VOLVO EC210B EC240B EC240C FC2421C EXCAVATOR VOE14533652 VOE14528734 TRAVEL MOTOR PARTS

VOLVO EC210B EC240B EC240C FC2421C EXCAVATOR VOE14533652 VOE14528734 TRAVEL MOTOR PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
  VOE14533652，  VOE14528734
EC210B EC240B EC240C FC2421C
Pos. Part No Qty Parts name Comments
1   VOE14528734   [2]   Drive unit
2   VOE14533652   [1]   Hydraulic motor
3   VOE14528735   [1]   Gearbox
4   VOE60110321   [60]   Hexagon screw
5   VOE60110299   [60]   Washer
Parts on group Travel motor:
Pos. Part No Qty Parts name Comments
  VOE14533652   [1]   Hydraulic motor
1   SA8230-21631   [1]   Cylinder
2   SA8230-28900   [9]   Piston
3   VOE14500075   [1]   Piston
4   VOE14500076   [1]   Seat
5       [1]   Block
6   VOE14570920   [1]   Plate
7   SA8230-21540   [1]   Ball
8   SA8230-31160   [2]   Washer
9   SA8230-21560   [1]   Washer
10   SA8230-21570   [1]   Spring
11   VOE14500077   [1]   Ring
12   VOE14500078   [5]   Bearing
13   SA8230-15140   [1]   Piston
14   VOE14500079   [1]   Piston
15   VOE14500080   [1]   Seat
16   VOE14504883   [1]   Shaft
17   SA8230-21520   [1]   Protecting plate
18   SA8230-21550   [1]   Protecting plate
19   SA8230-21650   [1]   Piston
20   SA8230-21660   [12]   Spring
21   SA8230-21670   [2]   Friction plate
22   SA8230-03560   [2]   Plate
23   VOE14621703   [1]   Seal
24   VOE990656   [1]   O-ring
25   VOE990660   [1]   O-ring
26   VOE14551534   [1]   Ball bearing
27   VOE14531426   [1]   Bearing
28   SA8230-21600   [2]   Support
29   SA8230-21610   [4]   Pin
30   SA8230-15150   [1]   Spring
31   VOE14536877   [1]   Spindle
32   VOE983495   [2]   O-ring
33   VOE960259   [1]   O-ring
34   SA8220-13340   [1]   Pin
35   VOE14500083   [1]   Flange
36       [1]   Flange
37   VOE14500084   [1]   Flange
38   VOE14500085   [1]   Spool
39   VOE14535476   [1]   Piston
40   SA8230-02710   [2]   Plug
41   SA8230-21700   [2]   Stop
42   SA8230-03590   [2]   Plug
43   SA8230-03600   [2]   Non-return valve
44   SA8230-02760   [2]   Spring
45   SA8230-03610   [2]   Spring
46   SA8220-14930   [4]   Plug
47   VOE990607   [2]   O-ring
48   VOE983523   [2]   O-ring
49   SA8230-30410   [2]   Plug
50   VOE14573795   [2]   Plug
51   SA8220-14920   [8]   Plug
52   VOE14573793   [2]   Plug
53   SA8230-21710   [1]   Coil
54   VOE14573791   [1]   Spring
55   SA9676-38000   [2]   Ball
56   VOE14617170   [1]   Filter
57   VOE14573784   [2]   Plug
58   SA8230-21890   [2]   Plug
59   VOE990551   [2]   O-ring
60   VOE983495   [2]   O-ring
61   VOE14500088   [2]   Ball
62   VOE983502   [2]   O-ring
63   VOE990557   [2]   O-ring
64   VOE983505   [2]   O-ring
65   VOE14526489   [1]   Orifice
66   VOE13968816   [12]   Allen Hd Screw
67   SA8230-21640   [1]   Relief valve
  VOE14533743   [1]   Sealing ring   Relief valve seal kit
100   VOE14553290   [1]   Sealing ring
