   VOE14500067   [1]   Plunger
38   VOE14560637   [3]   Plug
39   VOE14518517   [2]   Relief valve   SER NO 10001-10527
  VOE14518517   [2]   Relief valve   SER NO 10528- SER NO 30001-
40   VOE990582   [1]   O-ring
41   VOE14880837   [1]   Back-up ring   SER NO 10001-10527
42   SA8230-27360   [1]   Block
43   SA8230-29070   [1]   Casing
44   SA8230-25640   [2]   Plug
45   VOE983502   [2]   O-ring
46   VOE983503   [2]   O-ring
47   VOE983493   [2]   O-ring
48   SA8240-03610   [4]   Screw
49   VOE14684415   [2]   Valve
50   VOE983509   [1]   O-ring
51   VOE14625240   [1]   Ring
52   SA8230-13550   [1]   Cover
53   SA8230-25830   [2]   Hex. socket screw
100   VOE14556029   [1]   Seal
