VOLVO EC200D EXCAVATOR VOE14715509 SWING MOTOR ROTARY GROUP AND SPARE PARTS

VOLVO EC200D EXCAVATOR VOE14715509 SWING MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
VOE14715509 EC200D
Pos. Part No Qty Parts name Comments
1   VOE14712521   [1]   Swing gearbox
2   VOE14715509   [1]   Swing motor
3   VOE14882609   [1]   Retaining ring
4   VOE14712543   [1]   Inlet pipe
5   VOE14726941   [1]   Gauge
6   VOE60110250   [8]   Hex. Socket Screw
7   VOE60110287   [11]   Washer
8   VOE997474   [11]   Hexagon screw
9   VOE14531024   [1]   Pin
Pos. Part No Qty Parts name Comments
  VOE14715509   [1]   Swing motor
1   VOE14594933   [1]   Piston
2   VOE14735330   [1]   Casing
3   SA7223-00660   [2]   Spring pin
4   VOE14550664   [1]   Valve
  VOE14594353   [2]   Plug
5   VOE14735327   [2]   Relief valve
6   VOE14528251   [1]   O-ring
7   VOE14552329   [2]   O-ring
8   VOE14552320   [1]   Seal
9   VOE14512953   [1]   Piston
10   VOE14693875   [1]   O-ring
11   SA8230-25540   [1]   O-ring
12   VOE14529763   [20]   Spring
13   VOE14529762   [3]   Plate
14   VOE14529761   [4]   Plate
15   VOE14594354   [3]   Plug
16   VOE14612051   [1]   Plug
17   VOE14529774   [1]   Shaft
18   VOE14529773   [1]   Cylinder
19   VOE14529772   [1]   Spring
20   VOE14529771   [1]   Plate
21   VOE14529770   [1]   Plate
22 VOE14529769   [1]   Plate
23   VOE14735329   [1]   Casing
24   VOE14552322   [1]   Cover
25   SA8230-14160   [2]   Control plunger
26   SA8230-14150   [2]   Spring
27   SA8230-25820   [4]   Bolt
28   VOE14529766   [1]   Ring
29   VOE14623517   [1]   Bearing
30   VOE14529765   [1]   Bearing
31   SA8230-25680   [2]   Plug
32   VOE14552321   [1]   O-ring
33   VOE14558299   [1]   Valve
34   VOE14550661   [1]   Casing
35   VOE14550218   [2]   Plug
36   SA8230-26191   [2]   O-ring
37   VOE14529757   [2]   O-ring
38   VOE14533603   [2]   O-ring
39   SA8240-03610   [4]   Screw
40   VOE14558298   [2]   Valve
41   VOE983509   [1]   O-ring
42   VOE14625240   [1]   Ring
43   VOE14529759   [1]   Plug
44   VOE14511643   [3]   Screw
