VOLVO EC200D EXCAVATOR VOE14713821 TRAVEL REDUCTION GEARBOX PARTS

VOLVO EC200D EXCAVATOR VOE14713821 TRAVEL REDUCTION GEARBOX PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group Travel motor:
Pos. Part No Qty Parts name Comments
  VOE14713821   [2]   Travel gearbox
1   VOE14713822   [1]   Housing
2   VOE14693033   [2]   Bearing
3   VOE14713823   [1]   Seal
  VOE14730966   [2]   Sealing ring
  VOE14730967   [2]   O-ring
4   VOE14712551   [3]   Collar   THICK = 10,8 mm
4   VOE14726582   [3]   Collar   THICK = 10,9 mm
4   VOE14726583   [3]   Collar   THICK = 11,0 mm
4   VOE14726584   [3]   Collar   THICK = 11,1mm
4   VOE14726585   [3]   Collar   THICK = 11,2 mm
4   VOE14726586   [3]   Collar   THICK = 11,3 mm
4   VOE14732107   [3]   Collar   THICK = 11,4 mm
5   SA9324-21212   [2]   Pin
6   VOE14713825   [1]   Gear
  VOE14713826   [1]   Planet carrier
7   VOE14713827   [1]   Planet carrier
8   SA1036-00290   [1]   Thrust ring
9   VOE14713828   [4]   Gear
10   VOE14713829   [4]   Needle roller bearing
11   VOE14718296   [8]   Thrust washer
12   VOE14713830   [4]   Pin
13   SA9325-06012   [4]   Spring pin
14   VOE14713831   [1]   Gear
15   VOE948341   [1]   Snap ring
  VOE14713832   [1]   Planet carrier
16   VOE14713833   [1]   Planet carrier
17   VOE14713834   [3]   Gear
18   VOE14713835   [3]   Needle roller bearing
19   VOE14713836   [6]   Thrust washer
20   VOE14713837   [3]   Pin
21   SA9325-06012   [3]   Spring pin
22   VOE14505753   [1]   Ring
23   VOE14713838   [1]   Gear
24   SA7117-15230   [1]   Pad
25   VOE14713839   [1]   Cover
26   VOE60113872   [16]   Plain washer
27   VOE997473   [16]   Hexagon screw
28   VOE983505   [2]   O-ring
29   VOE14577793   [2]   Plug
30   VOE914515   [1]   Retaining ring
