VOLVO EC210D EC220D EC220E EC250D EC250E EXCAVATOR VOE14728804 VOE14728665 TRAVEL MOTOR ROTARY GROUP

VOLVO EC210D EC220D EC220E EC250D EC250E EXCAVATOR VOE14728804 VOE14728665 TRAVEL MOTOR ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
EC210D EC220D EC220E EC250D EC250E VOE14728804 VOE14728665
  VOE14728665   [1]   Travel motor
  VOE14728665       Travel motor
1   VOE14719538   [1]   Cylinder block
2   VOE14567677   [1]   Piston
3   VOE14719539   [1]   Shaft
4   VOE14721121   [1]   Plate
5   VOE14569268   [1]   Piston
6   VOE14721122   [3]   Friction plate
7   VOE14721123   [2]   Plate
8   VOE14721124   [1]   Ball bearing
9   VOE14621704   [2]   Pivot
10   SA8230-21610   [4]   Pin
11   VOE14567156   [1]   Spring
12   VOE14719297   [1]   Spindle
13   VOE14569269   [1]   Flange
14   VOE14719535   [2]   Plug
15   SA8230-03610   [2]   Spring
16   VOE14703388   [2]   Non-return valve
17   VOE14719534   [2]   Plug
18   SA8230-02760   [2]   Spring
19   VOE14569270   [2]   Spring guide
20   VOE14569272   [6]   Plug
21   VOE14567682   [2]   Plug
22   VOE14622052   [2]   Ball
23   VOE14573791   [1]   Spring
24   VOE14567683   [1]   Plug
25   VOE14717109   [1]   Spool
26   VOE14567691   [3]   Plug
27   SA8230-02690   [1]   Ring
28   VOE14569273   [1]   Valve guide
29   SA8230-02670   [1]   Spring
30   SA8230-04940   [1]   Valve
31   VOE14721127   [1]   Ball bearing
32   VOE14567685   [1]   Throttle sleeve
33   VOE14621706   [1]   Pin
34   VOE14721128   [12]   Spring
35   VOE14721129   [1]   Plate
36   VOE14722621   [12]   Bolt
37   VOE14737472   [2]   Relief valve   SEE SB 441/90
38   VOE14569274   [1]   Sealing kit
  VOE14634645  VOE14651069 VOE14690440   VOE14694041   VOE14698790   VOE14704450   VOE14729053   VOE14735961
  VOE14604840   VOE14626809   VOE14674258   VOE14728665   VOE14728804
Pos. Part No Qty Parts name Comments
1   VOE14634645       Drive unit
1   VOE14634645   [2]   Drive unit   S/N -230428/ -240159 S/N -270667/ -280026
1   VOE14694041   [2]   Drive unit   S/N 270668-270693 S/N 280027-280030
1   VOE14698790   [2]   Drive unit   S/N 230429-231006 S/N 240160-245005
1   VOE14704450   [2]   Drive unit   S/N 270723-270849 S/N 280034-280177
1   VOE14729053   [2]   Drive unit   S/N 270850-270930 S/N 280178-280308
1   VOE14735961   [2]   Drive unit   S/N 270931-, 280309-, 245025-, 231928-
1   VOE14690440       Drive Unit
2   VOE14626809       Travel motor
2   VOE14626809   [2]   Travel motor   S/N -245005/-231006 S/N -270693/-280030
2   VOE14674258   [2]   Travel motor   S/N 230429-231006 S/N 240160-245005
2   VOE14728665   [2]   Travel motor   S/N 270723-270849 S/N 280034-280177
2   VOE14728665   [2]   Travel motor   S/N 270850-270930 S/N 280178-280308
2   VOE14728804   [2]   Travel motor   S/N 270931-/ 280309-/ 231928-
2   VOE14604840       Travel motor
3   VOE14621718       Travel gearbox
3   VOE14621718   [2]   Travel gearbox   S/N -230428/ -240159 S/N -270667/ -280026
3   VOE14693059   [2]   Travel gearbox   S/N 270668-270930 S/N 280027-280308
3   VOE14735901   [2]   Travel gearbox   S/N 270931-/ 280309- 231928-
3   VOE14599921       Travel gearbox
4   VOE60110321   [60]   Hexagon screw
4   VOE997474       Hexagon screw
5   VOE60110299   [60]   Washer
5   VOE60110287       Washer
