VOLVO EC200D EXCAVATOR VOE14719059 VOE14715510 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

VOLVO EC200D EXCAVATOR VOE14719059 VOE14715510 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
VOE14719059 VOE14715510 EC200D
Pos. Part No Qty Parts name Comments
1   VOE14719059   [2]   Drive unit
2   VOE14715510   [1]   Travel motor
3   VOE14713821   [1]   Travel gearbox
4   VOE60110299   [60]   Washer
5   VOE60110356   [60]   Hexagon screw
Pos. Part No Qty Parts name Comments
  VOE14715510   [1]   Travel  motor
1   VOE14567678   [1]   Flange
2   VOE14567683   [2]   Plug
3   VOE14622061   [3]   Plug
4   VOE14567686   [3]   Plug
5   VOE14567684   [1]   Throttle sleeve
6   VOE14567682   [2]   Plug
7   VOE14622052   [2]   Ball
8   VOE14567685   [1]   Throttle sleeve
9   VOE14721127   [1]   Ball  bearing
10 VOE14703388   [2]   Non-return valve
11   SA8230-03610   [2]   Spring
12   VOE14719535   [2]   Plug
13   VOE14719534   [2]   Plug
14   VOE14567679   [2]   Valve guide
15   SA8230-02760   [2]   Spring
16   VOE14567691   [3]   Plug
17   VOE14622053   [1]   Spring
18   VOE14622054   [1]   Spool
19   VOE14722621   [12]   Bolt
20   VOE14621706   [1]   Pin
21   VOE14567238   [1]   Plug
22   VOE14721129   [1]   Plate
23 VOE14567681   [12]   Spring
24 VOE14567669   [1]   Piston
25   VOE14721123   [2]   Plate
26   VOE14721122   [2]   Friction plate
27 VOE14719538   [1]   Cylinder block
28   VOE14567235   [1]   Plate
29   SA8230-21600   [2]   Support
30   SA8230-21610   [4]   Pin
31   VOE14567677   [1]   Piston
32   VOE14567156   [1]   Spring
33   VOE14567237   [1]   Shaft
34   VOE14567236   [1]   Spindle
35   VOE14567692   [2]   Relief valve
36   VOE14622988   [1]   Sealant
37   VOE14721124   [1]   Ball bearing
38   VOE14567693   [1]   Sealing kit
