VOLVO EC200D Swing gearbox S/N 280001-,- 240000, S/N - 280330

VOLVO EC200D Swing gearbox S/N 280001-,- 240000, S/N - 280330

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
EC200D Swing gearbox S/N 280001- NoneNone S/N - 240000, S/N - 280330 Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14712521   [1]   Swing gearbox
1   VOE14712522   [1]   Shaft
2   VOE14712523   [1]   Collar
3   VOE990600   [1]   O-ring
4   VOE14712524   [1]   Bearing
5   VOE14737753   [1]   Case
6   VOE14712525   [1]   Bearing
7   VOE14712544   [2]   Collar   THICK = 9,8 mm
7   VOE14712545   [2]   Collar   THICK = 9,9 mm
7   VOE14712546   [2]   Collar   THICK = 10,0 mm
7   VOE14712547   [2]   Collar   THICK = 10,1 mm
7   VOE14712548   [2]   Collar   THICK = 10,2 mm
7   VOE14712549   [2]   Collar   THICK = 10,3 mm
7   VOE14712550   [2]   Collar
8   VOE14508911   [1]   Seal
9   VOE14883953   [2]   Pin
10   VOE14737754   [1]   Gear
  VOE14712528   [1]   Planet carrier
11   VOE14712529   [1]   Planet carrier
12   VOE14712530   [3]   Gear
13   VOE14712532   [3]   Bushing
14   VOE14712533   [6]   Thrust washer
15   VOE14712531   [3]   Pin
16   SA9325-06012   [3]   Spring pin
17   VOE14712534   [1]   Gear
18   SA7118-30380   [1]   Thrust ring
19   VOE14883955   [1]   Retaining ring
  VOE14712536   [1]   Planet carrier
20   VOE14712537   [1]   Planet carrier
21   SA1036-00120   [1]   Thrust washer
22   VOE14712538   [3]   Gear
23   VOE14712540   [3]   Needle roller bearing
24   VOE14712533   [6]   Thrust washer
25   VOE14712539   [3]   Pin
26   SA9325-06012   [3]   Spring pin
27   VOE14712541   [1]   Gear
28   VOE997885   [8]   Hex. socket screw
29   VOE14712542   [1]   Outlet pipe
30   VOE14883863   [1]   Plug
