VOLVO EC160C EXCAVATOR VOE14538585 FINAL DRIVE VOE14538546 TRAVEL MOTOR PARTS

VOLVO EC160C EXCAVATOR VOE14538585 FINAL DRIVE VOE14538546 TRAVEL MOTOR PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
EC160C Travel motor with mounting parts 120001-120962 140001-140192  8280371-8280372 NoneNone None Autodata Volvo online
VOE14538585 VOE14538546 EC160C
Pos. Part No Qty Parts name Comments
1   VOE14538585   [2]   Drive unit
2   VOE14538546   [1]   Engine
3   VOE14528733   [1]   Travel gearbox
Pos. Part No Qty Parts name Comments
  VOE14538546   [1]   Engine
1   SA8230-21631   [1]   Cylinder
2   SA8230-28900   [9]   Piston
3   VOE14500075   [1]   Piston
4   VOE14500076   [1]   Seat
5       [1]   Block
6   SA8230-21530   [1]   Plate
7   SA8230-21540   [1]   Ball
8   SA8230-31160   [2]   Washer
9   SA8230-21560   [1]   Washer
10   SA8230-21570   [1]   Spring
11   VOE14500077   [1]   Ring
12   VOE14500078   [5]   Bearing
13   SA8230-15140   [1]   Piston
14   VOE14500079   [1]   Piston
15   VOE8230-28790   [1]   Seat
16   SA8230-33140   [1]   Drive shaft
17   VOE14519069   [1]   Plate
18   SA8230-21550   [1]   Protecting plate
19   SA8230-21650   [1]   Piston
20   SA8230-21660   [12]   Spring
21   SA8230-21670   [2]   Friction plate
22   SA8230-03560   [2]   Plate
23   VOE14621703   [1]   Seal
24   VOE990656   [1]   O-ring
25   VOE990660   [1]   O-ring
26   VOE14551534   [1]   Ball bearing
27   VOE14531426   [1]   Bearing
28   SA8230-21600   [2]   Support
29   SA8230-21610   [4]   Pin
30   SA8230-15150   [1]   Spring
31   VOE14535473   [1]   Spindle
32   VOE983495   [2]   O-ring
33   VOE960259   [1]   O-ring
34   SA8220-13340   [1]   Pin
35   VOE14622759   [1]   Flange
36   VOE14553288   [1]   Flange
37   VOE14550653   [1]   Flange
38   VOE14502032   [1]   Spool
39   VOE14500086   [1]   Piston
40   SA8230-02710   [2]   Plug
41   SA8230-21700   [2]   Stop
42   SA8230-03590   [2]   Plug
43   SA8230-03600   [2]   Non-return valve
44   SA8230-02760   [2]   Spring
45   SA8230-03610   [2]   Spring
46   SA8220-14930   [4]   Plug
47   VOE990607   [2]   O-ring
48   VOE983523   [2]   O-ring
49   SA8230-30410   [2]   Plug
50   VOE14573795   [2]   Plug
51   SA8220-14920   [8]   Plug
52   VOE14573793   [2]   Plug
53   SA8230-21710   [1]   Coil
54   VOE14500087   [1]   Spring
55   SA9676-38000   [2]   Ball
56   VOE14617170   [1]   Filter
57   SA8230-23140   [2]   Plug
58   SA8230-21890   [2]   Plug
59   VOE990551   [2]   O-ring
60   VOE983495   [2]   O-ring
61   VOE14500088   [2]   Ball
62   VOE983502   [2]   O-ring
63   VOE990557   [2]   O-ring
64   VOE983505   [2]   O-ring
65   VOE14535474   [1]   Orifice
66   VOE13968816   [12]   Allen Hd Screw
67   SA8230-21640   [2]   Relief valve
  VOE14533743   [1]   Sealing ring
100   VOE14553290   [1]   Sealing ring
